VOLVO XC60

Wiring diagram

2010
TP 39153201

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the XC60 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Volvo XC60

Summary of Contents for Volvo XC60

  • Page 1: Wiring Diagram

    VOLVO XC60 Wiring diagram 2010 TP 39153201...

  • Page 2: Vehicles With Srs (Airbag)/Sips Bag/Ic

    2. Damage or malfunction of the SRS/SIPS bag/IC system. Work involving the SRS/SIPS bag/IC systems or other components in the vehicle that may affect the SRS/SIPS bag/IC systems must always be performed by an authorized Volvo workshop. In case of doubt, consult the SRS and SIPS bag/IC service manual.

  • Page 3: Table Of Contents

    Horn ................85 Steering Wheel Module (SWM) ........46 Keyless vehicle 1:2 ............86 Anti-theft alarm ............88 Parking assistance............89 Collision warning with power brake booster....90 Tire pressure monitoring system (TPMS) ....91 Alcohol lock..............92 TP39153201 XC60 2010...
  • Page 4 Group 88 Internal equipment Speed dependent power steering......119 Rear-view mirror with automatic dimming....149 Supplemental restraint system 1:2......150 Remote controlled garage opening......152 Group 76 Shock absorbers Four-C................ 120 Index 1:2 ............153 List of components 1:5 ......155 TP39153201 XC60 2010...

  • Page 5: Explanations

    = Pink = Israel RD, R = Red = Japan VT, VO = Violet = Korea WH, W = White = Norway YE, Y = Yellow = Netherlands = Sweden = United States of America = Western Europe TP39153201 XC60 2010...

  • Page 6: How To Use The Wiring Diagrams 1:2

    Fuse Electrical distribution rail/box G. Component location Audio The end of the manual contains a section that Service/diagnostics describes component appearance and location in Contact reel numerical order. Meter Ignition component/shunt Optics Ground connection Branching point Connector TP39153201 XC60 2010...

  • Page 7: How To Use Wiring Diagrams 2:2

    = DIN cable, coaxial cable, etc. = Data communication = CAN communication = MOST communication = MOST communication = Connection with distribution box = Further connection to... = Connector between cable harnesses = Connector connected in component TP39153201 XC60 2010...

  • Page 8: Electrical Distribution 1:2

    RD-BK 11A/1 2/22 4/56C5:1 RD_BU 11A/2 4/56C5:2 RD-GN 11A/3 15/32 RD-GY 11A/4 15/32 RD-BN 11A/5 15/32 11A/6 4/46B:16 2/193 RD-GY VT-GN 4/56C1:48 11B/14 11B/13 11B/11 11B/9 11B/15 11B/12 11B/10 11B/24 11B/8 11B/25 11B/26 31/3 C1:1 C1:1 73/3076 TP39153201 XC60 2010...
  • Page 9 11D/B9 RD-GN 73/5075 11D/A9 11D/B10 11D/A10 RD-GY RD-GN 11D/B11 11D/A11 RD-GY RD-GN 11D/B12 11D/A12 2/16 RD-GY 2/88 2/82 YE-VT RD-GY RD-VT BU-RD 11D/D1 11D/D2 11D/D3 11D/D4 74/505 11D/D5 11D/D6 11D/D7 11D/D8 11D/D9 11D/D10 11D/D11 11D/D12 BU-RD RD-BN TP39153201 XC60 2010...

  • Page 10: Fuses

    Fuses in cargo compartment fuse box 11A/4 2/88 Relay, 15-feed rear 11D/B1-11D/B8 Fuses in cargo compartment fuse box 2/88 11D/B9-11D/B12 Fuses in cargo compartment fuse box 11A/5 11D/D1-11D/D7 Fuses in cargo compartment fuse box 11A/7 9/42 PTC-element continues TP39153201 XC60 2010...

  • Page 11: Distribution Box In Engine Compartment F9-F24

    4/28 Transmission control module (TCM) 4/46 Engine control module (ECM) 11B/21 9/43 Heated windshield washer nozzle, left 9/44 Heated windshield washer nozzle, right 11B/23 3/111 Light switch module (LSM) 11B/24 6/104 High pressure headlight washer motor continues TP39153201 XC60 2010...

  • Page 12: Distribution Box In Engine Compartment F25-F30

    Relay auxiliary lights 10/65 Auxiliary light, front right 2/64 10/69 Auxiliary light, front left 2/64 11B/29 2/17 Relay, horn 16/10 Horn 1 2/17 11B/30 2/32 Main relay, engine management system 4/46 Engine Control Module (ECM), 6-Cyl. continues TP39153201 XC60 2010...

  • Page 13: Distribution Box In Engine Compartment F31-F37

    Mass air flow sensor MAF, 5-Cyl. Diesel 8/98 Control valve fuel pressure, 5-Cyl. Diesel 8/111 Control valve fuel flow, 5-Cyl. Diesel 4/46 Engine Control Module (ECM), 6-Cyl. 7/17 Mass air flow sensor MAF, 6-Cyl. 8/6-11 Injection valves, 6-Cyl. continues TP39153201 XC60 2010...

  • Page 14: Distribution Box In Engine Compartment F38-F43

    Heated fuel filter, 5-Cyl. Diesel 11B/41 6/67 Pump fuel leakage control 6-Cyl. Turbo 7/200 Sensor coolant temperature 9/32 PTC resistor crankcase ventilation, 5-Cyl. Diesel 11A/42 20/22-26 Glow plug, 5-Cyl. Diese 4/109 11A/43 4/71 Cooling fan control module TP39153201 XC60 2010...

  • Page 15: Central Electronic Module (Cem) F1 - F13

    RTI switch 3/130, 3/131 10/1 Lamp housing, front left 10/2 Lamp housing, front right 4/33 Panoramic roof control module 10/48 Reversing light, right 10/55 Reversing light, left 10/5 Fog light, front left 10/6 Fog light, front right continues TP39153201 XC60 2010...

  • Page 16: Central Electronic Module (Cem) F14 - F19

    10/150A Rear reading light 10/150B Rear reading light 17/45 Alcolock outlet 26/6 Converter/control module, sill moldings, driver’s side 26/7 Converter/control module, sill moldings, passenger side 26/8 Alcolock charging cradle Driver Information module (DIM) 4/52 Power seat module (PSM) continues TP39153201 XC60 2010...

  • Page 17: Central Electronic Module (Cem) F20 - F28

    Steering column lock module (SCL) Relay, soldered 6/37 Lock motor, fuel filler flap Climate control module (CCM) 16/35 Siren control module (SCM) 17/13 Data link connector 3/132 Start control module (SCU) Contact brake light 4/93 Keyless vehicle module (KVM) TP39153201 XC60 2010...

  • Page 18: Rear Electrical Center Fa1-Fa12

    Relay, heated rear window Heated rear window 2/82 11D/A9 17/39 13-pin outlet, tow hitch cable harness FA10 11D/A10 4/52 Power seat module (PSM) FA11 11D/A11 4/110 Trailer module (TRM) FA12 11D/A12 4/116 Power Operated Tailgate Module (POT) TP39153201 XC60 2010...

  • Page 19: Distribution Box In Cargo Compartment Fb1-Fb12

    Control module, rear left seat heater 11D/B9 3/27 Switch unit, power passenger seat FB10 11D/B10 4/93 Keyless vehicle module (KVM) FB11 11D/B11 6/146 Lock motor, rear left brake disc 4/115 FB12 11D/B12 6/147 Lock motor, rear right brake disc 4/115 TP39153201 XC60 2010...

  • Page 20: Rear Electrical Center Fd1-Fd7

    16/162 Digital Audio Broadcast Module (DABM) 11D/D5 16/105 Audio module (AUD) 11D/D6 3/281 Infotainment control module (ICM) 4/124 Accessory USB unit (AUU) 16/1 Integrated Audio Module (IAM) 11D/D7 16/60 Phone module (PHM) 16/147 Bluetooth phone module (BPM) TP39153201 XC60 2010...

  • Page 21: Battery Pf1-Pf2

    Fuses in engine compartment fuse box 11B/33 Fuses in engine compartment fuse box 2/32 11B/34 Fuses in engine compartment fuse box 11B/35-11B/41 Fuses in engine compartment fuse box 2/32 6/25 Starter motor 6/26 Alternator control module (ACM) TP39153201 XC60 2010...

  • Page 22: Relays

    Relays Relays in the engine compartment R2 15/33 Engine compartment cold zone Relay function 2/17 Relay, horn TP39153201 XC60 2010...

  • Page 23: Relays In The Engine Compartment R8-R9

    Relays Relays in the engine compartment R8-R9 15/31 Distribution box engine compartment Relay function 2/31 Relay, 15-feed 2/193 Relay, comfort functions TP39153201 XC60 2010...

  • Page 24: Relays In The Engine Compartment R10-R13

    Relays Relays in the engine compartment R10-R13 15/31 Distribution box engine compartment Relay function 2/32 Main relay, engine management system 2/142 Relay pre-heater fuel filter 2/35 Relay, starter motor 2/22 Relay, climate control system TP39153201 XC60 2010...

  • Page 25: Distribution Box In Cargo Compartment Ra1-Rd1

    Relays Distribution box in cargo compartment RA1-RD1 15/32 Rear electrical center Relay function 2/82 Relay, heated rear window 2/16 Relay, rear window wiper 2/88 Relay, 15-feed rear Mounting TP39153201 XC60 2010...

