VOLVO S60 & XC60
VOLVO NAVIGATION SYSTEM (VNS)
Web Edition
OPERATING MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the S60 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Volvo S60

Summary of Contents for Volvo S60

  • Page 1 VOLVO S60 & XC60 VOLVO NAVIGATION SYSTEM (VNS) Web Edition OPERATING MANUAL...
  • Page 2 Text and symbols on the screen Direction to take at next guidance point Distance to the next guidance point Name of next street or road Stored location Symbol for Final destination Remaining time to destination Final destination Remaining distance to destination Intermediate destination Speed limit (at the vehicle’s current location (18)) Compass...
  • Page 3 VOLVO NAVIGATION SYSTEM (VNS) WITH RTT VNS is a navigation system developed by Volvo, which is designed The system indicates the vehicle’s current location, and shows part to help guide you to the destination of your choice and provide infor- or all of the route to your destination, depending on the settings you mation along the way.

  • Page 4: Table Of Contents

    Contents 01 Quick guide 02 Getting to know your 03 Planning your trip navigation system Getting started.......... 10 Setting a destination......... 38 This manual..........16 Itinerary............. 44 Before you begin........17 Current position........47 DVDs and the screen........ 19 Settings............. 48 System overview ........

  • Page 5: Points Of Interest (Pois) 66

    Contents 04 Traffic information 05 Symbols on the map 06 Questions & Answers Introduction..........58 Points of interest (POIs)......66 Frequently asked questions...... 70 Reading information........60 EULA – License agreement....... 72 Dealing with traffic problems....62...

  • Page 6: Contents

    Contents 07 Index Index............76...
  • Page 7 Contents...
  • Page 8 Getting started..................10...
  • Page 9 Q U I C K G U I D E...

  • Page 10: Quick Guide

    Navigation system options Navigate and make selections by turning the thumb wheel (1). With the ignition switched on (see the section The Volvo Navigation System can be operated • "Ignition modes" in the Owner's Manual): in several ways: Confirm a selection by pressing the thumb wheel (written in the following •...
  • Page 11 01 Quick guide Getting started Guidance to a street address Screen/menu Action Screen/menu Action Screen/menu Action Itinerary Scroll to Start guid- Set destination Scroll to Point of ance + OK. interest (POI) Do as follows if a Press the NAV but- map is not displayed ton on the center The system will...
  • Page 12 01 Quick guide Getting started Demo mode (simulated guidance) The system has a Demonstration Mode that can be used as a learning tool, see page 54.
  • Page 13 01 Quick guide...
  • Page 14 This manual..................... 16 Before you begin..................17 DVDs and the screen................19 System overview ..................20 Navigation system controls..............23 Voice control................... 25 On-screen keyboard................28 Maps, types of roads and the compass..........30 Main menu, Scroll menu................. 32 Menu selections..................34...
  • Page 15 G E T T I N G T O K N O W Y O U R N A V I G A T I O N S Y S T E M...

  • Page 16: Getting To Know Your Navigation System

    A quick guide is available to help you get started with the basic functions as quickly as Contact your Volvo retailer for additional infor- possible, see page 10. mation. The rest of the manual is divided into chapters...

  • Page 17: Before You Begin

    Before you begin General information Map mode On/Off The Volvo Navigation System uses the WGS84 When the system is started, it displays the fol- reference system, which provides the vehicle's lowing text, which must be confirmed by press- 1. Press the remote key into the ignition slot.
  • Page 18 02 Getting to know your navigation system Before you begin NOTE The system can be used even when the engine is not running. To help avoid battery drain, the system should be turned off when it is not in use. Demo (simulated guidance) For an overview of how guidance functions, specify a destination.

  • Page 19: Dvds And The Screen

    The ferred to the vehicle's navigation system, an update is in progress. latest DVDs can be purchased from a Volvo which is done using the infotainment system's retailer. media player. To update the map information: DVD care 1.

  • Page 20: System Overview

    02 Getting to know your navigation system System overview The above illustration is schematic; certain details may vary, depending on the car model and market...
  • Page 21 02 Getting to know your navigation system System overview Global Positioning System (GPS) culate the vehicle’s current location and direc- Screen tion. antenna The screen displays the maps and provides The antenna is integrated into the roof module. detailed information about routes, distances, This also helps the system calculate direction etc.
  • Page 22 02 Getting to know your navigation system System overview Speakers Sound from the navigation system comes from the infotainment system's front speakers.

