Master-force 241-0401 Operator's Manual
  1. Manuals
  2. Brands
  3. Master-force Manuals
  4. Drill
  5. 241-0401
  6. Operator's manual

Master-force 241-0401 Operator's Manual

High-performance 1/2" drill/driver
Hide thumbs

Advertisement

Quick Links

High-Performance 1/2" Drill/Driver
241-0401
OPERATOR'S MANUAL
CAUTION: To Reduce The Risk Of Injury, User Must
Read And Understand Operator's Manual. Save These
Instructions For Future Reference.
For questions / comments, technical assistance or repair parts –
Please Call Toll Free: 1-866-917-4374. (M-F 8am – 6pm EST.)

Advertisement

loading
Need help?

Need help?

Do you have a question about the 241-0401 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Master-force 241-0401

Summary of Contents for Master-force 241-0401

  • Page 1 High-Performance 1/2" Drill/Driver 241-0401 OPERATOR’S MANUAL CAUTION: To Reduce The Risk Of Injury, User Must Read And Understand Operator’s Manual. Save These Instructions For Future Reference. For questions / comments, technical assistance or repair parts – Please Call Toll Free: 1-866-917-4374. (M-F 8am – 6pm EST.)

  • Page 2: Table Of Contents

    TAbLE OF CONTENTS SAFETy SyMbOLS Some of these following symbols may be used on this tool. Please study them and learn their Safety Symbols ............Page 2 meaning.

  • Page 3: Safety Instructions

    SAFETy INSTRUCTIONS SAFETy INSTRUCTIONS The purpose of safety symbols is to attract your attention to possible dangers. The safety 4. Do not abuse the cord. Never use the WARNING: Read all safety symbols and the explanations with them deserve your careful attention and understanding. cord for carrying, pulling or unplugging the warnings and instructions! The symbol warnings do not, by themselves, eliminate any danger.
  • Page 4 SAFETy INSTRUCTIONS SAFETy INSTRUCTIONS SPECIFIC SAFETy RULES FOR 6. Dress properly. Do not wear loose 7. Use the power tool, accessories, 8. Always set the direction-of-rotation clothing or jewelry. Keep your hair, clothing tool bits etc., in accordance with these switch to the center (locked) position CORDLESS DRILL/DRIVER and gloves away from moving parts.

  • Page 5: Assembly

    ASSEMbLy SAFETy INSTRUCTIONS UNPACkING • Lead from lead-based paints Your risk from these exposures varies, WARNING: If any part is broken • Crystalline silica from bricks and cement depending on how often you do this type or missing, DO NOT attempt to attach the and other masonry products, and of work.

  • Page 6: Operation

    OPERATION OPERATION TO ATTACH bATTERy PACk ELECTRIC bRAkE 3. Pull forward on the battery pack to The direction of rotation of the bit is remove it from the drill/driver. reversible and is controlled with a selector (FIG. 2) located above the trigger switch. With the To stop the tool, release the trigger switch drill/driver held in normal operating position: TRIGGER SWITCH (FIG.
  • Page 7 OPERATION OPERATION kEyLESS CHUCk (FIG. 7) TWO-SPEED GEAR bOX (FIG. 9) INSTALLING A bIT (FIG. 11A) ADJUSTAbLE TORQUE CLUTCH (FIG. 10) Release Release FIG.11a FIG. 7 FIG. 9 Slide Switch FIG.10 Arrow Keyless Keyless Chuck Chuck Grip Grip Torque-Adjustment ring The arrows on the chuck indicate the 1.
  • Page 8 OPERATION OPERATION REMOVING A bIT (FIG. 11b) DRILLING MODE OPERATION SCREWDRIVER OPERATION 1. Check the direction-of-rotation selector for the correct setting (forward or FIG.11b reverse). For drilling in wood, use twist bits, spade 1. Select the desired speed/torque range 2. Use a vise or clamps to secure the bits, power auger bits or hole saws.

  • Page 9: Maintenance

    MAINTENANCE TROUbLESHOOTING Periodic maintenance of your shear allows WARNING: PRObLEM CAUSE SOLUTION To avoid serious for long life and trouble-free operation. personal injury, always disconnect The drill/driver does not work Battery is depleted Charge the battery A cleaning, lubrication and maintenance the plug from the power source when schedule should be maintained.

  • Page 10: Warranty

    NOTES High-Performance 1/2” Drill/Driver WARRANTy 90-DAy MONEy bACk GUARANTEE: This MASTERFORCE® brand power tool carries our 90-DAY Money Back Guarantee. If you are not completely satisfied with your MASTERFORCE® brand power tool for any reason within ninety (90) days from the date of purchase, return the tool with your original receipt to any MENARDS®...
  • Page 11 © 2014 Menard, Inc., Eau Claire, WI 54703 09/2014...