  • Page 26: Central Electronic Module (Cem)

    Central Electronic Module (CEM) 4/56 Central Electronic Module (CEM) Relay function Front fog lights High beam Reversing lights K5-A Washer motor K5-B Washer motor Fuel pump Steering column lock module (SCL) K10-A Interior lighting Lock motor, fuel filler flap TP39153201 XC60 2010...

  • Page 27: Ground Connections

    Ground connections Overview 31/89 XX14 31/88 31/90 XX10 31/95 31/AL XX15 31/2 31/96 31/93 31/94 31/4 31/XX4 31/1 31/3 31/83 31/10 31/7 31/84 31/6 31/15 31/67 31/65 31/68 31/66 31/47 31/5 31/48 31/TRM INFOT TP39153201 XC60 2010...
  • Page 28 Diagnostic contact, brake light, LHD 4/56 Central Electronic Module (CEM), RHD 7/51 Accelerator pedal sensor, LHD 7/175 Weight sensor passenger seat, seat belt reminder, RHD 8/51 Igniter side airbag front left, LHD 8/52 Igniter side airbag front right, RHD TP39153201 XC60 2010...

  • Page 29: 31/10 - 31/15 Continues

    Lock contact, RH front door 3/276 Lock contact, RH rear door 4/52 Power Seat Module (PSM), RHD 6/55 Lock motor, central locking, RH front door 6/56 Lock motor, central locking, RH rear door 7/122 Mass Movement Sensor Module (MMS), front continues TP39153201 XC60 2010...
  • Page 30 Parking Assistance Module (PAM) 9/15 Control module, rear right seat heater 10/46 Fog light, rear right 10/53 Fog light, rear left 31/68 Rear seat riser, RH side 2 6/35 Fuel pump, auxiliary heater 9/38 Electrically heated fuel filter TP39153201 XC60 2010...
  • Page 31 20/6 Spark plug and ignition coil 31/89 Engine ignition coils 20/5 Spark plug and ignition coil 20/6 Spark plug and ignition coil 20/7 Spark plug and ignition coil 20/8 Spark plug and ignition coil 20/16 Capacitor, 6-Cyl TP39153201 XC60 2010...

  • Page 32: 31/90 - 31/Xx10

    3/282 Switch indicator 1st gear, I5D 4/28 Transmission control module (TCM) 4/46 Engine control module (ECM) 6/139 Upper actuating motor, intake manifold 6/140 Lower actuating motor, intake manifold 7/200 Sensor coolant temperature 9/32 PTC resistor, crankcase ventilation TP39153201 XC60 2010...

  • Page 33: 31/Xx14 - 31/Trm

    Multimedia module (MMM) 16/145 Remote Digital Audio Receiver (RDAR) 16/162 Digital Audio Broadcast Module (DABM) 31/TRM Accessories 17/37 4-pin outlet, tow hitch cable harness 17/38 7-pin outlet, tow hitch cable harness 17/39 13-pin outlet, tow hitch cable harness TP39153201 XC60 2010...

  • Page 34: Control Modules

    Control modules Overview locations G034507 TP39153201 XC60 2010...

  • Page 35: Overview Designations

    3/128 Left rear door module (LDM) 4/33 4/33 Panoramic roof control module 3/111 Light switch module (LSM) 4/71 4/71 Cooling fan control module 16/108 Multimedia module (MMM) 17/13 17/13 Data link connector 7/93 Occupant weight sensor (OWS) TP39153201 XC60 2010...

  • Page 36: Central Electronic Module (Cem) 1:3

    4/52 C2:74 RD-GY 2/16:1, 2/16:5 C2:57 RD-BN 7/214:3, 7/122:1 C4:15 7/199:3 C4:16 RD-BN 4/119:1,4/119.2:1 C2:76 YE-OG 4/83:4, 6/33:4 C3:76 YE-BU 4/102:2 C3:71 C3:42 C2:67 YE-BU 6/37:2 C1:67 16/35:3 C3:73 17/13:16, 4/6C1:1 C3:74 RD-VT 3/132:1 C2:66 RD-WH 3/9:1 TP39153201 XC60 2010...
  • Page 37 GY-VT 10/17:1 C2:73 GN-BN 10/18:1 C1:68 YE-OG 10/6:1 C1:69 BU-RD 10/5:1 K5-A C1:71 6/127:1 K5-B C1:72 VT-GN 6/127:2 C1:65 C3:66 RD-GN 4/9C2:67, 7/93:2, 4/125C1:5 C1:55 GN-WH 4/16C1:8 C2:58 C2:55 BU-RD 7/51:6 C3:68 BU-RD 3/65:1, 9/42C1:1 C4:18 8/48:1 TP39153201 XC60 2010...
  • Page 38 GN-BK 3/130C1:7 C3:52 GN-VT 3/111:6 C4:2 VT-OG 3/117C1:8 C4:3 4/33:6 C4:4 GY-BN 4/119:2, 4/119.2:2 C4:7 7/199:2 GY-RD C4:8 73/3030 7/149:1 BK-RD C4:14 VT-WH 4/33:2 73/3036 C4:20 GY-BK 10/22C1:3 BK-GN C1:54 C2:65 BK-GN BK-GN 31/96 31/95 31/7 31/84 TP39153201 XC60 2010...

  • Page 39: Data Communication High Speed Can

    GN-BK GN-BK GN-BK GN-BK GN-BK GN-BK BU-BK BU-BK 73/5098 73/4007 73/4006 73/4038 73/5016 BU-BK BU-BK GN-BK GN-BK GN-BK GN-BK 4/125 3/130 73/4008 C1:4 BU-BK 74/518 C1:3 GN-BK 74/901 4/68 BU-BK C1:3 4/80 4/84 17/13 C1:4 G034235 GN-BK TP39153201 XC60 2010...

  • Page 40: Data Communication Intermediate Speed Can, Lhd

    VT-OG VT-OG VT-OG VT-OG VT-OG VT-OG 73/5012 73/4035 73/5004 73/5010 73/4002 73/5006 74/409 73/3019 GY-OG 73/3020 VT-OG GY-OG 73/5103 VT-OG 73/5104 74/9 74/604 12 11 74/30 C1:6 C1:11 C1:12 C1:11 16/60 C2:3 C2:4 4/116 4/52 G034269 31/47 TP39153201 XC60 2010...

  • Page 41: Data Communication Intermediate Speed Can, Rhd

    GY-OG GY-OG GY-OG VT-OG VT-OG VT-OG VT-OG VT-OG VT-OG VT-OG VT-OG VT-OG VT-OG 73/5002 73/4035 73/5004 73/5012 73/4002 73/5104 73/5006 73/5010 4/116 74/604 C1:4 C1:3 12 11 74/30 C1:12 C1:11 16/60 C2:3 C2:4 4/52 73/5030 G034270 31/47 TP39153201 XC60 2010...

  • Page 42: Data Communication Local Can

    Data communication Local CAN MS - CAN MS - CAN HS- CAN 4/125 4/125 4/16 4/80 74/901 74/412 74/504 74/411 74/901 74/409 11 12 C1:73 VT-WH 74/412 C1:72 74/31 74/409 11 12 7/164 7/203 C1:73 C1:72 7/93 G040977 TP39153201 XC60 2010...

  • Page 43: Data Communication, Lin 1:2

    BUS 1 BUS 2 6/1 LHD 6/1 RHD 4/102 BUS 3 C3:49 GY-BU YE-BU YE-BU 7/149 C1:36 74/901 GY-RD GY-RD C4:8 BUS 2 4/119.2 C2:17 GY-BN BUS 0 C2:40 C4:4 GY-BN GY-BN 4/119 GY-BN 4/93 C4:14 GY-BN TP39153201 XC60 2010...
  • Page 44 5 CYL.D A:36 BU-BN 6/103 BLIS GN-WH BLIS GN-WH 6/48 3/176 27/3 3/126 3/127 27/4 6/95 C2:4 C1:20 BLIS BLIS GN-WH GN-WH GN-WH GN-WH 73/5019 GN-WH GN-WH GN-WH 3/128 3/129 74/507 74/509 74/510 74/508 GN-WH GN-WH GN-WH GN-WH TP39153201 XC60 2010...

  • Page 45: Data Communication Most

    16/60 C2:2 C4:1 C4:1 C4:2 74/404 C2:2 3/281 16/105 C4:1 C4:2 16/108 C3:1 16/145 RDAR C3:1 C3:2 C3:2 16/79 74/529 C2:1 C2:2 16/162 DABM C3:1 C3:2 16/145 RDAR 16/162 DABM RDAR/DABM C3:2 C3:1 74/529 16/79 C2:2 C2:1 TP39153201 XC60 2010...

  • Page 46: Steering Wheel Module (Swm)

    C1:7 C3:51 C3:3 GN-BK TURN 4/68 C1:4 3/131 3/135 C1:3 SWSR 3/281 C1:12 C1:6 C3:5 GN-OG C1:13 C3:4 C1:14 73/4016 C1:2 73/4017 C2:1 C2:2 8/30 C2:33 C2:8 C2:34 C2:7 BN-OG C2:36 C2:2 8/61 C2:35 C2:1 OG-BK 31/83 TP39153201 XC60 2010...

