Technical Specifications - Danfoss Link FT Installation Manual

Installation Guide

Technical specifications

Operation voltage
Standby consumption
Relay:
• Resistive load
• Inductive load
Sensing unit
Sensing values:
• 0°C
• 20°C
• 50°C
Regulation
Ambient temperature
Sensor failure
monitoring
Transmission
frequency
Transmission range
Transmission power
IP class
Dimensions
VISGZ45X
Danfoss Link™ FT
180-250 VAC, 50/60 Hz
Max . 1 W
230 V ~ 15 A / 3450 W
cos φ = 0 .3 Max . 1 A
NTC 15 kOhm at 25°C
42 kOhm
18 kOhm
6 kOhm
PWM
-10° to +30°C
The thermostat has a built-in
monitoring circuit, which will
switch off the heating if the
sensor is disconnected or short-
circuited
868 .42 MHz
Up to 30 m (in normal buildings)
Max . 1 mW
31
85 mm × 85 mm × 21 mm
© Danfoss 04/2011
GB
11
