241-0436

OPERATOR'S MANUAL

CAUTION: To Reduce The Risk Of Injury, User Must

Read And Understand Operator's Manual. Save These

Instructions For Future Reference.

For questions / comments, technical assistance or repair parts –

Please Call Toll Free: 1-866-917-4374. (M-F 8am – 6pm EST.)

Page 1

Table of Contents

Need help?

Do you have a question about the 241-0436 and is the answer not in the manual?

Questions and answers

Summary of Contents for Master-force 241-0436

Page 1 Right Angle Drill 241-0436 OPERATOR’S MANUAL CAUTION: To Reduce The Risk Of Injury, User Must Read And Understand Operator’s Manual. Save These Instructions For Future Reference. For questions / comments, technical assistance or repair parts – Please Call Toll Free: 1-866-917-4374. (M-F 8am – 6pm EST.)
Page 2: Table Of Contents
TABLE OF CONTENTS Safety Symbols ............Page 2 Safety Instructions .
Page 3: Safety Symbols
SAFETY SYMBOLS Some of these following symbols may be used on this tool. Please study them and learn their meaning. Proper interpretation of these symbols will allow you to operate the tool better and more safely. Symbol Designation / Explanation Name Volts Voltage...
Page 4 SAFETY INSTRUCTIONS The purpose of safety symbols is to attract your attention to possible dangers. The safety symbols and the explanations with them deserve your careful attention and understanding. The symbol warnings do not, by themselves, eliminate any danger. The instructions and warnings they give are no substitutes for proper accident prevention measures.
Page 5: Safety Instructions
SAFETY INSTRUCTIONS 4. Do not abuse the cord. Never use the WARNING: Read all safety cord for carrying, pulling or unplugging the warnings and instructions.Failure to follow power tool. Keep the cord away from heat, the warnings and instructions may result in oil, sharp edges or moving parts.
Page 6 SAFETY INSTRUCTIONS 4. Remove any adjusting key or wrench 5. Maintain power tools. Check before turning the power tool on. A wrench misalignment or binding of moving parts, or a key left attached to a rotating part of the breakage of parts and any other condition power tool may result in personal injury.
Page 7 SAFETY INSTRUCTIONS SERVICE 7. Protect your hearing. Wear hearing protection during extended periods of operation. Following this rule will reduce the 1. Have your power tool serviced by a risk of serious personal injury. qualified repair person using only identical 8.
Page 8: Overview/Specifications
OVERVIEW Keyless chuck LED Worklight Vents Direction of Rotation Selector Variable speed (Forward/Center trigger Switch Lock/ Reverse) Bit storage SPECIFICATIONS Switch VSR (Variable Speed Reversible) No Load Speed 0-1050 RPM Chuck 3/8" single sleeve Max.torque 150 in. lbs. Drill Weight (without battery) 2 lbs.
Page 9 OVERVIEW VARIABLE SPEED LED WORK LIGHT variable-speed trigger switch Pressing the trigger switch illuminates the delivers higher speed with increased LED worklight, located on the front of the pressure and lower speed with decreased Right Angle Drill. This feature provides extra trigger pressure.
Page 10: Assembly
ASSEMBLY UNPACKING WARNING: If any part is broken or missing, do not attempt to plug in the power This product has been shipped completely cord or operate the tool until the broken assembled. or missing part is replaced. Failure to do 1.
Page 11 OPERATION DIRECTION-OF-ROTATION WARNING: when placing battery SELECTOR (FORWARD/CENTER pack on the tool, be sure that the raised LOCK/REVERSE) (FIG. 2B) rib on battery pack aligns with the groove on the saw and the latches snap into place properly. Improper assembly of FIG.
Page 12 OPERATION LED WORKLIGHT (FIG. 4) NOTICE: This drill has an electric brake. When the trigger switch is released, the chuck stops turning. When the brake is FIG. 4 functioning properly, sparks will be visible through the vent slots on the housing. This is normal and is the action of the brake.
Page 13 OPERATION BIT STORAGE (FIG. 6) 3. Insert the drill bit straight into the chuck the full length of the jaws. 4. To tighten: grasp and hold the tool with one hand, while rotating the chuck with FIG. 6 your other hand. NOTICE: Rotate the chuck in the direction of the arrow marked LOCK to tighten the chuck jaws.
Page 14: Maintenance
OPERATION Move the drill bit into the workpiece, When drilling metals, use light oil on the drill applying only enough pressure to keep bit to keep it from overheating. The oil will the bit cutting. Do not force or apply side prolong the life of the bit and increase the pressure to elongate a hole.
Page 15: Troubleshooting
MAINTENANCE To remove the chuck: To retighten a loose chuck 1. Remove the battery. The chuck may become loose on the spindle 2. Lock the trigger switch by placing the and develop a wobble. Periodically check direction of rotation selector in the the chuck screw for tightness.
Page 16 NOTES Page 15...
Page 17 NOTES Page 16...
Page 18 NOTES Page 17...
Page 19: Warranty
RIGHT ANGLE DRILL WARRANTY 90-DAY MONEY BACK GUARANTEE: This MASTERFORCE® brand power tool carries our 90-DAY Money Back Guarantee. If you are not completely satisfied with your MASTERFORCE® brand power tool for any reason within ninety (90) days from the date of purchase, return the tool with your original receipt to any MENARDS®...