  • Page 47: Group 23 Fuel System

    VT-BN 73/3003 A:62 YE-GN YE-GY 20/4 YE-GN A:57 BK-OG YE-BU YE-GY 31/88 20/6 YE-GN A:56 BK-RD GN-VT 31/89 7/81 A:24 WH-BN A:23 BU-GN A:69 GY-BU 6/139 A:38 BK-YE GY-BU 73/3094 6/140 A:39 BK-YE GY-BU 73/3039 31/XX10 GY-BU TP39153201 XC60 2010...
  • Page 48 74/504 C5:14 VT-WH BU-WH B:26 BU-WH YE-OG YE-OG B:21 YE-OG B:34 BK-WH BK-WH B:35 74/511 74/514 74/507 17 18 73/5072 73/5071 4/83 B:54 B:41 6/62 BK-YE BK-YE BK-YE 7/69 73/3012 6/33 BK-YE GY-BU 31/XX10 31/84 31/7 31/66 TP39153201 XC60 2010...

  • Page 49: Engine Management System, 6-Cyl. B6324S2 1:2

    YE-GY 20/4 YE-GN BK-OG A:57 YE-BU YE-GY 31/88 20/6 YE-GN C2:1 A:56 BK-RD GN-VT 7/81 31/89 A:24 A:23 WH-BN A:69 BU-GN A:92 BU-BN 73/3095 6/139 A:38 BK-YE GY-BU 6/140 73/3133 A:39 BK-YE GY-BU 73/3039 73/3094 GY-BU 31/XX10 TP39153201 XC60 2010...
  • Page 50 4/93 74/504 C5:14 VT-WH BU-WH B:26 BU-WH YE-OG YE-OG B:21 YE-OG B:34 BK-WH BK-WH B:35 74/511 74/514 74/507 17 18 73/5071 4/83 B:54 B:41 6/62 BK-YE BK-YE BK-YE 73/3012 7/69 73/3094 6/33 BK-YE GY-BU 31/XX10 31/7 31/66 TP39153201 XC60 2010...

  • Page 51: Engine Management System, 6-Cyl. Turbo 1:2

    BK-RD VT-BN A:58 73/3003 A:62 YE-GN YE-GY 20/4 YE-GN A:57 BK-OG YE-BU YE-GY 31/89 20/6 YE-GN A:56 BK-RD GN-VT 7/81 31/88 A:24 BU-BN A:23 A:69 BU-GN 8/28 YE-BU A:95 GY-BU A:90 YE-OG 8/68 73/3039 GY-BU GY-BU GY-BU TP39153201 XC60 2010...
  • Page 52 74/504 C5:14 VT-WH BU-WH B:26 BU-WH YE-OG B:21 YE-OG YE-OG B:34 BK-WH BK-WH B:35 74/511 74/514 74/507 17 18 73/5072 73/5071 4/83 B:54 B:41 6/62 BK-YE BK-YE BK-YE 7/69 73/3012 6/33 BK-YE GY-BU 31/XX10 31/84 31/7 31/66 TP39153201 XC60 2010...

  • Page 53: Engine Management System, 5-Cyl. Diesel Euro5 1:3

    1 Ag GY-BU A:52 A:71 73/3131 74/504 4/109 8/98 10 9 7 6 1 Au VT-BK A:42 74/301 74/512 8/111 VT-BK 9/32 9/38 A:95 GN-BU 7/35 1 Ag GY-BU 73/3108 GY-YE A:28 BU-GN A:13 73/3094 GN-BN 31/68 31/XX10 TP39153201 XC60 2010...
  • Page 54 74/504 B:30 BU-WH BU-WH 4/93 BK-WH B:21 BK-WH B:46 C5:14 VT-WH 3/284 BN-GN 74/514 74/507 17 18 73/5072 73/5071 B:54 B:41 6/62 BK-YE BK-YE 7/69 6/33 BK-YE 73/3012 GN-BN GN-BN GN-BN BK-YE GN-BN 31/XX10 31/84 31/7 31/66 TP39153201 XC60 2010...
  • Page 55 EURO 5 7/162 A:62 BU-BN 1 Au A:61 BU-RD A:21 7/165 A:32 WH-BN BU-GN A:80 A:45 GN-BN A:85 7/81 GN-BN A:78 A:18 A:82 WH-BN 6/120 1 Au A:24 BU-GN YE-VT A:48 A:58 YE-VT BU-WH A:20 VT-WH A:33 TP39153201 XC60 2010...

  • Page 56: Emission Control 6-Cyl

    B:46 A:89 GY-VT B:23 VT-OG A:45 WH-GN A:41 BU-BK 73/3039 GY-BU 8/125 GY-BU B:41 W/O Turbo A:90 8/126 GY-BU B:54 W/O Turbo WH-OG A:91 8/117 GY-BU A:86 7/172 A:11 GN-BN A:34 YE-RD A:12 7/173 GN-BN A:33 GN-VT TP39153201 XC60 2010...

  • Page 57: Group 26 Cooling System

    Group 26 Cooling system Cooling fan 5-Cyl. Diesel EURO5 15/31 11A/43 11A/44 4/46 7/16 1 Au A:64 BN-GN DIESEL EURO5 74/301 B:34 GN-BN GN-BN GY-BN GY-BN B:11 4/71 B:54 B:41 BK-BU 31/2 TP39153201 XC60 2010...

  • Page 58: Cooling Fan 6-Cyl

    Group 26 Cooling system Cooling fan 6-Cyl. 15/31 11A/43 11A/44 4/46 7/16 1 Au A:68 A:13 6 CYL 74/301 B:53 B:51 GN-BN GN-BN B:31 GY-BN GY-BN 4/71 B6324S2 B:54 B:41 BK-BU 31/2 TP39153201 XC60 2010...

  • Page 59: Group 27 Engine Controls

    15/31 2/32 B6324S2 & 7/203 I5D EU5 C1:2 Au Au 6 CYL. C1:6 8/111 73/3051 5 CYL.D GY-VT B:27 VT-BK VT-BK A:95 GN-BU 6/120 YE-VT A:75 A:74 BU-GN A:17 BU-OG GN-VT A:67 A:48 BU-RD A:65 31/84 31/7 TP39153201 XC60 2010...

  • Page 60: Group 32 Alternator And Voltage Regulator

    Group 32 Alternator and voltage regulator Power supply 73/3076 6/25 C2:1 C1:1 31/XX4 31/4 6/26 C1:1 4/46 6 CYL A:92 VOLT. REG. 4/46 C2:1 6 CYL BU-BN 73/3095 A:92 BU-BN BU-BN B6324S2 4/46 5 CYL DIESEL A:36 BU-BN 31/3 TP39153201 XC60 2010...

  • Page 61: Group 33 Starting System

    B:25(I5D) GY-BN B:53(I5D), B:17 BU-WH BU-WH 74/411 4/102 3/132 73/4027 C3:35 C3:50 C3:74 RD-VT C3:49 GY-BU C2:27 GY-BN 73/5055 C3:76 YE-BU 3/271 73/4016 C3:71 C3:42 BK-OG YE-BU 73/4012 73/5071 BK-BU 73/5072 G034317 31/10 31/3 31/7 31/84 31/83 TP39153201 XC60 2010...

  • Page 62: Group 35 Lighting

    C1:7 RD-BK RD-BU 4/56 C3:51 C5:1 C5:2 74/411 3/111 C1:76 RD-BK C3:52 GN-VT C1:75 C1:49 C1:50 73/4017 C1:74 C1:73 BK-VT BK-OG 10/1 10/2 TURN HIGH TURN HIGH VT-OG GY-BN BU-GN 73/3033 73/3035 YE-RD 73/4016 31/93 31/94 31/83 TP39153201 XC60 2010...

  • Page 63: High And Low Beam (Dual Xenon)

    RD-BK C3:52 GN-VT C1:75 BU-GN C1:49 C1:50 73/3073 73/4017 C1:74 C1:73 VT-OG 73/3035 73/3033 BK-VT BK-OG 73/3072 BK-VT BK-OG 10/1 10/2 TURN HIGH XENON TURN HIGH XENON HIGH / HIGH / BU-GN YE-RD 73/4016 31/93 31/94 31/83 TP39153201 XC60 2010...

  • Page 64: Beam Length Adjustment, Manual

    Group 35 Lighting Beam length adjustment, manual 15/31 2/31 11B/27 11A/1 11A/2 11B/23 11B/16 74/411 4/56 C5:1 C5:2 C1:45 3/111 C3:52 GN-VT 10/2 10/1 HIGH TURN HIGH TURN VT-GN VT-GN 74/411 73/4017 73/4016 31/83 TP39153201 XC60 2010...

  • Page 65: Running/Parking Light, Tail Lights

    73/3097 C1:50 GY-RD BK-VT C1:40 10/2 10/1 C2:52 C2:50 C2:24 HIGH TURN HIGH TURN GN-OG 74/602 GY-RD YE-BK 10/3 3/35 10/18 10/17 BK-OG BK-BU 73/5031 74/602 BK-OG BK-OG 73/5030 73/6001 73/5033 31/96 31/48 31/94 31/93 31/83 31/47 TP39153201 XC60 2010...

