AXIS P1365-E Network Camera
Installation Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the P1365-E and is the answer not in the manual?

Questions and answers

Related Manuals for Axis P1365-E

Summary of Contents for Axis P1365-E

  • Page 1 AXIS P1365-E Network Camera Installation Guide...
  • Page 2 Low Voltage (LVD) Directive 2006/95/EC. See Safety Every care has been taken in the preparation of this on page 3 . document. Please inform your local Axis office of any • Restrictions of Hazardous Substances (RoHS) Directive inaccuracies or omissions. Axis Communications AB cannot 2011/65/EU.
  • Page 3 FAQ database. は、家庭環境で使用することを目 的としています Search by product, category, or phrase が、この装置がラジオやテレビジョン受信機に近 • report problems to Axis support staff by logging in to 接して使用されると、 受信障害を引き起こすこと your private support area があります。 取扱説明書に従って正しい取り扱い • chat with Axis support staff (selected countries only) をして下さい。...

  • Page 5: Hazard Levels

    AXIS P1365-E Network Camera Safety Information Read through this Installation Guide carefully before installing the product. Keep the Installation Guide for future reference. Hazard Levels DANGER Indicates a hazardous situation which, if not avoided, will result in death or serious injury.

  • Page 6: Safety Instructions

    Battery The Axis product uses a 3.0 V BR/CR2032 lithium battery as the power supply for its internal real-time clock (RTC). Under normal conditions this battery will last for a minimum of five years. Low battery power affects the operation of the RTC, causing it to reset at every power-up. When the battery needs replacing, a log message will appear in the product’s server report.
  • Page 7 WARNING • Risk of explosion if the battery is incorrectly replaced. • Replace only with an identical battery or a battery which is recommended by Axis. • Dispose of used batteries according to local regulations or the battery manufacturer's instructions.

  • Page 9: Installation Steps

    Installation Guide This Installation Guide provides instructions for installing AXIS P1365–E Network Camera on your network. For other aspects of using the product, see the User Manual available at www.axis.com Installation Steps 1. Make sure the package contents, tools and other materials necessary for the installation are in order.

  • Page 10: Hardware Overview

    AXIS P1365-E Network Camera Hardware Overview Status LED Built-in microphone Focus puller Zoom puller microSD card slot Audio in Audio out Network connector (PoE) Power LED 10 Network LED 11 Control button 12 I/O connector 13 Iris connector 14 Power connector (not used)
  • Page 11 Status LED indicator Network connector (PoE IN) Heater cable Cable gasket M20 (2x) Drill-out (2x) Slot for intrusion alarm switch – supports AXIS Door Switch A (sold separately) 10 Holder screw T20 (2x) 11 Camera screw T20 12 Pin 13 Holder...

  • Page 12: Wall Mount

    AXIS P1365-E Network Camera Wall Mount Network cable (route through wall bracket) Screw T20 (4x) Bracket adjustment screw T30 Wall bracket LED Indicators Note • The Status LED can be configured to be unlit during normal operation. To configure, go to Setup >...

  • Page 13: Led Indicators (Axis T93F10, Axis T93F20)

    Single flash: Heater error Double flash: Fan error Triple flash: General error Alarm events will be triggered through the camera’s input port. Contact your Axis reseller for information about spare parts and troubleshooting. LED Indicators (AXIS T93F10, AXIS T93F20) Indication...

  • Page 14: Status Led Behavior For Focus Assistant

    AXIS P1365-E Network Camera Status LED Behavior for Focus Assistant Color Indication Green Focus Assistant is enabled The lens is optimally adjusted Amber The camera has been moved, or an object has been inserted in front of the lens. Exit and restart the Focus Assistant.
  • Page 15 Set up an action rule in the camera to configure which action the signal shall trigger. For information about events and action rules, see the User Manual available on www.axis.com Audio Connector The Axis product has the following audio connectors: •...

