Outdoor Lifestyles CARODG36I-B Owner's Manual

Care and operation
Hide thumbs Also See for CARODG36I-B:

Advertisement

INSTALLER: Leave this manual with party responsible for use and operation.
OWNER: Retain this manual for future reference.
NOTICE: DO NOT discard this manual!
Models:
WARNING!
Risk of Fire!
Do not install glass doors on this fi replace.
Glass doors could cause overheating of
adjacent structures.
DANGER
Outdoor Lifestyles by Hearth & Home Technologies Inc. • Carolina-B Owner's Manual • 4066-501 Rev. G • 7/15
Owner's Manual

Care and Operation

alteration, service or maintenance can cause injury or property
damage. Read the installation, operating and maintenance
instructions thoroughly before installing or servicing this
equipment.
DANGER
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open fl ame.
3. If odor continues, keep away from the
appliance and immediately call your gas
supplier or fi re department.
WARNING: For Outdoor Use Only.
WARNING
Do not store or use gasoline or other fl ammable
vapors and liquids in the vicinity of this or any
other appliance.
An LP-cylinder not connected for use shall not
be stored in the vicinity of this or any other
appliance.
WARNING:
Improper installation, adjustment,
CARBON MONOXIDE HAZARD
This appliance can produce carbon monoxide
which has no odor.
Using it in an enclosed space can kill you.
Never use this appliance in an enclosed space
such as a camper, tent or home.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CARODG36I-B and is the answer not in the manual?

Questions and answers

Summary of Contents for Outdoor Lifestyles CARODG36I-B

  • Page 1: Care And Operation

    Using it in an enclosed space can kill you. Never use this appliance in an enclosed space such as a camper, tent or home. Outdoor Lifestyles by Hearth & Home Technologies Inc. • Carolina-B Owner’s Manual • 4066-501 Rev. G • 7/15...
  • Page 2: Welcome

    Maximum Pressure (Pression) ........... X.X in. w.c. (Po. Col. D’eau) Serial: Min/Max Input BTUH: ............XX,XXX/XX,XXX (Série): Orifice Size: ................ #XX/ XXX Model Number Outdoor Lifestyles by Hearth & Home Technologies Inc. • Carolina-B Owner’s Manual • 4066-501 Rev. G • 7/15...
  • Page 3: Table Of Contents

    C. Contact Information ......24  = Contains updated information. Outdoor Lifestyles by Hearth & Home Technologies Inc. • Carolina-B Owner’s Manual • 4066-501 Rev. G • 7/15...
  • Page 4: Limited Warranty

    Outdoor Lifestyles Warranty - 2108-975B - 2/15/13 - page 1 Outdoor Lifestyles by Hearth & Home Technologies Inc. • Carolina-B Owner’s Manual • 4066-501 Rev. G • 7/15...
  • Page 5 The duration of any implied warranty is limited to the duration of the warranty period specified herein. Outdoor Lifestyles Warranty - 2108-975B - 2/15/13 - page 2 Outdoor Lifestyles by Hearth & Home Technologies Inc. • Carolina-B Owner’s Manual • 4066-501 Rev. G • 7/15...
  • Page 6: Product Specifi C Information

    36,000/55,000 #27 / .144 CARODG36I-B (LP) 29,000/50,000 #46 / .081 CARODG42I-B (NG) 33,000/65,000 #24 / .152 CARODG42I-B (LP) 37,000/62,000 #43 / .089 Outdoor Lifestyles by Hearth & Home Technologies Inc. • Carolina-B Owner’s Manual • 4066-501 Rev. G • 7/15...
  • Page 7: Appliance Safety

    The appliance is considered to be over fi ring if the fl ames are contacting the top of the fi rebox. Call a qualifi ed service technician to service the appliance Outdoor Lifestyles by Hearth & Home Technologies Inc. • Carolina-B Owner’s Manual • 4066-501 Rev. G • 7/15...
  • Page 8: General Operating Parts

    • Conversions must be made by a qualified service technician using Hearth & Home Technologies specifi ed and approved parts. Outdoor Lifestyles by Hearth & Home Technologies Inc. • Carolina-B Owner’s Manual • 4066-501 Rev. G • 7/15...
  • Page 9: Lighting Instructions (Ipi)

    For additional information on operating your Hearth & Home Technologies fi replace, please refer to www.fi replaces.com. Final inspection by Outdoor Lifestyles by Hearth & Home Technologies Inc. • Carolina-B Owner’s Manual • 4066-501 Rev. G • 7/15...
  • Page 10: Appliance Break-In

    CAUTION! Risk of Electric Shock! Avoid touching wires operation without receiving a command from the wall and electrical components in appliance control cavity. switch or optional remote. Outdoor Lifestyles by Hearth & Home Technologies Inc. • Carolina-B Owner’s Manual • 4066-501 Rev. G • 7/15...
  • Page 11: Maintenance And Service