  • Page 66: Running/Parking Light, Tail Lights (Dual Xenon)

    C2:52 C2:50 C2:24 TURN HIGH XENON HIGH / GN-OG 10/2 GY-RD 74/602 YE-BK XENON TURN HIGH HIGH / 10/3 3/35 10/18 10/17 BK-OG BK-BU 73/5031 74/602 BK-OG BK-OG 73/5030 73/6001 73/5033 31/96 31/48 31/47 31/94 31/93 31/83 TP39153201 XC60 2010...

  • Page 67: Fog Lights

    C1:6 RD-BK BU-RD YE-OG 4/56 C5:1 C5:2 C1:69 C1:68 74/411 3/111 RD-BK GN-VT 73/4017 C3:52 73/4016 74/526 74/526 73/3033 BN-GN 74/527B 74/527B 74/527A 74/527A 10/53 10/46 73/5092 BK-BU BK-BU 74/527A 74/527B 74/526 73/5029 31/94 31/93 31/67 31/83 TP39153201 XC60 2010...

  • Page 68: Brake Lights

    C1:49 C5:14 C2:54 VT-WH VT-WH C1:50 74/602 C2:34 YE-GY 10/19 C2:38 C2:59 74/526 BK-OG 73/6001 74/527B 74/527A VT-BN VT-BN 73/5054 10/18 10/17 10/46 74/602 73/5031 73/5092 BK-OG BK-BU 74/527A 74/527B 73/5030 73/5033 74/526 73/5029 31/48 31/67 31/47 TP39153201 XC60 2010...

  • Page 69: Reversing Lights

    AUTO 74/403 74/301 74/411 BN-VT BN-VT BN-VT BN-VT 11A/1 11A/2 A:14 4/56 C5:1 RD-BK C5:2 RD-BU C3:47 C3:48 C1:26 C2:73 C2:62 74/301 3/10 GN-BN GY-VT 10/18 10/17 73/3133 BK-OG BK-BU 73/5031 73/5030 73/3094 73/5033 31/48 31/XX10 31/47 TP39153201 XC60 2010...

  • Page 70: Follow-Me-Home Lighting Lhd

    74/504B 73/5075 15/32 11D/A1 11D/A2 74/508 74/507 3/126 3/127 C1:2 C1:2 C2:3 C2:3 C2:12 BK-VT C2:12 BK-VT C2:23 C2:23 C2:15 C2:15 C1:20 C1:20 C1:13 C1:13 6/62 6/63 73/5037 73/5024 10/149 10/148 74/508 74/507 73/5035 73/5023 31/6 31/15 TP39153201 XC60 2010...

  • Page 71: Follow-Me-Home Lighting Rhd

    74/504B 73/5075 15/32 11D/A2 11D/A1 74/508 74/507 3/127 3/126 C1:2 C1:2 C2:3 C2:3 C2:12 BK-VT BK-VT C2:12 C2:23 C2:23 C2:15 C2:15 C1:20 C1:20 C1:13 C1:13 6/62 6/63 73/5037 73/5024 10/149 10/148 74/508 74/507 73/5035 73/5023 31/6 31/15 TP39153201 XC60 2010...

  • Page 72: Interior Lighting, Lhd 1:2

    MAP READING 3/117 C1:2 C1:1 YE-BU C3:22 10/114 10/150B 10/150A BU-RD BU-RD 74/403 10/72 3/272 BK-GN PANROOF 16/181 73/5026 73/4014 BK-GN BK-WH 74/530 BU-WH 73/4020 BU-WH 73/4016 BU-WH BU-WH 73/5023 BK-WH BK-WH PANROOF 73/4012 BK-WH BK-WH 73/4013 74/414 TP39153201 XC60 2010...
  • Page 73 3/128 BK-GN C2:7 GN-VT 74/510 C2:8 KEYLESS 73/5036 BK-VT C2:6 BK-GN BK-VT 74/508 74/509 6/56 6/55 3/127 C1:2 C2:3 GROUND C2:15 GROUND C1:15 C1:13 73/5035 3/129 73/5024 BK-GN KEYLESS 73/5025 BK-GN 74/508 74/510 BK-GN 73/5023 31/15 31/6 TP39153201 XC60 2010...

  • Page 74: Interior Lighting, Rhd 1:2

    3/117 C1:2 C1:1 YE-BU C3:22 10/114 10/150B 10/150A BU-RD BU-RD 74/403 10/72 3/272 BK-GN PANROOF 16/181 73/5026 73/4014 BK-GN BK-WH 73/4017 74/530 BU-WH 73/4020 BU-WH 73/4016 BU-WH BU-WH 73/5023 BK-WH BK-WH PANROOF 73/4012 BK-WH BK-WH 73/4013 74/414 TP39153201 XC60 2010...
  • Page 75 3/128 C2:7 GN-VT 74/510 C2:8 73/5036 KEYLESS C2:6 BK-VT BK-GN BK-VT 74/508 74/509 6/55 6/56 3/126 C1:2 C2:3 GROUND C2:15 GROUND C1:15 C1:13 BK-GN 73/5035 3/129 73/5037 KEYLESS BK-GN 73/5025 BK-GN 74/508 74/510 BK-GN 73/5023 31/6 31/15 TP39153201 XC60 2010...

  • Page 76: Active Headlight

    C1:1 C1:6 C1:11 BU-OG C1:4 C1:5 C1:2 C1:12 YE-GN 7/119 C1:19 YE-GN C1:9 Four-C GN-BN C1:20 BU-RD 74/504 74/512 7/121 C1:17 YE-GN YE-GN YE-GN Four-C C1:8 GN-BN GN-BN GN-BN C1:18 GN-VT GN-VT GN-VT C1:7 BK-GN 73/3036 31/95 TP39153201 XC60 2010...

  • Page 77: Lighting In Door Sill Trims

    C5:2 K10-A 10X/125 73/4019 BU-WH BU-WH BU-WH GY-BK GY-BK 10/125 C3:67 10X/126 C3:19 BU-WH BU-WH BU-WH GY-BK GY-BK C3:37 10/126 GY-BK 10/249 LHD 10/250 LHD 10/250 RHD 10/249 RHD 26/6 LHD 26/7 LHD 26/7 RHD 26/6 RHD TP39153201 XC60 2010...

  • Page 78: Auxiliary Lights

    Group 35 Lighting, Accessories Auxiliary lights 15/31 11A/2 11A/1 11B/28 3/60 4/56 C°/F° C5:1 RD-BK C5:2 RD-BU C1:50 C1:49 C1:7 C1:12 73/ALS3 C1:7 2/64 1(86) 3(30) 5(87) 2(85) 73/ALS1 73/ALS2 10/69 10/65 31/AL TP39153201 XC60 2010...

  • Page 79: Group 36 Additional Electrical Equipment

    3/130 4/56 C5:1 C5:2 K10-A C1:7 C3:51 GN-BK 7/149 74/901 C4:17 VT-BN VT-BN C4:8 GY-RD GY-RD 73/4014 BK-WH BK-WH C2:65 C1:36 73/4013 74/414 1 LHD 4 RHD 3 LHD 2 RHD 73/4012 73/3034 31/10 31/7 31/84 31/XX15 TP39153201 XC60 2010...

  • Page 80: Direction Indicator And Hazard Warning Flashers Lhd

    C2:11 C2:11 C2:23 C1:13 C1:13 C1:19 C2:36 C3:8 C3:41 C2:18 C1:1 6/62 6/63 BK-VT 73/5024 10/1 10/2 HIGH TURN HIGH TURN 10/18 10/17 74/507 74/508 BK-OG 73/5031 73/5030 73/5033 73/5023 31/6 31/93 31/10 31/94 31/15 31/47 31/48 TP39153201 XC60 2010...

  • Page 81: Direction Indicator And Hazard Warning Flashers Rhd

    C2:11 C2:11 C2:23 C1:13 C1:13 C1:19 C2:36 C3:8 C3:41 C2:18 C1:1 6/63 6/62 BK-GN 73/5024 10/1 10/2 HIGH TURN HIGH TURN 10/18 10/17 74/508 74/507 BK-OG 73/5031 73/5030 73/5033 73/5035 31/15 31/93 31/10 31/94 31/6 31/47 31/48 TP39153201 XC60 2010...

  • Page 82: Wiper/Washer Windshield

    6/1 LHD 6/1 RHD 73/3034 BK-RD BK-RD 4/56 C1:36 C5:2 C5:1 C1:45 74/304 BU-GY BU-GY K5-B K5-A 73/3040 C1:49 C1:50 C1:71 C3:51 C1:72 3/130 73/3037 BK-OG BK-OG 74/304 6/127 18/4 73/3033 WIPER C1:7 GN-BK TURN 31/93 31/XX15 TP39153201 XC60 2010...

  • Page 83: High Pressure Headlight Washer

    Group 36 Additional electrical equipment High pressure headlight washer 15/31 11B/27 2/193 1(86) 3(30) 5(87) 2(85) 3/130 11B/24 18/4 4/56 WIPER C1:7 C3:51 GN-BK TURN C1:48 GN-VT C1:47 WH-BU 74/309 73/3035 BK-OG YE-OG 31/94 TP39153201 XC60 2010...

