The NX-1750 ProxPad is the combination of a proximity card reader and a keypad. The NX-
1750 ProxPad allows to control an access door and to show the system status. The NX-1750
ProxPad can be added to the NetworX range of panels. The NX-1750 features include:
•
•
•
•
•
•
•
•
•
•
•
•
•
•
For detailed ordering information and part numbers, please refer to the EMEA Distribution
price list of the Caddx product range.
NX-1750 Installation manual
GENERAL DESCRIPTION
microprocessor controlled door control module
includes a flexible programmable changeover relay contact output, which can be used to
control a door strike
treated as a normal keypad
up to 8 readers per partition
can be programmed to control access in any or all partitions
up to 3 scan functions (single beep, double beep and triple beep)
LED's for indication of armed status, ready to arm status and alarm
LED's for up to 8 zones status indication
Fire alarm LED
Spare terminal to support easy wiring of a door contact to the panel zone input
Compatible with TAG1750 series of tags
Tamper protection against opening and pry off.
Wall or recess mounting, fits a standard electrical box.
Removable screw terminals for easy wiring.
ORDERING INFORMATION
Page 4
18/02/05
