Summary of Contents for Origin Acoustics Crown CDi CDi1000
- Page 1 Crown CDi Amplifier Set-Up For Origin Landscape Speakers Models: CDi1000 CDi2000 CDi4000...
-
Page 2: Table Of Contents
LANDSCAPE CROWN AMPLIFIER INSTALLATION MANUAL TABLE OF CONTENTS Introduction Crown Amplifier Ins & Outs Input Connections Unbalanced (Most Common) Balanced Output Connections Terminating The Wires Which Preset To Use? How To Load A Preset How Many Speakers Can Be Run On Each Channel? 7 Technical Assistance 844·674·4461 WWW.ORIGINACOUSTICS.COM... -
Page 3: Introduction
LANDSCAPE CROWN AMPLIFIER INSTALLATION MANUAL CH. 2 Source INTRODUCTION Origin Landscape speakers are designed so they can be part of a 70V system or an 8Ω system for smaller installs using a standard receiver. As part of a 70V system, they will need to be paired with Shield a Crown CDi amplifier that has been designed to work with our Landscape speakers. -
Page 4: Output Connections
LANDSCAPE CROWN AMPLIFIER INSTALLATION MANUAL WHICH PRESET TO USE? The Crown CDi series amplifier you purchased from Origin Acous- Output Connections tics is preloaded with 18 presets to allow allow you to optimally configure your sound system for practically any circumstance. Terminating the wires The presets have been divided into two families -- the Active Attach the supplied spade connectors to the ends of your speaker... -
Page 5: How To Load A Preset
LANDSCAPE CROWN AMPLIFIER INSTALLATION MANUAL EQ Presets on Crown CDi amplifiers for Origin Acoustics How to Load a Preset 1. Press the Select / Enter button on the front of the amplifier. 2. Press the Next / Down button until the word PRESET appears on the display. -
Page 6: Technical Assistance
If you are considering returning the product, it’s required that you contact Origin Acoustics prior to any return attempts. This way we can determine if the issue can be resolved without returning the product, or if needed we can provide instructions and support for the return process. - Page 7 ©2014 Origin Acoustics. All copyrighted, trademarked and patented elements mentioned herein are the sole property of Origin Acoustics.