  • Page 84: Wiper/Washer Rear Window

    Group 36 Additional electrical equipment Wiper/Washer rear window 15/31 3/130 11A/2 11A/1 4/56 18/4 C5:2 C5:1 K10-A WIPER GN-BK C1:7 C3:51 TURN C2:74 C2:44 GY-BN RD-GY 15/32 2/16 RD-GY 6/32 74/602 GY-BU 73/5031 VT-GN BK-OG BK-OG 73/5030 BK-OG BK-OG 73/6001 31/47 TP39153201 XC60 2010...

  • Page 85: Horn

    Group 36 Additional electrical equipment Horn 15/31 11A/1 11A/2 11B/29 RD-VT 73/3041 15/33 3/130 3/37 2/17 18/4 C3:2 C3:6 C1:2 C1:10 4/56 C3:13 C5:1 RD-BK C5:2 RD-BU C1:46 16/10 GY-BK BK-VT 73/3035 73/4016 31/83 31/94 TP39153201 XC60 2010...

  • Page 86: Keyless Vehicle 1:2

    C4:16 C4:4 74/414 11D/B10 74/504 BK-WH 73/4012 31/10 C2:40 C4:14 GY-BN C2:27 C3:35 C2:54 C5:14 VT-WH VT-WH 74/409 C4:15 GY-BN BU-WH BU-WH 73/5055 73/4027 C3:5 RD-VT GY-BN C5:3 3/271 73/5033 C3:4 BK-BU 73/5072 73/5071 31/84 31/7 31/48 TP39153201 XC60 2010...
  • Page 87 VT-OG VT-OG RELEASE C2:2 YE-BU YE-BU LOCK C3:2 BU-BN BU-BN 74/602 16/132 C1:21 GN-OG GN-OG C1:22 16/133 C1:18 YE-BK C1:2 BN-VT 74/530 16/135 C1:4 GN-RD GN-RD C1:16 YE-OG YE-OG 16/134 C2:14 GY-VT GY-VT C2:17 BU-WH BU-WH 31/6 TP39153201 XC60 2010...

  • Page 88: Anti-Theft Alarm

    BK-WH C1:49 C2:9 73/6001 73/4014 74/602 7/214 74/507 73/4013 74/530 74/530 7/122 6/36 GN-VT AJAR 74/414 6/55 74/508 GN-BK GN-BK 73/5026 AJAR 74/530 6/57 74/509 73/4012 AJAR 73/5023 6/56 74/510 AJAR 31/47 31/48 31/15 31/10 31/95 31/96 TP39153201 XC60 2010...

  • Page 89: Parking Assistance

    YE-OG YE-OG GN-WH C3:2 YE-GY 73/5064 7/133 RR/I C3:3 YE-BK BU-WH C3:5 YE-GN YE-GY 15 5 73/5067 GN-WH C1:8 C3:8 BK-GN GN-WH 73/5029 7/132 LR/I BU-WH C1:14 YE-BK C1:7 GN-WH 7/131 LR/O BU-WH YE-GN GN-WH GN-WH 31/67 TP39153201 XC60 2010...

  • Page 90: Collision Warning With Power Brake Booster

    C1:3 GN-BN C1:4 C2:2 BU-GN C1:15 C2:3 C1:6 C2:4 C1:7 C2:5 74/412 C2:6 C1:1 GY-BK GY-BK C2:S C1:14 C1:11 74/418 74/901 9/39 74/411 73/4017 7/203 GY-OG W/O FLR Au Au GY-OG GY-OG 73/3052 GY-OG 73/3030 31/96 31/83 TP39153201 XC60 2010...

  • Page 91: Tire Pressure Monitoring System (Tpms)

    4/56 C5:1 C5:2 C1:49 4/93 C1:50 C3:5 RD-VT C2:17 GY-BN C4:14 C4:3 C4:4 73/5033 C3:4 BK-BU C2:40 C4:4 4/119 C4:16 BK-WH GY-BN GY-BN RD-BN RD-BN 73/4014 7/210 7/211 4/119.2 BK-WH 73/4013 GY-BN RD-BN 74/414 7/212 7/213 73/4012 TP39153201 XC60 2010...

  • Page 92: Alcohol Lock

    15/31 C1:2 11A/1 11A/2 C1:6 4/56 C5:1 C5:2 7/238 K10-A 26/8 73/4019 C3:67 BU-WH C1:49 C1:50 10X/29 C4:16 C2:40 C2:17 C4:4 17/45 GY-BN 10/29 4/119.2 GY-BN 74/414 73/4014 BK-WH BK-WH BK-WH 73/4012 RD-BN PANROOF BK-WH 73/4013 31/10 TP39153201 XC60 2010...

  • Page 93: Group 37 Wiring And Fuses Diagnostics System

    Group 37 Wiring and fuses Diagnostics system 15/31 11A/1 4/56 C5:1 C1:50 C1:49 C3:47 C3:48 C3:73 MIDSPEED 73/4017 BK-WH 73/4012 73/4001 73/4002 73/4037 73/4038 73/4016 31/83 31/10 TP39153201 XC60 2010...

  • Page 94: Outlet 12V

    Group 37 Wiring and fuses Outlet 12V 15/31 11A/3 11A/1 11B/27 2/193 11B/25 74/504B 74/504 73/5075 15/32 4/56 C5:1 C1:48 74/530 11D/A6 RD-VT BK-GN 73/5042 C3:22 9/25 73/5026 BK-GN BK-GN 73/5027 74/403 10/72 17/19 74/530 73/5023 31/48 31/15 TP39153201 XC60 2010...

  • Page 95: Cable Harness Towbar/Tow Hitch 4-Pin

    RD-WH C2:66 C1:50 C1:49 73/5075 VT-WH C2:54 C2:45 73/5040 15/32 C2:59 2/88 11D/A11 73/5054 11D/B1 BU-RD 73/5091 4/110 C1:2 BU-RD C2:5 C2:3 VT-BN 17/37 C3:7 C2:1 C3:3 C2:2 C3:12 10/18 C2:4 BK-OG 73/5031 74/538 73/5030 31/TRM 31/47 TP39153201 XC60 2010...

  • Page 96: Cable Harness Towbar/Tow Hitch 7-Pin

    C2:54 VT-WH C2:45 73/5040 15/32 C2:59 2/88 11D/A11 73/5054 11D/B1 BU-RD 73/5091 4/110 C2:5 BU-RD C1:2 C3:10 C3:2 17/38 C2:3 VT-BN C3:6 C3:8 C2:1 C2:2 C3:1 10/18 C3:12 C2:4 C3:3 C3:7 74/538 BK-OG 73/5031 73/5030 31/TRM 31/47 TP39153201 XC60 2010...

  • Page 97: Cable Harness Towbar/Tow Hitch 13-Pin

    15/32 C2:59 2/88 11D/A11 11D/A9 73/5054 11D/B1 BU-RD 73/5091 4/110 C1:2 BU-RD C2:5 C3:1 C2:3 VT-BN C3:3 C3:7 C2:1 C2:2 C3:12 10/18 C3:10 C3:6 C2:4 C3:8 C3:2 17/39 BK-OG 73/5031 73/5030 74/538 RESERVE: INDICATION TRAILER 31/TRM 31/47 TP39153201 XC60 2010...

  • Page 98: Usb Unit (Auu)

    16X/1C2 GY-YE GY-YE C2:1 GY-YE Y-YE 73/4016 C2:8 GY-YE 16/123 74/403 16X/1C2 GY-VT C2:10 YE-BK C2:12 C2:11 4/124 C1:1 C1:2 17/42 16/98 74/412 C2:4 C2:5 74/409 GN-VT GN-VT GN-VT C2:2 16/16C1:1 C2:2 C2:1 16X/1C4 C4:2 C4:1 31/83 TP39153201 XC60 2010...

  • Page 99: Group 38 Instruments

    Group 38 Instruments Seat belt reminder 15/31 11/A2 11/A1 4/56 C5:1 C5:2 3/117 10/22 73/4014 C4:2 C1:8 C1:4 BK-WH BK-WH VT-OG 73/4013 PANROOF C2:23 74/31 7/175 74/414 BK-GN LHD OWS BK-GN 73/5083 BK-GN 73/4012 31/84 31/7 31/10 TP39153201 XC60 2010...

  • Page 100: Driver Information Module

    RD-WH C1:3 73/4016 C1:2 C1:6 4/115 4/56 C5:1 C5:2 C1:16 C1:17 K10-A GY-BU C1:8 74/409 C3:69 BK-OG 73/3033 C3:11 GY-BU C1:25 C1:11 BK-GN 73/3030 7/73 C1:27 GY-VT 74/511 18 19 73/3036 6/33 31/66 31/93 31/95 31/96 31/83 TP39153201 XC60 2010...