  • Page 23: Navigation System Controls

    02 Getting to know your navigation system Navigation system controls About Navigation system controls Press OK/MENU to confirm or activate a Voice control selection. The button will be described in The navigation system can be operated using See the section "Voice control" beginning on the manual as OK or "+ OK."...
  • Page 24 02 Getting to know your navigation system Navigation system controls the # sign. Press the INFO button to display all of the available information.

  • Page 25: Voice Control

    02 Getting to know your navigation system Voice control Introduction Getting started See the "Tutorial" section on page 26 for additional information about using voice com- The navigation system's voice control feature mands to control the navigation system. enables you to voice-activate certain system functions.
  • Page 26 02 Getting to know your navigation system Voice control 3. The text on the screen will change Useful tips NOTE Repeat instruction Navigation go to to " • When giving commands, speak at your A complete list of short cut commands can address Itinerary Itinerary...
  • Page 27 02 Getting to know your navigation system Voice control • By pressing the voice control button and The available languages have this icon Settings Voice settings Voice user saying "Voice tutorial." in the list. User 1 User 2 setting. Select •...

  • Page 28: On-Screen Keyboard

    02 Getting to know your navigation system On-screen keyboard Entering text and making selections Entering characters Other characters The inset menu in the text wheel shows other special characters or numbers. Note that grayed-out characters cannot be selected in the current context: •...
  • Page 29 02 Getting to know your navigation system On-screen keyboard The number in the upper right corner of the screen indicates that the there are five alterna- tives containing the characters entered ( No list An empty list and the characters in the upper right corner indicates that there are over 1,000 alternatives containing the characters...

  • Page 30: Maps, Types Of Roads And The Compass

    02 Getting to know your navigation system Maps, types of roads and the compass Map views The above illustration is schematic; certain details may vary, depending on the car model and market...
  • Page 31 02 Getting to know your navigation system Maps, types of roads and the compass Voice guidance Compass Once a destination has been entered and the The red point on the compass Map views of the current location vehicle is approaching an intersection or an needle points north on the The way in which the map is displayed exit, a voice will provide guidance about dis-...

  • Page 32: Main Menu, Scroll Menu

    02 Getting to know your navigation system Main menu, Scroll menu The menu system Display the main menu from the map Scroll menu view The various sections of this manual present all • Press OK. of the navigation system's menus and alterna- tives.
  • Page 33 02 Getting to know your navigation system Main menu, Scroll menu The crosshairs Pause guidance Pressing OK will display a menu for the point on the map that the crosshairs are currently pointing to. This menu contains the following alternatives: •...

  • Page 34: Menu Selections

    02 Getting to know your navigation system Menu selections Three levels of the menu structure are shown p. 40 p. 42 Stored location Postcode here. A number of the third level menus also have sub-menus, which are described in detail Add to itinerary Route details in their respective sections in this manual.
  • Page 35 02 Getting to know your navigation system Menu selections p. 60 p. 50 p. 52 Read traffic message Map options System options Map colors GPS information p. 62 Traffic events along route Show dual map mode Map version: Single map settings Map loading progress Traffic events ahead Right map settings...
  • Page 36 Setting a destination................38 Itinerary....................44 Current position..................47 Settings....................48 Demo....................... 54...
  • Page 37 P L A N N I N G Y O U R T R I P...

  • Page 38: Planning Your Trip

    03 Planning your trip Setting a destination Address See page 28 for information about entering 3. Or select City: + OK and begin entering the text/numbers in the system's various text name. fields. The following search criteria can be used: •...
  • Page 39 03 Planning your trip Setting a destination More about Information Points of interest (POI) By name In addition to searching for a POI by general Select an address/street + OK to select the fol- Set destination Point of interest (POI) lowing: category (e.g., restaurants), the POI's name can be used.
  • Page 40 03 Planning your trip Setting a destination Along the route Along the street Storing a location To store the location of your choice: 1. Use the scroll function (see page 32) to select the location to be saved. 2. Press OK to open the crosshairs' menu. 3.
  • Page 41 03 Planning your trip Setting a destination • Edit Name • Icon • Distance • Chronological Delete • Delete a stored location. Previous destination Store displays this editing menu Store displays the same editing menu as for This opens the selected stored location and Stored location Edit.
  • Page 42 03 Planning your trip Setting a destination Searching for a location on the map Searching by latitude/longitude Add to itinerary Add the selected coordinates for the location on the map to the itinerary. Information This displays any available information about the location.
  • Page 43 03 Planning your trip Setting a destination 1. Select Postcode: + OK to display the text wheel. 2. Select characters with TUNE and enter them by pressing OK (or use the center console number keys). NOTE Zip codes/post codes may be presented differently, depending on the country/area.

