PNEUMATIC BELT SANDER
Please read this manual carefully before you attempt to use
your tool so that you may use it properly and safely.
BABY BELTON
PROFESSIONAL TOOL
Maximum Operating Pressure
Air Consumption (No Load)
Rated Speed (No load)
Standard Belt Size
Mass (Weight)
Sound Pressure Level
Sound Power Level
Vibration Level
Thread Size of Air Inlet
Due to continuous product development/improvement the specifications and configurations in this
document are subject to change without prior notice.
Keep the manual handy – so you can use it whenever necessary.
Specifications
Model
Manufactured by :
NITTO KOHKI Co., Ltd.
2-9-4, Nakaikegami, Ohta-ku,
Tokyo, 146-8555, Japan
TEL
FAX
E-mail : overseas@nitto-kohki.co.jp
URL
Model BB-20
BB-20
0.6 MPa
3
0.43 m
/min
-1
16,000 r/min (min
)
20 x 330 mm
0.8 kg
86 dB (A)
97 dB (A)
2
0.6 m/s
Rc 1/4
: (81)-3-3755-1111
: (81)-3-3753-8791
: www.nitto-kohki.co.jp
Original Instructions
Advertisement
Table of Contents
Related Manuals for Nitto Kohki BB-20
Summary of Contents for Nitto Kohki BB-20
- Page 1 Thread Size of Air Inlet Rc 1/4 Due to continuous product development/improvement the specifications and configurations in this document are subject to change without prior notice. Manufactured by : NITTO KOHKI Co., Ltd. 2-9-4, Nakaikegami, Ohta-ku, Tokyo, 146-8555, Japan : (81)-3-3755-1111 : (81)-3-3753-8791 E-mail : overseas@nitto-kohki.co.jp...
-
Page 2: Table Of Contents
6. STORAGE ………………………………………………… 7 7. OPTIONAL PARTS ………………………………………… 7 German : Bitte fragen Sie lhren Händler ● 8. ORDERING SERVICE PARTS …………………………… 7 nach eine Betriebsanleitung in 9. EXPLODED DIAGRAM: BB-20 ………………………… 8 Landessprache. French : S'il vous plait, veuillez demandez ● PICTOGRAM á... -
Page 3: Important Safety Instructions
IMPORTANT SAFETY BEFORE OPERATION INSTRUCTIONS Inspect tool before use. ● Before using, check that screws are securely When using the tool, please observe the safety tightened, that any protective cover or guard is precautions below to prevent possible accident or injury. securely in place, other parts are free from damage GENERAL: TOOLS and that the tool runs as it should. -
Page 4: General: Pneumatic Tools
Do not carry the tool by the air hose. becomes missing, contact the sales agent through Do not pull the air hose to disconnect. which you have purchased your tool or Nitto Kohki Co. Ltd, directly for a replacement. DISPOSAL... -
Page 5: Instructions For This Tool
Drained water, etc., if flown into the Tool, could Always use the genuine Abrasive Belt for the ● cause Tool failure. Install an Air Filter between the Belt Sander BB-20 (Nitto Kohki Co., Ltd.). Compressor and the Tool. 1. USAGE Air Regulator... -
Page 6: How To Operate The Tool
chips in the surroundings of the Drive Pulley 4 HOW TO OPERATE THE TOOL with an air blower. ① Press the Idle Pulley to Warning the direction shown with an arrow. ② Press the Push Button after Push Button replacing the Abrasive Belt. When sanding, always wear protective glasses ●... - Page 7 Protruding portion Caution Insert Do not hold the Throttle Lever when turning the ● Valve Body. Do not turn the Valve Body with the Shoe Offset Throttle Lever set to ON. Otherwise, it may cause Pull out Bracket Set the more heavily Dust Cover bent side of the shoe a trouble.
-
Page 8: Thread Size Of Hose Fitting
Caution When using the Abrasive Belt turning in R ● direction with a right hand or using it turning in direction L with a left hand, it may slip if a force is applied to a material from the top. When using it in these directions, keep pushing it forward. -
Page 9: Exploded Diagram
9. EXPLODED DIAGRAM: BB-20 Warning This diagram is for your reference only. Do not attempt to service or repair the Tool. Do not take the Tool apart. Contact an authorized Nitto dealer for all service and repair of the Tool. - Page 10 The parts numbers with ( ) are included in the Assʼy parts written above them. No. Parts No. Description Qty Price No. Parts No. Description Qty Price TB07105 Tension Bar Assʼy 1set TQ10519 Stop Ring O-22.2x1 (TB07106) Idle Pulley 20 Assʼy 1set TQ10516 Lock Ring...
- Page 12 Tel: (65)-6227-5360 Fax:(65)-6227-0192 http://www.nitto-kohki.co.jp/e/nksb/ NITTO KOHKI EUROPE Co., Ltd. Unit 21, Empire Centre, Imperial Way, NITTO KOHKI Co., Ltd. Shanghai Representative Office Watford Hertfordshire, WD24 4TS, United Kingdom #1117 Ruijing Building, Maoming South Road, Shanghai 200020 China Tel: (44)-01923-239668 Fax:(44)-01923-248815 http://www.nitto.co.uk/...
