PNEUMATIC BELT SANDER
Please read this manual carefully before you attempt to use
your tool so that you may use it properly and safely.
BABY BELTON
PROFESSIONAL TOOL
Model
Maximum Operating Pressure
Air Consumption (No Load)
Rated Speed (No Load)
Standard Belt Size
Mass (Weight)
Sound Pressure Level
Sound Power Level
Vibration Level
Thread Size of Air Inlet
Due to continuous product development/improvement the specifications and configurations in
this document are subject to change without prior notice.
Keep the manual handy – so you can use it whenever necessary.
Specifications
10×330 mm (25/64 ×13 )
Manufactured by :
NITTO KOHKI Co., Ltd.
2-9-4, Nakaikegami, Ohta-ku,
Tokyo, 146-8555, Japan
Tel : (81)-3-3755-1111
Fax : (81)-3-3753-8791
E-mail : overseas@nitto-kohki.co.jp
URL : www.nitto-kohki.co.jp
Model BB-10A
BB-10A
0.6 MPa
0.26 m
3
/min
−1
16000 r/min (min
)
0.6 kg
80 dB (A)
91 dB (A)
2
0.6 m/s
Rc 1/4
Original Instructions
Advertisement
Table of Contents
Related Manuals for Nitto Kohki Baby Belton BB-10A
Summary of Contents for Nitto Kohki Baby Belton BB-10A
- Page 1 Rc 1/4 Due to continuous product development/improvement the specifications and configurations in this document are subject to change without prior notice. Manufactured by : NITTO KOHKI Co., Ltd. 2-9-4, Nakaikegami, Ohta-ku, Tokyo, 146-8555, Japan Tel : (81)-3-3755-1111 Fax : (81)-3-3753-8791 E-mail : overseas@nitto-kohki.co.jp...
-
Page 2: Table Of Contents
Thank you very much for your purchase of this CONTENTS page IMPORTANT SAFETY INSTRUCTIONS …………………… 2 Nitto Kohki products. GENERAL: TOOLS …………………………………………… 2 Before using your tool, please read this manual GENERAL: PNEUMATIC TOOLS ………………………… 3 carefully so that you may use it properly to get INSTRUCTIONS FOR THIS TOOL …………………………... -
Page 3: Important Safety Instructions
IMPORTANT SAFETY BEFORE OPERATION INSTRUCTIONS Inspect tool before use. Before using, check that screws are securely When using the tool, please observe the safety tightened, that any protective cover or guard is precautions below to prevent possible accident or injury. securely in place, other parts are free from damage GENERAL: TOOLS and that the tool runs as it should. -
Page 4: General: Pneumatic Tools
Do not carry the tool by the air hose. becomes missing, contact the sales agent through Do not pull the air hose to disconnect. which you have purchased your tool or Nitto Kohki Co. Ltd, directly for a replacement. DISPOSAL... -
Page 5: Instructions For This Tool
Always keep your face away from Air Regulator the sanding surface. Oiler Always use the genuine Abrasive Belt for the Air Filter belt sander BB-10A (Nitto Kohki Co., Ltd.). Compressor 1. USAGE Cupla This is a handheld pneumatic belt sander designed 9.5mm (3/8”) I.D. - Page 6 Before you change or adjust the tool or parts, Push the Idle Pulley against the Housing to lock the always disconnect the air supply hose. Tension Bar. Never touch the moving parts in operation. Change the Abrasive Belt with a new one and press the Push Button.
-
Page 7: Thread Size Of Hose Fitting
mark on the Hosing. 4-7. Sanding Operation 2) Loosen the Hex. Socket Set Screw found at "A" on Caution Fig. 7 with Hex. Socket Screw Key 1.5 included in the package. Do not press the Abrasive Belt too hard upon the 3) Twist the Rear Valve Ass'y by 180 degrees around workpiece. -
Page 8: Exploded Diagram: Bb-10A
9. EXPLODED DIAGRAM: BB-10A Warning This diagram is for your reference only. Do not attempt to service or repair the Tool. Do not take the Tool apart. Contact an authorized Nitto dealer for all service and repair of the Tool. Improper service and repair can cause accidents and severe injuries. -
