W E B E D I T I O N

O W N E R ' S M A N U A L

Table of Contents

Advertisement

Table of Contents

Need help?

Need help?

Do you have a question about the XC60 and is the answer not in the manual?

Questions and answers

Summary of Contents for Volvo XC60

Page 1 W E B E D I T I O N O W N E R ' S M A N U A L...
Page 3 Volvo is one of the safest cars in mation contained in this owner's manual. the world. Your Volvo has also been designed to satisfy all current safety and environmental requirements.
Page 4: Table Of Contents
Seatbelt tensioner........29 Two-stage booster seat* - raising..... 51 the Internet..........20 Safety - warning symbol......29 Two-stage booster seat* - lowering..52 Volvo ID............. 21 Airbag system........... 30 Child seat - ISOFIX........53 Environmental philosophy......22 Driver airbag..........31 ISOFIX - size classes........
Page 5 Approach lighting........100 Trip computer - trip statistics*....126 Symbols in the display......76 Headlamps - adjusting headlamp pat- tern............100 Volvo Sensus..........79 Wipers and washers....... 101 Key positions..........80 Power windows........103 Key positions - functions at different lev- els..............
Page 6 Table of contents 04 Climate control 05 Loading and storage General information on climate control... 128 Engine block heater and passenger com- Storage spaces........151 partment heater*........142 Actual temperature......... 129 Tunnel console........153 Engine block heater and passenger com- Sensors - climate control......
Page 7 Table of contents 06 Locks and alarm 07 Driver support Remote control key......... 163 Keyless drive* - locking......174 Active chassis - Four C*......189 Remote control key - losing ....163 Keyless drive* - unlocking....... 175 Adjustable steering force*....... 189 Remote control key - personalisation*..
Page 8 Table of contents Adaptive cruise control* - temporary Collision warning system*....... 224 Park Assist*..........241 deactivation, and standby mode.... 205 Collision warning system* - function..225 Park assist syst* - function..... 241 Adaptive cruise control* - overtaking Collision warning system* - detection of Park assist syst* - backward....
Page 9 Table of contents 08 Starting and driving Alcohol lock*........... 255 Start/Stop*..........276 Fuel filler flap - manual opening....297 Alcohol lock* - functions and operation.. 255 Start/Stop* - function and operation..277 Filling up with fuel........297 Alcohol lock* - storage......256 Start/Stop* - the engine does not stop...
Page 10 09 Wheels and tyres 10 Maintenance and service Tyres - maintenance....... 315 Tyre pressure monitoring (TPMS)* - rec- Volvo service programme....... 348 ommendations........330 Tyres - direction of rotation....316 Book service and repair*......348 Tyre pressure monitoring (TPMS)* - driv- Tyres - tread wear indicators....
Page 11 Table of contents 11 Specifications Lamp replacement - number plate light- Rustproofing........... 395 Type designations........399 ing............367 Cleaning the interior........ 395 Dimensions..........402 Lamp replacement - lighting in cargo Paint damage.......... 396 Weights........... 403 area............367 Towing capacity and towball load..404 Lamp replacement - vanity mirror light- Engine specifications......
Page 12 Table of contents 12 Alphabetical Index Alphabetical Index........422...
Page 13 Table of contents...
Page 14 I N T R O D U C T I O N...
Page 15: 01 Introduction
For cars with owner information in the screen, with Volvo's recommendations in the advice on how best to handle the car in differ- the printed owner's manual is a supplement owner's information.
Page 16 Media Sending location In the event of uncertainty over what is stand- Decals ard or an option/accessory, contact a Volvo The car contains different types of decal dealer. which are designed to convey important information in a simple and clear manner. The...
Page 17 01 Introduction Risk of property damage Information When there is a series of illustrations for step-by-step instructions each step is numbered in the same way as the corres- ponding illustration. Lists of letters appear adjacent to the ser- ies of illustrations where the order of the instructions is not significant.
Page 18: Digital Owner's Manual In The Car
01 Introduction • Digital owner's manual in the car Related information Search - Search function for finding an article. Related information refers to other articles The owner's manual can be read on the • containing closely-associated information. Categories - All articles sorted into cate- screen in the car .
Page 19 01 Introduction Search Enter with the numerical keyboard 3. To change the input mode to numbers or special characters, or to perform a search, turn TUNE to one of the options (see explanation in the following table) in the list for changing the input mode (2), press OK/MENU.
Page 20: Recording Data
OK/MENU to open an article. ing and maintenance and so that Volvo can Press EXIT to go back to the previous view. Favourite - adds/removes an article as a fulfil legal requirements and other regulations.
Page 21: Accessories And Extra Equipment
This information may be stored by tively affect the car's electronic system. Volvo as long as it can help to further develop Certain accessories only function when asso- and further enhance safety and quality and as...
Page 22: Support And Information About The Car On The Internet
My Volvo Web which is a the Internet via a mobile phone. personal Web page for you and your car. Create a personal Volvo ID, log in to My Volvo Web and get an overview of service, agree- Applies to certain markets.
Page 23: Volvo Id
(e.g. My Volvo) Create a Volvo ID To create a Volvo ID you need to enter a per- sonal e-mail address. Then follow the instruc- tions in the e-mail message that is automati- cally sent to the specified address in order to complete the registration.
Page 24: Environmental Philosophy
Clean air in the passenger Environmental care is one of Volvo Cars' core fuel consumption generally results in lower values, which influence all operations. We emission of the greenhouse gas, carbon diox-...
Page 25 Warranty Booklet's recommended inter- Interior facility. vals. The interior of a Volvo is designed to be plea- • If the car is equipped with an engine Related information sant and comfortable, even for people with block heater*, use it before starting from •...
Page 26: The Owner's Manual And The Environment
01 Introduction The owner's manual and the Laminated glass environment The windscreen and panorama roof The paper pulp in a printed owner's manual have laminated glass. It is reinforced ® comes from Forest Stewardship Council cer- which provides better protection tified forests or other controlled sources.