    CAUTION! Risk of Burns! The fi replace shall be turned off and cooled before servicing. Outdoor Lifestyles by Hearth & Home Technologies Inc. • Carolina-B Owner’s Manual • 4066-501 Rev. G • 7/15...
  • Page 12: Maintenance Tasks - Qualifi Ed Service Technician

    Figure 4.1 IPI Pilot Flame Patterns NOTE: Appearance of rock jig, pilot shield and media tray may vary between appliance models. Outdoor Lifestyles by Hearth & Home Technologies Inc. • Carolina-B Owner’s Manual • 4066-501 Rev. G • 7/15...
  • Page 13 Figure 4.7. Notch against grate Figure 4.4 Place Left Front Log Figure 4.7 Place Top Right Log Outdoor Lifestyles by Hearth & Home Technologies Inc. • Carolina-B Owner’s Manual • 4066-501 Rev. G • 7/15...
  • Page 14 Place the top log on the indentations of the left front log and the back log as shown in Figure 4.10 for Carolina-36. Figure 4.10 Place Top Log in Center- Carolina 36 Outdoor Lifestyles by Hearth & Home Technologies Inc. • Carolina-B Owner’s Manual • 4066-501 Rev. G • 7/15...
  • Page 15: Frequently Asked Questions And Troubleshooting

    fi cations of the attached non-combustible material are listed in the Installer’s Manual for this the touch. appliance. Contact your dealer for additional information regarding operation and troubleshooting. Visit www.hearthnhome.com to locate a dealer. Outdoor Lifestyles by Hearth & Home Technologies Inc. • Carolina-B Owner’s Manual • 4066-501 Rev. G • 7/15...
  • Page 16: Troubleshooting

    Verify that 1.5 to 1.8 VDC is supplied to pilot solenoid from module. If below 1.5 volts, replace module. If 1.5 volts or greater, replace valve. Outdoor Lifestyles by Hearth & Home Technologies Inc. • Carolina-B Owner’s Manual • 4066-501 Rev. G • 7/15...
  • Page 17 A. False fl ame detected. Shut off gas and power immediately and call a technician. 3 Flashes on the Module Red LED. Outdoor Lifestyles by Hearth & Home Technologies Inc. • Carolina-B Owner’s Manual • 4066-501 Rev. G • 7/15...
  • Page 18: Reference Materials

    • Install a switch lock or a wall/remote control with child protection lockout feature. • Keep remote controls out of reach of children. See your dealer if you have questions. Outdoor Lifestyles by Hearth & Home Technologies Inc. • Carolina-B Owner’s Manual • 4066-501 Rev. G • 7/15...
  • Page 19: Service Parts

    Carolina 36” Outdoor Beginning Manufacturing Date: May 2014 Gas Fireplace Ending Manufacturing Date: Active Log Set Assembly Part number list on following page. 07/15 Outdoor Lifestyles by Hearth & Home Technologies Inc. • Carolina-B Owner’s Manual • 4066-501 Rev. G • 7/15...
  • Page 20 Pilot Ori ce NG 593-528 Pilot Ori ce LP 593-527 Regulator NG NGK-DXV-50 Regulator LP LPK-DXV-50 Additional service part numbers appear on following page. Outdoor Lifestyles by Hearth & Home Technologies Inc. • Carolina-B Owner’s Manual • 4066-501 Rev. G • 7/15...
  • Page 21: Log Set Assembly

    Carolina 42” Outdoor Beginning Manufacturing Date: May 2014 Gas Fireplace Ending Manufacturing Date: Active Log Set Assembly Part number list on following page. 07/15 Outdoor Lifestyles by Hearth & Home Technologies Inc. • Carolina-B Owner’s Manual • 4066-501 Rev. G • 7/15...
  • Page 22 Pilot Ori ce NG 593-528 Pilot Ori ce LP 593-527 Regulator NG NGK-DXV-50 Regulator LP LPK-DXV-50 Additional service part numbers appear on following page. Outdoor Lifestyles by Hearth & Home Technologies Inc. • Carolina-B Owner’s Manual • 4066-501 Rev. G • 7/15...
  • Page 23 90 Degree Elbow 4021-373 Valve NG 2166-302 18.14 Valve LP 2166-303 Wire Harness 2166-304 Electric Kit to AC Power 4066-073 Power Supply 2326-131 Outdoor Lifestyles by Hearth & Home Technologies Inc. • Carolina-B Owner’s Manual • 4066-501 Rev. G • 7/15...
  • Page 24: Contact Information

    5941237, 6006743, 6019099, 6053165, 6145502, 6374822, 6484712, 6601579, 6769426, 6863064, 7077122, 7098269, 7258116, 7470729, 8147240 or other U.S. and foreign patents pending. 2000-945C Printed in U.S.A. - Copyright 2015 Outdoor Lifestyles by Hearth & Home Technologies Inc. • Carolina-B Owner’s Manual • 4066-501 Rev. G • 7/15...
