Nitto Kohki Belton B-10CL Instruction Manual

PNEUMATIC BELT SANDER
Please read this manual carefully before you attempt to use
your tool so that you may use it properly and safely.
BELTON
PROFESSIONAL TOOL
B-10CL
Model
Maximum Operating Pressure
Air Consumption (No Load)
Rated Speed (No Load)
Standard Belt Size
Mass (Weight)
Sound Pressure Level [Uncertainty K] dB(A)
Sound Power Level [Uncertainty K]
Vibration Level [Uncertainty K]
Thread Size of Air Inlet
change without prior notice due to improvements we are making day in, day out.
Keep the manual handy – so you can use it whenever necessary.
Model B-10CL, B-20CL, B-30CL
B-20CL
B-10CL
MPa
m 3 /min 0.4
min -1 17000
10x330
mm
(25/64"x13") (25/32"x20-15/32")
kg 0.9
78 [ ≦ 2.0]
dB(A) 89 [ ≦ 2.0]
≦ 2.5
m/s 2
(1.2 [0.75] )
B-30CL
B-20CL B-30CL
0.6
0.48 0.82
18000 15000
20x520 30x540
(1-3/16"x21-17/64")
1.6 2.4
81 [ ≦ 2.0] 86 [ ≦ 2.0]
92 [ ≦ 2.0] 97 [ ≦ 2.0]
Grip: ≦ 2.5
(0.56 [0.17] )
≦ 2.5
(1.32 [0.19] )
Sub handle: ≦ 2.5
(1.88 [0.3] )
Rc 1/4
Manufactured by :
NITTO KOHKI Co., Ltd.
9-4, NAKAIKEGAMI
2-CHOME, OHTA-KU,
TOKYO, 146-8555, JAPAN
Tel : +81-3-3755-1111
Fax : +81-3-3753-8791
Original Instructions