  • Page 44: Itinerary

    03 Planning your trip Itinerary Menu overview Set up an itinerary with several stops along the NOTE way to avoid adding intermediate destinations The most recently added intermediate des- during your trip. tination always becomes Intermediate des- tination 1. Existing ones will be raised one Up to 8 intermediate destination can be set.
  • Page 45 03 Planning your trip Itinerary • • Clear itinerary : erase the current itinerary. Move in list : change the order in which the Next destination intermediate destinations appear in the • Route options : opens a shortcut to itinerary. Settings Route options, see...
  • Page 46 03 Planning your trip Itinerary • Delete : remove the current intermediate Otherwise, the functions are the same as for destination and show the next one. the Scroll menu, see page 32. • : show a position on the map with the Scroll menu, see page 32.

  • Page 47: Current Position

    03 Planning your trip Current position Where am I? Current position This feature displays a map with the vehicle's current location and information such as the location's name and coordinates.

  • Page 48: Settings

    03 Planning your trip Settings Traffic information Traffic message (Traffic message) Settings Route options Several selections can be made here for dis- playing traffic messages. (Settings > Route options) • : information about all reported traffic Route type disruptions will be displayed. •...
  • Page 49 03 Planning your trip Settings • Route proposal Avoid season-restricted roads (Avoid Route options season-restricted roads) • Avoid unverified roads • Avoid borders NOTE • If a route has already been set when one or more of these alternatives are changed, there may be a slight delay in guidance as the system recalculates the route.
  • Page 50 03 Planning your trip Settings If this alternative is marked and the same route : the "car" symbol and map will always be Settings Map options is driven three times, this new route will be viewed from above. stored and replace the original itinerary. (Settings >...
  • Page 51 03 Planning your trip Settings • The map can be displayed over the entire Points of interest (POIs) on the map Graphic screen or two split-screen maps can be dis- • Text : the compass heading (upward on the played at the same time. screen) will be indicated by a letter, for example for "North."...
  • Page 52 03 Planning your trip Settings Guidance options Mark Voice guidance if you would like spoken System information instructions. See page 25 for additional infor- mation. Voice volume Voice guidance (Voice guidance) This displays a volume control on the screen for setting the level for voice guidance. •...
  • Page 53 03 Planning your trip Settings • Map-matched position Reset navigation settings Delete all user data • Altitude: • The geographic name of the current posi- tion. Map version Settings Reset navigation settings Settings Delete all user data This function returns all settings to the original The menu alternative Settings Delete all...

  • Page 54: Demo

    03 Planning your trip Demo Start the demo (system simulation) Route details Start demo When the vehicle is at a standstill, this function offers simulated guidance to the currently set destination. To interrupt the simulation: • Start The previous memo selection ( demo ) changes to Stop demo...
  • Page 55 03 Planning your trip...
  • Page 56 Introduction..................... 58 Reading information................60 Dealing with traffic problems..............62...
  • Page 57 T R A F F I C I N F O R M A T I O N...

  • Page 58: Traffic Information

    04 Traffic information Introduction Display and reception Traffic symbols on the map Slow traffic Broadcast traffic information is always received and presented, even if no destination is specified. Slow traffic in both directions The way in which traffic information is presen- ted can be set and changed in Settings Extent...
  • Page 59 04 Traffic information Introduction Extent Accident Contraflow (two-way traffic, single lanes in each direction) Detour (diversion) Information Certain traffic messages also contain informa- Narrow road tion on the extent of the traffic obstruction. In addition to the symbol, a yellow, orange, red or black line along the route is shown on all Parking information scales up to 3 miles.

  • Page 60: Reading Information

    04 Traffic information Reading information Read traffic message Traffic information 1. Move the crosshairs to the traffic disrup- A traffic problem and the area affected, marked by Main menu tion (indicated by a colored line or arrows arrows parallel with the road) that you would like Traffic information information about.
  • Page 61 04 Traffic information Reading information • expected duration • limitations (speed, vehicle width/height, etc.) • roads affected If there is more than one traffic disruption within the box, press OK to display information about the problem closest to the center of the cross- hairs first.