  • Page 101: Group 39 Other Audio Premium 1:3

    74/405 16/50 C3:1 C3:1S 17/42 16/16 74/420 C2:1 C1:1 C1:1 C5:1 VBUS C3:2 C1:4 C5:4 C1:2 C5:2 C3:2S DATA- 16/138 C1:3 C5:3 DATA+ C1:5 SHLD SHLD C5:5 SHIELD C2:1 C1:1 C3:1 C3:1S 16/154 GN-VT FM1/AM C1:2 31/83 TP39153201 XC60 2010...
  • Page 102 C2:2 73/5088 C3:2 BK-GN 4/56 16/181 74/503 74/403 C3:22 C2:16 BU-RD BU-RD WH-OG WH-OG C2:15 C2:17 GN-VT GN-VT C2:1 BU-OG BU-OG C2:13 GY-BN GY-BN C2:2 YE-GN YE-GN C2:3 C2:14 YE-VT YE-VT C2:4 73/5026 74/530 73/5023 31/INFOT 31/15 TP39153201 XC60 2010...
  • Page 103 GY-BK GY-BK GY-BK 73/5079 GN-BK 16/4.1 GY-BK 16/5 74/510 C1:13 VT-RD VT-RD VT-RD C1:5 YE-RD YE-RD YE-RD 16/137 VT-RD YE-RD 16/6 74/509 C1:12 GN-RD GN-RD GN-RD C1:4 GY-RD GY-RD GY-RD 16/136 GN-RD GY-RD 16/26 74/409 C1:10 C1:2 TP39153201 XC60 2010...

  • Page 104: Audio 1:2

    C1:1 GY-YE GY-YE C2:1 C2:8 73/4016 16/123 74/403 C2:10 C2:11 C2:12 16/98 74/412 C2:4 C2:5 74/409 C2:2 GN-VT 74/405 C3:1 C3:1S 16/50 16/138 16/16 C2:1 C1:1 C3:2 C3:2S C1:1 C2:1 16/154 C3:1 C3:1S GN-VT FM1/AM C1:2 31/83 TP39153201 XC60 2010...
  • Page 105 VT-BK YE-BK 74/407 C1:1 VT-BK C1:7 16/4.2 YE-BK 74/507 C1:6 GN-BK GN-BK VT-BK C1:12 GY-BK GY-BK YE-BK 16/5 74/510 C1:4 VT-RD VT-RD VT-RD C1:10 YE-RD YE-RD YE-RD 16/6 74/509 C1:3 GN-RD GN-RD GN-RD C1:9 GY-RD GY-RD GY-RD TP39153201 XC60 2010...

  • Page 106: Cellular Phone 1:2

    15/32 C1:50 C1:17 11D/D6 11D/D7 C3:64 74/503 74/403 C1:5 GY-YE GY-YE AUDIO PREMIUM GY-YE 16/98 74/412 3/130 16/1 C1:6 C2:5 GY-YE C2:4 C2:1 73/4016 C4:1 C2:8 C1:6 C4:2 3/281 73/4017 C2:1 C2:2 C1:13 GN-OG C1:12 C1:14 31/83 TP39153201 XC60 2010...
  • Page 107 RESET C3:3 POWER WH-OG C3:2 C3:1 GN-VT CLOCK 3/267 74/412 C1:1 BN-GN BN-GN C1:2 GY-VT GY-VT C1:3 BU-GY BU-GY C1:4 YE-VT YE-VT C1:13 C1:14 C1:15 16/47 74/406 C2:1 C3:1 TELE C2:1S C3:1S C5:1 C1:1 C5:1S C1:1S 74/419 TP39153201 XC60 2010...

  • Page 108: Dab Radio

    15/32 11D/D4 16/162 C1:1 RD-BN DABM 16/47 C3:1 C3:2 74/531 74/531 C2:1 C2:1 C2:1S C2:1S 74/532 C1:2 C2:2 C2:2S 16 /16 16/1 C5:1 C5:1S C4:1 C4:2 3/281 16/105 C2:1 C2:2 C1:13 C4:1 C1:14 C4:2 73/5123 C1:12 31/INFOT TP39153201 XC60 2010...

  • Page 109: Telephone System Bluetooth

    Group 39 Other Telephone system Bluetooth 15/31 11A/5 74/505 RD-BN 15/32 11D/D7 74/503 74/403 16/147 C2:1 C1:32 C2:2 C1:16 31/83 TP39153201 XC60 2010...

  • Page 110: Bluetooth Handsfree

    GY-YE GY-YE C1:1 73/4016 C1:11 YE-VT C1:2 3/290C1:2 GY-BN C1:6 GY-BN 3/290C1:5 GN-VT C1:7 GN-VT 3/290C1:6 C1:8 3/290C1:1 C1:9 3/290C1:3 C1:10 YE-GN YE-GN 3/290C1:4 GN-OG C1:12 GN-OG 3/130C1:6 GY-OG GY-OG C1:13 VT-OG VT-OG C1:14 C1:15 C1:16 31/83 TP39153201 XC60 2010...

  • Page 111: Multimedia & Traffic Information

    74/403 16/46 16/108 C2:1 C1:6 C3:1 HLDF 74/408 C2:2 C1:2 C2:2 SYNC SYNC C3:2 C1:3 C2:3 C2:3 V-GND VREF C1:4 C2:4 C1:5 C2:5 C1:6 C2:6 C1:S C2:S S-GND C1:11 C5:1 C5:1S C4:1 C4:1S 73/5123 16/16 16/47 31/INFOT TP39153201 XC60 2010...

  • Page 112: Satellite Radio

    Group 39 Other, Accessories Satellite radio 15/31 11A/5 74/505 RD-BN 15/32 11D/D4 16/145 C1:1 RD-BN RDAR 16/47 C2:1 C2:1 C2:1S C2:1S C1:2 C3:1 C3:2 16/1 C4:1 C4:2 73/5123 3/281 16/105 C2:1 C2:2 C1:13 C4:1 C1:14 C4:2 C1:12 31/INFOT TP39153201 XC60 2010...

  • Page 113: Parking Camera

    27/6 74/403 27/7 RD-BN 16/46 C2:5 C2:1 C3:1 HLDF 16/108 C1:6 C3:1S 74/408 C2:2 C1:2 C2:2 SYNC SYNC C1:3 C2:3 C2:3 V-GND VREF C3:1 C1:4 C2:4 C1:5 C2:5 C3:2 C1:6 C2:6 C1:S C2:S S-GND C1:11 73/5123 31/INFOT TP39153201 XC60 2010...

  • Page 114: Group 43 Transmission

    Transmission M66 15/31 11A/1 11A/2 4/46 3/282 5 CYL DIESEL B:26 Ag GY-VT 4/56 C5:1 C5:2 3/10 74/301 C1:26 7/123 C1:51 C1:53 WH-VT C1:52 BN-GN C3:43 74/403 8/134 73/3133 WH-BN BK-GN 73/5026 73/3094 74/530 73/5023 31/XX10 31/15 TP39153201 XC60 2010...

  • Page 115: Automatic Transmission, Tf-80Sc Awd

    SLUG C3:47 C3:48 4/56 8/38 8/39 C1:45 C5:1 C5:2 C1:50 C1:49 3/156 8/36 74/301 74/411 74/403 A:16 BU-GY BU-GY BU-GY BU-GY A:13 GN-OG GN-OG GN-RD GN-OG BN-VT BN-VT BN-VT BN-VT 74/530 BK-GN 73/5026 73/3094 73/5023 31/XX10 31/15 TP39153201 XC60 2010...

  • Page 116: Differential Electronic Module (Dem)

    Differential electronic module (DEM) 15/31 11A/1 11A/2 11A/4 4/56 C5:1 RD-BK 74/504B C5:2 RD-BU C3:48 C3:47 73/5040 C2:45 15/32 2/88 11D/B6 GN-RD 4/82 74/511 74/520 C1:1 GN-RD GN-RD BU-BK BU-BK C1:8 GN-BK C1:7 GN-BK C1:4 BK-YE C1:2 BK-YE 74/514 31/65 TP39153201 XC60 2010...

  • Page 117: Group 55 Parking Brake Electric Parking Brake

    RD-BK C3:48 C5:2 RD-BU C3:22 74/504B 73/5040 BU-RD 15/32 3/272 11D/B11 11D/B12 73/4017 74/409 73/4016 4/115 C1:15 C1:13 73/5070 C1:28 BK-OG C1:30 BK-OG 74/514 74/524 Ag Ag Ag Ag 6/146 6/147 2- 1+ 2- 1+ 31/47 31/83 TP39153201 XC60 2010...

  • Page 118: Group 59 Brake System

    GN-RD 74/512 7/164 7/57 C1:43 YE-BK YE-BK C1:42 BU-RD BU-RD C1:19 GN-OG GN-OG C1:18 BU-WH BU-WH C1:22 VT-BN VT-BN C1:29 GN-BU GN-BU 8/46 C1:24 VT-GY C1:23 BU-GY C1:21 WH-GN C1:31 GY-OG C1:17 YE-GN C1:16 C1:47 73/3070 31/XX14 TP39153201 XC60 2010...

  • Page 119: Group 64 Steering

    Group 64 Steering Speed dependent power steering 4/56 15/31 11B/27 11A/2 11A/1 2/31 C5:1 RD-BK C5:2 RD-BU C1:45 GN-VT 11B/19 C1:17 4/99 VT-WH 6/71 GN-BU WH-GN BK-OG 73/3033 31/93 TP39153201 XC60 2010...

  • Page 120: Group 76 Shock Absorbers

    VT-WH VT-WH VT-WH C1:28 8/22 YE-GN YE-GN YE-GN GN-BU GN-BU GN-BU C1:2 C1:1 YE-BU YE-BU YE-BU 74/511 74/525 3/225 74/503 YE-RD YE-RD C1:24 C1:26 C1:11 GN-BK GN-BK GY-OG C1:29 GY-OG C1:3 YE-BK YE-BK C1:21 VT-OG VT-OG 31/67 TP39153201 XC60 2010...

