Page 5: Introduction
SUBA -150 AMPLIFIER INSTALLATION USER MANUAL Introduction Thank you for purchasing the SubA Series amplifier. At Origin Acoustics, we take pride in providing you with a high quality product. All of Origin Acoustics’ products are designed to have excellent sound quality, longevity, and a simple installation process. -
Page 6: Amplifier Specifications
SUBA -150 AMPLIFIER INSTALLATION USER MANUAL Amplifier Specifications MODEL SUBA-150 PART AMPSUB1X150 Continuous Power Output 80 watts RMS at 8 ohms 150 watts RMS at 4 ohms Input Sensitivity 140 mV for full output (L/LFE only driven), 150 W, with level... -
Page 7: What's Included
SUBA -150 AMPLIFIER INSTALLATION USER MANUAL What’s Included 100-120V AC 220-240V AC CROSSOVER PHASE VOLUME TRIGGER DESIGNED AND ENGINEERED IN THE USA MADE IN CHINA FUSE T8AL/250V AUTO 300(LFE) SUB 1S TOTAL IMPEDANCE UB 2 +12VDC 100-120V~60Hz/220-240V~50Hz 500 WATTS INPUT OUTPUT POWER MODE (SUB 1 + SUB 2) MINIMUM 4... -
Page 8: Amplifier Features
SUBA -150 AMPLIFIER INSTALLATION USER MANUAL Amplifier Features A. Power Red: Off/Standby Blue: On/Operating B. RCA LINE LEVEL INPUTS LFE IN: Connects the left female RCA input to an LFE output connection on a receiver or pre-amp processor. L/R IN: Connects the left and right female RCA input to the left and right front output connections on a receiver or pre-amp processor. - Page 9 SUBA -150 AMPLIFIER INSTALLATION USER MANUAL Single Sub Connection Single Sub Connection AV RECEIVER AV RECEIVER SWITCHED OUTLET SWITCHED OUTLET LFE SUB OUT LFE SUB OUT 100-120V AC 220-240V AC CROSSOVER PHASE VOLUME TRIGGER DESIGNED AND ENGINEERED IN THE USA MADE IN CHINA FUSE T8AL/250V AUTO...
-
Page 10: Setup Guide
SUBA -150 AMPLIFIER INSTALLATION USER MANUAL 5” MINIMUM OF FREE AIR SPACE ABOVE 3” MINIMUM OF FREE AIR SPACE ON SIDE 5” 3” Set Up Guide 5” AMPLIFIER POSITIONING 5” MINIMUM OF FREE AIR SPACE BELOW Placing the amplifier can have a large impact on performance and longevity. Please take the following guidelines into consideration: page | 6 •... - Page 11 SUBA -150 AMPLIFIER INSTALLATION USER MANUAL CONNECTION ! CAUTION: All connections and switching must be done with the amplifier turned off. Connect the power cord last to ensure that the amplifier is off during all the connections and set up. RCA Line Level Use high-quality RCA cables that feature low impedance with adequate shielding and high-quality connectors.
- Page 12 SUBA -150 AMPLIFIER INSTALLATION USER MANUAL DUAL SUB CONNECTIONS Dual Sub Connections 100-120V AC 220-240V AC CROSSOVER PHASE VOLUME TRIGGER DESIGNED AND ENGINEERED IN THE USA MADE IN CHINA FUSE T8AL/250V AUTO 300(LFE) SUB 1 TOTAL IMPEDANCE SUB 2 +12VDC 100-120V~60Hz/220-240V~50Hz 500 WATTS INPUT OUTPUT...
-
Page 13: Fine Tuning
SUBA -150 AMPLIFIER INSTALLATION USER MANUAL Fine Tuning After making all connections and calibrating the speakers, fine tune the subwoofer as instructed below. NOTE: When using an AV receiver and the LFE input, set the subwoofer calibration level to the factory setting. 1. - Page 14 SUBA -150 AMPLIFIER INSTALLATION USER MANUAL NOTE: If deeper bass is desired, adjust the CROSSOVER control toward the lower frequencies. Experiment with different frequency settings until finding one that sounds best. When using the LFE input, set to LFE and make any crossover adjustments in the preamplifier or receiver crossover settings.
-
Page 15: Troubleshooting
SUBA -150 AMPLIFIER INSTALLATION USER MANUAL Troubleshooting If you have a problem, try isolating it first. For example, if you’re playing a DVD and there is no sound, try replacing the DVD with an MP3 player to see if you get sound. -
Page 16: Technical Assistance
If you are considering returning the product, it’s required that you contact Origin Acoustics prior to any return attempts. This way we can determine if the issue can be resolved without returning the product, or if needed we can provide instructions and support for the return process. -
Page 17: Year Limted Warranty
If the product is determined to be defective, it will be repaired or replaced at Origin Acoustics’ discretion. If the product must be replaced yet it is no longer manufactured, it will be replaced with a model of equal to or greater value that is the most similar to the original. -
Page 18: Return Process
Before making any return attempts, it is required that you first contact Origin Acoustics. Return product to Origin Acoustics or your dealer, either in person or by mail. It’s preferable if the product is returned in the original packaging. If this isn’t possible, the customer is responsible for insuring the shipment for the full value of the product. - Page 19 SUBA -150 AMPLIFIER INSTALLATION USER MANUAL...
