Bellini CEB6401-1 Installation And User Manual

60cm

Hide thumbs

Quick Links

60cm Built In Oven

Installation and User manual

Content

Important Safety instructions-------------------- 1

Product description--------------------------------- 3

Installation-------------------------------------------- 4

Oven setting----------------------------------------- 6

Maintenance and cleaning------------------------ 9

Warranty----------------------------------------------- 12

For warranty service call 1300 373 199(Australia)

or 0508 123108(New Zealand) to connect you to

the nearest authorised service centre

20120607 issue2

CEB6401-1

CEB6401-1F

CEB6801-1

CEB6801-1F

CEB6802G

CEB6802G-F

Need help?

Do you have a question about the CEB6401-1 and is the answer not in the manual?

Questions and answers

Summary of Contents for Bellini CEB6401-1

Page 1: Table Of Contents
Important Safety instructions-------------------- 1 Product description--------------------------------- 3 Installation-------------------------------------------- 4 Oven setting----------------------------------------- 6 Maintenance and cleaning------------------------ 9 Warranty----------------------------------------------- 12 CEB6401-1 CEB6401-1F For warranty service call 1300 373 199(Australia) CEB6801-1 or 0508 123108(New Zealand) to connect you to CEB6801-1F the nearest authorised service centre...
Page 2: Important Safety Instructions
Important Safety Instructions This manual explains the proper installation and use of your oven, please read it carefully before using even if you are familiar with the product. The manual should be kept in a safe place for future reference. General Warnings Child Safety If the supply cord is damaged, the cord must be...
Page 3 To reduce the risk of fire, do not place or install Do not use the door as a shelf. this unit in areas where the ventilation or Do not push down when the oven door is open. circulation ducts may become blocked. Make sure there are at least 70mm of space between the Grill back of your oven and the wall.
Page 4: Product Description
Product Description A. Minute Minder Knob D. Heating Indicator Light B. Function Select Knob E. Handle C. Temperature Select Knob F. 3 Layer Glass Door Accessories Accessory Name Picture Quantity Mounting Screws(ST4x25) Baking Pan & Rack 1 Pair Rack Technical data product dimensions electrical min.
Page 5: Installation
Installation The unit panels next to the appliance must be WARNING! Please follow the points below when heat resistant. In the case of veneered wood installing the appliance units, glue must be resistant to a temperature of 120°C. If the appliance is to be installed adjacent to vinyl Use An Authorised Person Installation should be carried out according to the wrapped surfaces, use an installation kit...
Page 6 The unit panels next to the appliance must be heat Cabinet Construction For Your Appliance The sizes of the unit for installing the appliance under resistant. In the case of veneered wood units, glues a worktop or in a column unit are shown in figure. must be resistant to a temperature of 120°C.
Page 7: Oven Setting
Do not close the oven door until the oven is completely dry . Select The Functions Turn the function selector in any direction to the desired function. The oven cavity light will turn on. CEB6401-1 Function Selector CEB6801-1,CEB6802G Function Selector function...
Page 8 CEB6801-1,CEB6802G When the selector knob is in any position other than the “0”position, the oven light Oven Light comes on. Select this function, the air at ambient temperature is distributed inside the oven for Defrost defrosting food more quickly and without proteins adulteration. Both the lower and upper heating elements operate together.
Page 9: Minute Minder
Select The Temperature To set the temperature, turn the temperature selector in a clockwise direction to the desired setting. An indicator light above the temperature selector will come on. A thermostat controls the temperature in your appliance. When the temperature is reached, the heating source switches itself off and the indicator light goes out.
Page 10: Maintenance And Cleaning
Maintenance & Cleaning WARNING! Before cleaning your oven, or performing maintenance, disconnect it from the power supply. Do not use steam cleaners. Do not line the oven bottom with aluminium foil, as the consequent accumulation of heat could compromise the cooking and damage the enamel. To protect against the risk of electrical shock, do not immerse the unit, cord or plug in water or other liquid or sprinkle water to clean the appliance! Do not clean the appliance when it is still hot! The inside and external surface of the oven should preferably...
Page 11 Replacement Of The Oven Light Bulb WARNING! In order to avoid the possibility of an electric shock ensure that the appliance is disconnected from the power supply before replacing the bulb. Set all control knobs to the position”●”/”0” and disconnect the mains plug Unscrew and wash the lamp cover and then wipe it dry Unscrew the light bulb from the socket, replace...
Page 12: Troubleshooting
Step 1 Step 2 Step 3 Step 4 Troubleshooting Faults Causes Remedies The upper crust is dark and Not enough heat from the bottom Use the natural convection position. the lower part too pale Use deeper cake tins. Lower the temperature. Put the cake on a lower shelf.
Page 13: Warranty
Consumer until the expiry of two (2) years (Warranty Period). If within the Warranty Period a manufacturing defect is discovered in the Bellini product or it fails to perform to the Company’s specifications as a result of some defect in materials, components or workmanship (Defect) then the Company will, at its option, repair the Bellini product or supply a replacement Bellini product free of charge.
Page 14 1.10 If you are required to transport the Bellini product to the Company or its service agent, you must ensure it is safely disconnected by a qualified tradesman and securely packed and insured. The Company does not accept any responsibility for loss or damage of the Bellini product prior to it being received by the Company or its service agent.

This manual is also suitable for:

Ceb6801-1f Ceb6401-1f Ceb6802g Ceb6802g-f Ceb6801-1
