Page 1
Operator’s Manual 12.0-Volt Lithium-Ion Right Angle Drill 241-0301 CHARGE BATTERY BEFORE FIRST USE IMPORTANT WARNING! To reduce the risk of injury, user must read instruction manual. Safety symbols in this manual are used to flag possible dangers. The safety symbols and their explanations require your full understanding.
Page 2
TABLE OF CONTENTS Safety Symbols page 3 Safety Instructions page 4-9 Description page 9-10 Assembly page 10-11 Operation page 12-14 Maintenance page 15 Troubleshooting page 15 Warranty Page 16 INTRODUCTION SAVE THESE INSTRUCIONS! This right angle drill has many features for making its use more pleasant and enjoyable. Safety, performance, and dependability have been given top priority in the design of this product making it easy to maintain and operate.
Page 3
WARNING: The operation of any power tool can result in foreign objects being thrown into your eyes, which can result in severe eye damage. Before beginning power tool operation, always wear safety goggles or safety glasses with side shields and a full-face shield when needed. We recommend a Wide Vision Safety Mask for use over eyeglasses or standard safety glasses with side shields.
SAFETY INSTRUCTIONS GENRAL SAFETY RULES WARNING: Read all safety warnings and instructions. Failure to follow the warnings and instructions may result in electric shock, fire and / or serious injury. Save all warnings and instructions for future reference. The term power tool in the warnings refers to your mains-operated (corded) power tool or battery-operated (cordless) power tool.
Page 6
U se personal protective equipment. Always wear eye protection. Protective equipment such as dust √ √ √ √ mask, non-skid safety shoes, hard hat, or hearing protection used for appropriate conditions will reduce personal injuries. P revent unintentional starting. Ensure the switch is in the off-position before connecting to power √...
Page 7
into account the working conditions and the work to be performed. Use of the power tool for operations different from those intended could result in a hazardous situation. 5) BATTERY TOOL USE AND CARE R echarge only with the charger specified by the manufacturer. A charger that is suitable for one type √...
Page 8
K eep your hands away from the motor-housing vents. Hot gas comes from the vents during operation. √ √ √ √ I f the bit becomes bound in the workpiece, release the trigger immediately, reverse the direction of √ √ √ √ rotation and slowly squeeze the trigger to back out the bit.
Page 9
A n extension cord should not be used unless absolutely necessary. Use of an improper extension cord √ √ √ √ could result in a risk of fire and electric shock. If an extension cord must be used, make sure that: The pins on plug of extension cord are the same number, size and shape as those of the plug on charger.
Page 10
Fig.1 LED worklight Hexagonal chuck Locking Sleeve Direction-of-rotation selector Variable-speed trigger switch Battery pack PRODUCT SPECIFICATION Motor 12 Volt DC Switch VSR (Variable Speed Reversible) No Load Speed 0-600 RPM Chuck 1/4" (6.35mm) Max torque 90 in/lbs Charging time 30 Min Drill Weight (Without battery) 1 lbs 6oz Battery Type...
Page 11
decreased trigger pressure. FORWARD/REVERSE/CENTER LOCK The angle drill has a direction of rotation selector located above the trigger switch for changing the direction of bit rotation. Setting the trigger switch in the OFF (center lock) position helps reduce the possibility of accidental starting when not in use.
Page 12
When the battery pack is very cold, it may “pulse” for the first minute of use to warm itself. Put the battery pack on a tool and use the tool in a light application. After about a minute, the battery pack will have warmed itself and will operate normally.
Page 13
CHARGING A HOT BATTERY PACK If the battery pack is above normal temperature range, the red LED will illuminate and the green LED will be off. When the battery pack cools down to approximately 104° F (40° C), the charger will automatically begin charging.
Page 14
Improper assembly of the battery pack can cause damage to internal components. TRIGGER SWITCH (Fig. 5a) Fig.5 To turn the tool ON, depress the trigger switch. To turn it OFF, release the trigger. VARIABLE SPEED (Fig.5a) Variable- Direction-of The variable speed trigger switch delivers higher speed with increased speed -rotation trigger pressure and lower speed with decreased trigger pressure.
Page 15
INSTALLING BITS (Fig. 7) Fig.7 Lock the trigger switch by placing the direction of rotation selector in the OFF (center) position. With one hand, pull the sleeve toward the front of the tool, and hold it in place. With the other hand, insert the 1/4-in. bit into the hexagonal chuck.
Page 16
WARNING! When servicing, use only identical replacement parts. Use of any other parts may create a hazard or cause product damage. WARNING! Always wear safety goggles or safety glasses with side shields during power tool operation or when blowing dust. If operation is dusty, also wear a dust mask. WARNING! To avoid personal injury, always remove the battery pack from the tool when cleaning or performing any maintenance.
Every six months of storage, fully charge the Lithium-Ion battery pack. √ √ √ √ Exterior may be cleaned with a cloth or soft non-metallic brush. √ √ √ √ BATTERY PACK REMOVAL AND PREPARATION FOR RECYCLING To preserve natural resources, please recycle or dispose of batteries properly. This product contains lithium-ion batteries.
Page 18
any defects as provided herein, as long as the seller is willing or able to replace this product or is willing to refund the purchase price as provided above. For insurance purposes, seller is not allowed to demonstrate any of these power tools for you. For questions / comments, technical assistance or repair parts –...