  • Page 121: Group 83 Doors And Openings Central Locking Front Doors Lhd

    C1:2 RD-BK RD-BK C1:15 C1:15 C1:13 C1:13 BK-VT BK-VT BK-GN 73/5037 GN-VT GN-BK BK-GN BK-GN C1:9 KEYLESS KEYLESS C1:21 73/5024 C1:21 C1:10 C1:7 C1:9 C1:7 C1:10 BK-GN 73/5023 73/5035 6/55 6/36 GROUND GROUND G034461 GN-BK 31/15 31/6 TP39153201 XC60 2010...

  • Page 122: Central Locking Front Doors Rhd

    C1:13 73/5037 C1:15 BK-VT C1:13 BK-GN BK-GN 73/5019 GN-WH C1:20 BK-VT BK-VT GN-VT GN-WH Au C1:9 KEYLESS KEYLESS GN-BK C1:21 73/5024 C1:21 C1:10 C1:7 C1:9 C1:7 C1:10 73/5023 73/5035 6/55 6/36 GROUND GROUND BK-GN G034462 31/6 31/15 TP39153201 XC60 2010...

  • Page 123: Central Locking Rear Doors

    3/128 3/129 C2:9 C2:8 74/509 74/510 GN-WH GN-WH RD-BU RD-BU RD-GN BK-GN BK-GN KEYLESS BK-VT BK-VT KEYLESS 73/5036 BK-VT BK-GN 73/5025 73/5023 73/5035 6/57 3 10 4 6/56 4 10 3 1 GROUND GROUND G034463 31/6 31/15 TP39153201 XC60 2010...

  • Page 124: Central Locking Tailgate

    C2:6 4/93 C2:11 BN-VT GY-BN RIGHT C4:14 C2:7 BK-OG 73/6001 C2:9 C4:4 C2:5 C2:1 GN-OG 6/149 C4:3 C5:18 C2:8 GN-BU 74/602 73/5044 74/602 73/5032 GY-YE 3/291 73/6007 GY-BN BU-WH BK-OG 74/602 74/604 3/35 10/3 10/25 31/47 31/83 TP39153201 XC60 2010...

  • Page 125: Central Locking Fuel Filler Flap

    Group 83 Doors and openings Central locking fuel filler flap 15/31 11A/1 11A/2 11B/23 4/56 C5:1 C5:2 74/411 C2:65 BK-GN BK-GN C2:67 C3:52 3/111 6/37 73/4017 73/4016 73/5033 31/48 31/7 31/84 31/83 TP39153201 XC60 2010...

  • Page 126: Signal Receiver Central Locking

    Group 83 Doors and openings Signal receiver central locking 15/31 11A/1 11A/2 4/56 C5:1 C5:2 C2:17 C4:16 C4:4 C2:40 4/119.2 BK-WH 73/4014 73/4013 74/414 73/4012 31/10 TP39153201 XC60 2010...

  • Page 127: Power Windows Front Doors Lhd

    C1:20 C2:3 C2:15 C1:22 C1:11 C1:18 C1:20 C1:2 C1:2 C1:13 BK-GN KEYLESS C1:12 C1:1 C1:6 C1:17 C1:5 C1:16 C1:12 C1:1 C1:6 C1:17 C1:5 C1:16 73/5024 6/60 6/58 74/507 74/508 3/176 GN-WH 73/5023 73/5035 BU-WH BK-VT 31/6 31/15 TP39153201 XC60 2010...

  • Page 128: Power Windows Front Doors Rhd

    C1:2 C1:20 C1:22 C1:11 C1:18 C2:15 C2:3 C1:13 C1:2 C1:20 C1:13 C2:3 C2:15 C1:12 C1:1 C1:6 C1:17 C1:5 C1:16 C1:12 C1:1 C1:6 C1:17 C1:5 C1:16 74/507 74/508 6/60 6/58 73/5023 73/5035 3/176 GN-WH BK-GN BU-WH 31/6 31/15 TP39153201 XC60 2010...

  • Page 129: Power Windows Rear Doors

    Group 83 Doors and openings Power windows rear doors 15/31 11A/1 11A/3 74/504B 73/5075 15/32 3/19 11D/A3 11D/A4 3/21 RD-BU 74/509 74/510 3/129 3/128 KEYLESS KEYLESS 73/5025 73/5036 6/61 6/59 74/509 74/510 73/5023 73/5035 31/6 31/15 TP39153201 XC60 2010...

  • Page 130: Power Sunroof

    CLOSE 74/414 C3:75 C4:14 C4:3 F 31 3/117 C3:7 C3:11 C3:6 C3:5 C3:8 C1:5 BU-BK C1:4 BK-WH 73/4014 73/4031 C2:3 YE-OG 10/22 BU-RD C2:2 VT-BN C2:1 BK-BU 4/33 74/414 RD-BN RD-BN BK-WH 73/4012 BK-WH BK-WH 73/4013 31/10 TP39153201 XC60 2010...

  • Page 131: Group 84 Exterior Decorative Elements, Etc

    KEYLESS BK-GN 73/5019 3/127 3/126 C1:20 C1:2 C1:13 C2:3 C2:15 C1:20 C1:2 C1:13 C2:3 C2:15 74/508 74/507 6/63 6/62 10 9 MEM X MEM X MEM Y MEM Y 73/5035 73/5023 3/176 GN-WH BU-WH BK-VT 31/6 31/15 TP39153201 XC60 2010...

  • Page 132: Power Door Mirrors Rhd

    73/5024 3/127 3/126 C1:13 C1:2 C1:20 C2:15 C2:3 C1:13 C1:2 C1:20 C2:3 C2:15 74/507 74/508 6/62 6/63 10 9 10 9 MEM X MEM X MEM Y MEM Y 73/5035 73/5023 3/176 GN-WH BK-GN BU-WH 31/6 31/15 TP39153201 XC60 2010...

  • Page 133: Heated Door Mirrors Lhd

    74/507 BK-VT 74/508 BK-GN 73/5024 GN-WH KEYLESS BK-GN 73/5019 3/127 3/126 C1:13 C2:3 C2:15 C1:20 C1:20 C1:2 C1:2 C1:13 C2:3 C2:15 C2:23 C2:10 C2:23 C2:10 74/508 74/507 6/63 6/62 73/5035 73/5023 3/176 GN-WH BU-WH BK-VT 31/6 31/15 TP39153201 XC60 2010...

  • Page 134: Heated Door Mirrors Rhd

    BK-GN 74/508 74/507 73/5037 BK-VT KEYLESS GN-WH BK-VT 73/5019 73/5024 3/127 3/126 C1:13 C1:2 C1:20 C2:3 C1:13 C1:2 C1:20 C2:3 C2:15 C2:23 C2:10 C2:23 C2:10 74/507 74/508 6/63 6/62 73/5035 73/5023 3/176 GN-WH BK-GN BU-WH 31/6 31/15 TP39153201 XC60 2010...

  • Page 135: Blind Spot Information System Lhd

    73/5024 BK-GN KEYLESS GN-WH 73/5019 3/126 3/127 C1:13 C2:3 C2:15 C1:20 C1:20 C1:2 C1:2 C1:13 C2:3 C2:15 C2:23 C1:3 C2:4 C2:23 C1:3 C2:4 6/62 6/63 74/508 74/507 27/3 27/4 73/5035 73/5023 3/176 GN-WH BU-WH BK-VT 31/6 31/15 TP39153201 XC60 2010...

  • Page 136: Blind Spot Information System Rhd

    BK-VT KEYLESS 73/5019 73/5024 3/127 3/126 C1:13 C1:2 C1:20 C2:15 C2:3 C1:13 C1:2 C1:20 C2:3 C2:15 C2:23 C1:3 C2:4 C2:23 C1:3 C2:4 6/62 6/63 74/507 74/508 27/3 27/4 73/5035 73/5023 BK-GN 3/176 GN-WH BK-GN BU-WH 31/6 31/15 TP39153201 XC60 2010...

  • Page 137: Heated Rear Window

    Group 84 Exterior decorative elements, etc. Heated rear window 15/31 11A/1 74/504B 73/5075 15/32 C°/F° 2/82 C1:10 C1:8 4/56 C2:26 YE-RD C1:49 C5:2 C1:50 C5:1 GY-RD 74/602 GY-RD 73/6008 31/5 TP39153201 XC60 2010...

  • Page 138: Group 85 Interior Equipment

    C2:6 GN-BK 31 S C2:12 GN-RD 6/19 C1:2 C2:4 CAN + BK-VT C2:3 73/5 CAN - C2:7 VT-BK C2:11 VT-RD 3/26 6/18 C1:4 BK-YE 73/6 C2:9 YE-BK C2:13 YE-RD 6/17 BK-BU C1:5 C2:10 BU-BK C2:14 BU-RD 31/6 TP39153201 XC60 2010...

