SUBA-500
SUBA500 SUBWOOFER AMPLIFIER
FEATURES
SUBA500 SUBWOOFER AMPLIFIER
L
OUT
(LFE)
DC 12V
TRIGGER
R
IN
OUT
IN
IR
D E
F
G
A. POWER
Red: O /Standby
Blue: On/Operating
B.
STATUS DISPLAY MENU
Displays current function/setting.
C. SELECTION KNOB/ROTARY ENCODER
Navigates and controls menu display functions.
D. RCA LINE LEVEL INPUTS
LFE IN: Connects the left female RCA input to an LFE output connection on a receiver or pre-amp processor.
L/R IN: Connects the left and right female RCA input to the left and right front output connections on a
receiver or pre-amp processor.
E.
RCA LINE LEVEL OUTPUTS
OUT: Connects additional ampli ers.
F.
12V TRIGGER IN/OUT
12V TRIGGER IN: Turns on the amp when a 12V signal is received from another 12V trigger device.
12V TRIGGER OUT: Sends a 12V signal to another 12V trigger device.
G. IR PORT
Installation Manual
OPERA TE
UPDATE
H
I
565.0
EA-AMP-SUB-1D-500R
SUB 1
Total Impedance
SUB 2
(Sub 1 + Sub 2) Minimum 4
J
page | 3
FUSE T8AL/250V
100-120V~60Hz/220-240V~50Hz 500W
ATTS
100-120V AC
220-240V AC
K
L
M N
