FOUNDATION COLLECTION
™
DSP3-100
Installation Manual
DSP3-100

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FOUNDATION COLLECTION DSP3-100 and is the answer not in the manual?

Questions and answers

Related Manuals for Origin Acoustics FOUNDATION COLLECTION DSP3-100

Summary of Contents for Origin Acoustics FOUNDATION COLLECTION DSP3-100

  • Page 1 FOUNDATION COLLECTION ™ DSP3-100 Installation Manual DSP3-100...

  • Page 2: Table Of Contents

    Table of Contents Introduction Amplifier Presets Specifications What’s Included Wire Recommendations About the DSP3-100 Startup Loading a DSP preset Adjusting the Volume Troubleshooting Technical Assistance Warranty Return Process...

  • Page 3: Introduction

    DSP3-100 AMPLIFIER INSTALLATION USER MANUAL Introduction Thank you for purchasing the DSP3 Series amplifier. At Origin Acoustics, we take pride in providing you with a high quality product. All of Origin Acoustics’ products are designed to have excellent sound quality, longevity, and a simple installation process.

  • Page 4: Amplifier Presets

    DSP3-100 AMPLIFIER INSTALLATION USER MANUAL Amplifier Presets PRESET SUB MODEL PRESET NAME MODEL SYSTEM DESCRIPTION NUMBER NUMBER NUMBER All DSP Bypassed, All inputs and outputs DSP Off None None linked, three mono channels Sub channel tuned for OSUB 10P, left OS55 P10 OSUB 10P OS55...
  • Page 5 DSP3-100 AMPLIFIER INSTALLATION USER MANUAL Amplifier Presets PRESET SUB MODEL PRESET NAME MODEL SYSTEM DESCRIPTION NUMBER NUMBER NUMBER Sub channel tuned for DSUB8, left and D39 D8 DSUB8 right channels tuned for D39 Sub channel tuned for DSUB10, left and D39D10 DSUB10 D138...

  • Page 6: Specifications

    DSP3-100 AMPLIFIER INSTALLATION USER MANUAL Specifications MODEL DSP3-100 PART AMPD03X1000 # of Channels 3 Powered Out (L/R/S) Analog Input 2x RCA A/B Unbalanced Max Input 12dBu Analog output 2x RCA A/B Unbalanced 17 x 3 1/ 2 x 14”(433 x 88 x 357mm) (Without mounts) Dimensions 19 x 3 1/ 2 x 14”...

  • Page 7: What's Included

    DSP3-100 AMPLIFIER INSTALLATION USER MANUAL The gauge of wire used can have an impact on the performance of your speakers. Use a multi-stranded wiring designed for amplifier to speaker connections. Which gauge to select depends on the length of wire to be used on any particular speaker.

  • Page 8: About The Dsp3-100

    DSP features are accessible by using the remote PC software. Each DSP3-100 comes preloaded with up to 16 DSP presets to optimize it for use with all of Origin Acoustics’ speakers and subwoofers assuring peak performance.
  • Page 9 DSP3-100 AMPLIFIER INSTALLATION USER MANUAL In order to access the menu, press the dial. Rotate the dial to select either “Load Program,” “Change Volume” or “Exit Menu” DSP3-700 Load Program DSP3-700 Change Volume DSP3-700 Exit Menu...

  • Page 10: Loading A Dsp Preset

    IP 192.168.0.100 Preset: “Program Name” Turn the dial to select your desired preset to match your Origin Acoustics Speakers. If you are not sure which preset to use, refer to the “Amplifier Preset” section of this manual. Once you have found the desired program number it will be blinking.

  • Page 11: Adjusting The Volume

    DSP3-100 AMPLIFIER INSTALLATION USER MANUAL Adjusting the Volume To change the volume, select the “Change Volume” page from the main page and press the dial to select. Output Left: Level = 0.0dB Once selected the volume level will appear on the display. Use the dial to change the volume level (from -60dB to +12dB) and press the dial once again to confirm the volume level selection.

  • Page 12: Troubleshooting

    DSP3-100 AMPLIFIER INSTALLATION USER MANUAL Troubleshooting If you have a problem, try isolating it first. For example, if you’re playing a DVD and there is no sound, try replacing the DVD with an MP3 player to see if you get sound.

  • Page 13: Technical Assistance

    If you are considering returning the product, it’s required that you contact Origin Acoustics prior to any return attempts. This way we can determine if the issue can be resolved without returning the product, or if needed we can provide instructions and support for the return process.
  • Page 14 If the product is determined to be defective, it will be repaired or replaced at Origin Acoustics’ discretion. If the product must be replaced yet it is no longer manufactured, it will be replaced with a model of equal to or greater value that is the most similar to the original.

  • Page 15: Warranty

    Before making any return attempts, it is required that you first contact Origin Acoustics. Return product to Origin Acoustics or your dealer, either in person or by mail. It’s preferable if the product is returned in the original packaging. If this isn’t possible, the customer is responsible for insuring the shipment for the full value of the product.
  • Page 16 6975 S Decatur Blvd, Las Vegas, NV 89118 • www.originacoustics.com • 844-674-4461 ©2019 Origin Acoustics. All copyrighted, trademarked and patented elements mentioned herein are the sole property of Origin Acoustics.