  • Page 62: Dealing With Traffic Problems

    04 Traffic information Dealing with traffic problems Avoiding traffic disruptions changes from Traffic events ahead Traffic The system will then calculate a new route to avoid the traffic disruption. events along route . You can opt to have the Traffic events ahead system guide you around the traffic disruption To get detailed information about a listed traffic on another route.
  • Page 63 04 Traffic information Dealing with traffic problems • Return to the map by pressing EXIT or Calculate new route select + OK: the itin- erary will be adjusted according to the changes made. A list with one alternative that can be edited. The following can be done: •...
  • Page 64 Points of interest (POIs)................66...
  • Page 65 S Y M B O L S O N T H E M A P...

  • Page 66: Symbols On The Map

    05 Symbols on the map Points of interest (POIs) Specify individual POIs to be shown on the NOTE Volvo dealer None map or select , see page 51. • The icons used for POIs and the number of POIs available may vary from country Parking to country.
  • Page 67 05 Symbols on the map Points of interest (POIs) Opera house/theater Park & Recreation Library Rest area Bar/nightclub Hospital Hotel Pharmacy Convention/exhibition center Restaurant Bank Train/commuter train station Restaurant Airport Post Restaurant, Chinese Bus station School/daycare center Restaurant, sea food Ferry terminal Campground Fast food...
  • Page 68 Frequently asked questions..............70 EULA – License agreement..............72...
  • Page 69 Q U E S T I O N S & A N S W E R S...

  • Page 70: Questions & Answers

    The vehicle’s position on the map is Updated DVDs are produced periodically. Tall buildings and mountains, tunnels, via- Please contact your Volvo retailer for more incorrect after its battery has been ducts, over/underpasses etc., also have a neg- information about availability.
  • Page 71 The system will automat- ically guide you to the final destination even if you drive past intermediate destinations. The system’s map information is not up- to-date Contact your Volvo retailer for updated map information. WARNING Navigating safely Always use good judgment when following...

  • Page 72: Eula - License Agreement

    06 Questions & Answers EULA – License agreement END-USER TERMS TERMS AND CONDITIONS tions installed or otherwise connected to or in communication with vehicles, capable of vehi- The Map Data Disc ("Data") is provided for your Personal Use Only cle navigation, positioning, dispatch, real time personal, internal use only and not for resale.
  • Page 73 06 Questions & Answers EULA – License agreement Disclaimer of Warranty ANY LOSS OF PROFIT, REVENUE, Entire Agreement NT AND ITS LICENSORS (INCLUD- These terms and conditions constitute the CONTRACTS OR SAVINGS, OR ANY entire agreement between NT (and its licen- ING THEIR LICENSORS AND SUP- OTHER DIRECT, INDIRECT, INCI- sors, including their licensors and suppliers)
  • Page 74 06 Questions & Answers EULA – License agreement delivered or otherwise furnished shall be marked and embedded as appropriate with the following "Notice of Use," and shall be treated in accordance with such Notice: NOTICE OF USE CONTRACTOR (MANUFACTURER/ SUPPLIER) NAME: NAVTEQ CONTRACTOR (MANUFACTURER/ SUPPLIER) ADDRESS : 222 Merchandise...
  • Page 75 06 Questions & Answers...
  • Page 76 07 Index About this manual........16 End-User terms......... 72 Intermediate destination......45 Activating the system........ 10 Extent............59 Intersections..........38 Address Itinerary entering..........38 clearing..........45 start guidance........44 Avoiding an area........45 Factory settings........17, 53 Frequently asked questions....... 70 Locations Change scale of traffic information....
  • Page 77 07 Index symbols on........... 66 Settings............17 version..........53 resetting..........53 Questions & Answers......... 70 Map areas..........19 Simulated guidance (demo)....... 54 Quick guide..........10 Map mode..........17 Start guidance........... 44 Map scale..........42 Steering wheel keypad..........21 Menu scroll............. 32 Stored locations........
  • Page 78 07 Index Unverified roads........31 Voice guidance..........31 Voice commands........25 Volvo Navigation System activating..........10 demo............. 54 end-user terms........72 general information....... 17 GPS receiver......... 21 overview..........20 questions & answers......70 quick guide........... 10 switching on/off........17 system menus........34 unverified roads........