  • Page 16: Specifications

    AXIS P1365-E Network Camera • Connecting to an AXIS Video Hosting System service or AXIS Internet Dynamic DNS Service. For more information about these services, see the User Manual. Specifications Operating Conditions The Axis product is intended for indoor use.
  • Page 17 AXIS P1365-E Network Camera Function Notes Specifications 0 V DC 0 V DC (-) DC output Can be used to power auxiliary equipment. 12 V D C Note: This pin can only be used as power out. Max load = 50 mA 3–...
  • Page 18 The recommended maximum cable length is 30 m (98.4 ft). SD Card Slot The Axis product supports microSD cards with up to 64 GB of storage. For best recording performance, use ultra-high speed microSD cards (microSDHC UHS-I or microSDXC UHS-I).

  • Page 19: Cable Area

    • Be careful not to scratch, damage or leave fingerprints on the window because this could decrease image quality. The Axis product can be installed with the cables routed through or along the wall. Read all the instructions before installing the product: 1.

  • Page 20: Install The Wall Mount

    AXIS P1365-E Network Camera Install the Wall Mount CAUTION Make sure that the screws and plugs are appropriate for the material (e.g. wood, metal, drywall, stone) and that the material is strong enough to support the combined weight of the camera, housing, and wall mount.
  • Page 21 AXIS P1365-E Network Camera Bottom cover Bottom cover screw T20 (4x) Cable gasket M20 (2x) 3. Push the network cable through the cable gasket. NO TICE TICE TICE If the network cable has a premounted network connector, remove the cable gasket and use the connector guard to prevent tearing of the cable gasket.
  • Page 22 AXIS P1365-E Network Camera 5. Make sure that the cable gasket is fitted properly. 6. If connecting an auxiliary device, for example an I/O, audio, or external power device, to the camera, repeat the steps above as applicable to the specific device.
  • Page 23 AXIS P1365-E Network Camera Screw T20 (4x) Wall bracket Bracket adjustment screw T30 Install the Camera in the Housing 1. Loosen the holder screws, then slide and lift the holder, see illustration below. 2. Attach the holder to the camera. Align the pin and camera screw with the pin hole and screw mount on the camera and tighten the camera screw (torque 1 Nm).
  • Page 24 AXIS P1365-E Network Camera Holder screw T20 (2x) Holder Position A (overlap) : +3.7 mm (+0.15 in) Position B (gap) : -6 mm to -4 mm (-0.24 in to -0.16 in) NO TICE TICE TICE • Position A: To avoid reflections in the image, adjust the holder’s position so that the camera lens edge overlaps the bottom cover edge by +3.7 mm (+0.15 in).
  • Page 25 AXIS P1365-E Network Camera Network connector (PoE OUT) Network connector (PoE IN) 8. Make sure that the camera and housing LEDs indicates the correct condition. See LED Indicators. 9. Loosen the bracket adjustment screw to aim the camera to the point of interest. For information about how to view the video stream, see Access the Product 10.

  • Page 26: Access The Product

    AXIS P1365-E Network Camera 12. If using a sunshield (sold separately), place it over the top cover, adjust its position and tighten the screws. Access the Product Use the tools provided on the Installation and Management Software CD to assign an IP address, set the password and access the video stream.

  • Page 27: Focus Assistant

    AXIS P1365-E Network Camera Focus Assistant Note • The view in front of the camera should not be changed during focus adjustment (steps 5 and 6). If the camera is moved, or if a finger or other object is placed in front of the lens, steps 3 - 7 will have to be repeated.

  • Page 28: Further Information

    Further Information The User Manual is available at www.axis.com Visit www.axis.com/techsup to check if there is updated firmware available for your network product. To see the currently installed firmware version, go to Setup > About. Visit Axis learning center www.axis.com/academy for useful trainings, webinars, tutorials and guides.
  • Page 30 Installation Guide Ver. M1.5 AXIS P1365-E Network Camera Date: February 2015 © Axis Communications AB, 2015 Part No. 60564...