  • Page 139: Power Driver's Seat With Memory Function, Rhd

    C2:2 GN-BK 31 S C2:9 GN-RD 6/19 C2:4 BK-VT CAN + 73/5 C1:6 C2:3 CAN - C2:14 VT-BK C2:10 VT-RD 3/26 6/18 BK-YE 73/6 C1:4 C2:12 YE-BK C2:8 YE-RD 6/17 BK-BU C1:3 C2:11 BU-BK C2:7 BU-RD 31/15 TP39153201 XC60 2010...

  • Page 140: Power Passenger Seat, Lhd

    74/504B 73/5040 4/56 15/32 C5:1 C5:2 3/27 6/65 K10-A BK-BU DOWN 6/66 BK-YE 11D/B9 DOWN 6/20 BK-VT FORWARD BACK 6/64 C2:56 BK-GN FORWARD STOP LOGIC BACK 74/31 BU-WH EXT. X RD-GN 73/5044 RD-BU RD-BK BK-GN 73/5023 31/15 TP39153201 XC60 2010...

  • Page 141: Power Passenger Seat, Rhd

    74/504B 73/5040 4/56 15/32 C5:1 C5:2 3/27 K10-A 6/65 BK-BU DOWN 6/66 BK-YE DOWN 11D/B9 6/20 BK-VT FORWARD BACK 6/64 C2:56 BK-GN FORWARD STOP LOGIC BACK 74/31 EXT. X RD-GN BU-WH 73/5044 RD-BU RD-BK BK-VT 73/5035 31/6 TP39153201 XC60 2010...

  • Page 142: Heated Front Seats

    4/56 15/32 C5:2 C5:1 74/401 11D/B4 11D/B3 73/4010 74/417 2/88 74/409 C2:45 VT-OG WH-GN BN-VT WH-GN BN-VT 74/31 74/30 9/12 9/13 9/16 9/17 7/110 7/111 9/18 9/19 74/30 74/31 73/5023 73/5035 73/5023 73/5035 31/15 31/15 31/6 31/6 TP39153201 XC60 2010...

  • Page 143: Heated Rear Seat

    15/32 C1:65 C5:1 C5:2 C1:45 BU-GN YE-RD 11D/B5 11D/B7 2/88 C2:45 C3:68 74/403 9/14 3/65 9/15 BU-RD GN-BU GN-BU 9/11 GY-VT GY-VT BK-GN 73/5026 7/112 7/113 GN-BU GN-BU GY-VT GY-VT 9/10 74/530 73/5029 73/5023 31/65 31/67 31/15 TP39153201 XC60 2010...

  • Page 144: Group 87 Climate Control System

    Group 87 Climate control system Climate control system PTC-element 15/31 11A/7 11A/1 11A/2 2/31 11B/17 4/56 C5:1 C5:2 C1:65 C1:45 9/42 C2:1 C1:1 BU-RD C3:68 C1:2 C3:39 BU-GN C1:3 C3:1 73/4016 31/83 31/1 TP39153201 XC60 2010...

  • Page 145: Climate Control System 1:2

    B:27 EURO 5 74/401 73/4028 C1:1 YE-RD C1:7 BN-VT WH-GN C1:12 C°/F° 4/31 C1:5 73/4026 C1:14 YE-VT YE-VT 74/401 VT-BK VT-BK C1:2 6/28 C1:13 BU-GN 73/4018 C1:8 C1:16 C1:10 73/4016 7/10 BU-WH C1:4 C1:6 GN-BU 31/10 31/83 TP39153201 XC60 2010...
  • Page 146 Group 87 Climate control system Climate control system 2:2 15/31 4/56 2/193 11B/26 C1:48 BU-BK VT-GN 74/411 3/112 6/96 74/417 BU-BK 74/401 73/4010 BN-VT BN-VT WH-GN 6/102 73/4012 BK-WH BK-WH 6/103 74/414 6/48 6/95 YE-VT BU-GN 7/159 7/41 31/10 TP39153201 XC60 2010...

  • Page 147: Parking Heater, Auxiliary Heater

    C5:2 RD-BU C1:50 C1:49 VT-OG GY-OG 73/3019 YE-VT 74/9 C1:6 C1:11 C1:3 74/9 C1:7 YE-RD C1:10 WH-VT C1:9 GN-OG 74/504 C1:2 6/73 74/512 9/30 6/35 FUEL COOLANT GLOW PREHEAT TEMP OVERHEAT C1:4 74/9 74/512 73/3034 31/XX15 31/68 TP39153201 XC60 2010...

  • Page 148: Parking Heater, Remote Start

    73/3019 YE-VT 74X/9 FUSE 1A 74/9 C1:6 C1:11 C1:3 74/9 74X/9 C1:7 YE-RD C1:10 WH-VT C1:9 GN-OG 74/504 C1:2 6/73 74/512 9/30 4/106 FUEL COOLANT GLOW PREHEAT TEMP OVERHEAT 6/35 C1:4 74/9 74X/9 74/512 73/3034 31/XX15 31/68 TP39153201 XC60 2010...

  • Page 149: Group 88 Internal Equipment

    Rear-view mirror with automatic dimming 15/31 11A/2 11A/1 11B/27 2/31 11B/17 4/56 C5:2 C5:1 C1:45 C1:65 C°/F° C4:18 C1:7 BN-VT 74/401 8/48 74/412 BN-VT BN-VT 73/4010 BK-WH BK-WH BK-WH 73/4014 BK-WH BK-WH 73/4012 PANROOF PANROOF 73/4013 74/414 31/10 TP39153201 XC60 2010...

  • Page 150: Supplemental Restraint System 1:2

    10/22 18/4 74/412 8/30 C2:70 C1:7 GN-WH GN-WH C1:4 C2:8 C2:33 C2:47 C1:10 C2:7 C2:34 BN-OG GY-BU GY-BU 8/61 C2:2 C2:36 C2:1 C2:35 OG-BK 73/4014 C1:2 73/4016 73/4017 73/4013 8/99 74/414 C2:40 C2:39 YE-BK 73/4012 31/83 31/10 TP39153201 XC60 2010...
  • Page 151 3/255 C1:72 C1:30 YE-VT C1:73 VT-WH VT-WH C1:29 BU-GY RD-GN RD-GN C1:28 BK-GN C1:27 7/175:2 12 2 6 7 8 74/409 RD-GN RD-GN 4/56C3:66 2 1 3 73/4041 BK-GN 73/5124 BK-BU BK-GN BK-GN 31/84 BK-GN BK-GN 31/7 TP39153201 XC60 2010...

  • Page 152: Remote Controlled Garage Opening

    Group 88 Internal equipment Remote controlled garage opening 15/31 11A/1 11A/2 10/114 LHD 10/115 RHD 4/76 4/56 C5:1 C5:2 K10-A 73/4014 73/4013 C3:67 BU-WH 73/4019 74/414 74/414 73/4012 73/4020 BU-WH 31/10 TP39153201 XC60 2010...

  • Page 153: Index 1:2

    Engine management system, 5-Cyl. Diesel ....53 Parking heater, auxiliary heater ......... 147 Engine management system, 6-Cyl. Parking heater, remote start ........148 Turbo ..........47 Parking light ..............65 Exterior decorative elements, etc., Group 84 .... 131 TP39153201 XC60 2010...

  • Page 154: Table Of Contents

    Running light, (Dual Xenon) ........66 Wiper/Washer rear window ......... 84 Wiper/Washer Windshield ........... 82 Satellite radio ............112 Wiring and fuses, Group 37 ......... 93 Seat belt reminder ............99 Shock absorbers, Group 76 ........120 TP39153201 XC60 2010...

  • Page 155: List Of Components 1:5

    Suspension module (SUM) 3/131 Steering wheel switch right (SWSR) 4/86 Parking Assistance Module (PAM) 3/132 Start control module (SCU) 4/93 Keyless vehicle module (KVM) 3/135 RTI switch 4/99 Electronic power steering control module 3/156 Gear selector module (GSM) TP39153201 XC60 2010...
  • Page 156 Passenger seat motor, up/down front edge 7/62 Output speed sensor 6/66 Motor passenger seat, up/down rear edge 7/69 Sensor outside temperature 6/67 Pump, fuel leakage control 7/73 Coolant level sensor 6/71 Valve, speed-dependent power steering 7/74 Fluid temperature sensor, automatic transmission TP39153201 XC60 2010...
  • Page 157 Igniter, right rear belt tensioner 7/178 Front impact sensor, right 8/61 Igniter, airbag stage 2, driver’s side 7/179 Front impact sensor, left 8/62 Belt tensioner igniter, center rear seat 8/66 Igniter, left inflatable curtain 8/67 Igniter, right inflatable curtain TP39153201 XC60 2010...
  • Page 158 Electrically heated fuel filter 10/125 Left-hand front courtesy lighting 9/39 Heating element camera 10/126 Right-hand front courtesy lighting 9/42 PTC-element 10/148 Lighting, left front door mirror 9/43 Heated windshield washer nozzle, left 9/44 Heated windshield washer nozzle, right TP39153201 XC60 2010...
  • Page 159 Connector interface, original car 74X/9 Connector interface, original car 16/135 Antenna, door lock, passenger compartment 74X/414 Connector interface, original car 16/136 LH rear door tweeter 16/137 RH rear door tweeter 16/138 Right-hand rear window antenna 16/140 SIM card reader TP39153201 XC60 2010...

Table of Contents

Save PDF
