Master-force Flexpower 241-0436 Operator's Manual

20 volt right angle drill
Hide thumbs Also See for Flexpower 241-0436:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Operator's Manual
20 Volt Right Angle Drill
241-0436
OPERATOR'S MANUAL
CAUTION:
To Reduce The Risk Of Injury, User Must Read And
Understand The Operator's Manual. Save These Instructions For
Future Reference.
For questions / comments, technical assistance or repair parts –
Please Call Toll Free: 1-866-917-4374. (M-F 8am – 6pm EST.)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Flexpower 241-0436 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Master-force Flexpower 241-0436

Summary of Contents for Master-force Flexpower 241-0436

  • Page 1 20 Volt Right Angle Drill 241-0436 OPERATOR’S MANUAL CAUTION: To Reduce The Risk Of Injury, User Must Read And Understand The Operator’s Manual. Save These Instructions For Future Reference. For questions / comments, technical assistance or repair parts – Please Call Toll Free: 1-866-917-4374. (M-F 8am – 6pm EST.)

  • Page 2: Table Of Contents

    TAbLE Of CONTENTS Safety Symbols ............Page 2 Safety Instructions .

  • Page 3: Safety Symbols

    SAfETy SyMbOLS Some of these following symbols may be used on this tool. Please study them and learn their meaning. Proper interpretation of these symbols will allow you to operate the tool better and more safely. Symbol Designation / Explanation Name Volts Voltage...

  • Page 4: Safety Instructions

    SAfETy INSTRUCTIONS The purpose of safety symbols is to attract your attention to possible dangers. The safety symbols and the explanations with them deserve your careful attention and understanding. The symbol warnings do not, by themselves, eliminate any danger. The instructions and warnings they give are no substitutes for proper accident prevention measures.

  • Page 5: Personal Safety

    SAfETy INSTRUCTIONS 3. Do not expose power tools to WARNING: Read all safety rain or wet conditions. Water entering warnings and instructions.Failure to a power tool will increase the risk of follow the warnings and instructions electric shock. may result in electric shock, fire and / or 4.
  • Page 6 SAfETy INSTRUCTIONS 4. Remove any adjusting key or wrench 5. Maintain power tools. Check before turning the power tool on. A wrench misalignment or binding of moving parts, or a key left attached to a rotating part of the breakage of parts and any other condition power tool may result in personal injury.
  • Page 7 SAfETy INSTRUCTIONS SERVICE 5. Always wear safety glasses with side shields. Everyday glasses have only impact resistant lenses. They are NOT safety 1. Have your power tool serviced by a glasses. Following this rule will reduce the qualified repair person using only identical risk of eye injury.

  • Page 8: Overview / Specifications

    OVERVIEW Keyless chuck LED Worklight Vents Direction of Rotation Selector Variable speed (Forward/Center trigger Switch Lock/ Reverse) Bit storage SPECIfICATIONS PRODUCT SPECIfICATIONS Switch VSR (Variable Speed Reversible) No Load Speed 0-1050 RPM Chuck 3/8” single sleeve Max.torque 150 in. lbs. Drill Weight (without battery) 2 lbs.

  • Page 9: Assembly

    ASSEMbLy VARIAbLE SPEED WARNING: If any part is broken or missing, do not attempt to plug in the power variable-speed trigger switch cord or operate the tool until the broken or delivers higher speed with increased missing part is replaced. failure to do so pressure and lower speed with decreased could result in possible serious injury.

  • Page 10: Operation

    OPERATION TO ATTACH bATTERy CAUTION: when placing battery PACk (fIG. 1) pack on the tool, be sure that the raised rib on battery pack aligns with the groove on the saw and the latches snap into FIG. 1 place properly. Improper assembly of the battery pack can cause damage to internal components.
  • Page 11 OPERATION DIRECTION-Of-ROTATION kEyLESS CHUCk (fIG. 3) SELECTOR (fORWARD/CENTER LOCk/REVERSE) (fIG. 2b) FIG. 3 UNLOCK (Release) FIG. 2b LOCK (Tighten) REVERSE FORWARD WARNING: Do not hold the chuck with one hand and use the power of the drill The direction of rotation is reversible and is to tighten the chuck jaws on the drill bit.
  • Page 12 OPERATION 2. To loosen the chuck jaw: grasp and hold The LED worklight, located on the front the tool with one hand, while rotating the of the Drill, will illuminate when the chuck with your other hand. trigger switch is depressed. This provides NOTICE: Rotating the chuck in the direction additional light on the surface of the work- of the arrow marked UNLOCK to loosen the...

  • Page 13: Maintenance

    OPERATION DRILLING (fIG. 7) Move the drill bit into the workpiece applying only enough pressure to keep the bit cutting. Do not force or apply side FIG. 7 pressure to elongate a hole. WARNING: be prepared for binding at bit breakthrough. When these situations occur, drill has a tendency to grab and kick opposite to the direction of rotation and could cause loss of control when breaking...

  • Page 14: Troubleshooting

    CHUCk REMOVAL (fIG. 8 & 9) 2. Insert a 5/16 in. hex key into the chuck of the drill and tighten the chuck jaws securely. 3. Tap the hex key sharply with a mallet in FIG. 8 a clockwise direction. This will loosen the screw in the chuck for easy removal.

  • Page 15: Warranty

    ® workmanship within three (3) years from the date of original purchase, simply bring this tool with the original sales receipt back to your nearest MENARDS retail store. ®...
  • Page 16 © 2013 Menard, Inc., Eau Claire, WI 54703 06/2013 Page 15...
