Sony DVP-K880P Service Manual

QQ
3 7 63 1515 0
SERVICE MANUAL
TE
L 13942296513
System
Laser: Semiconductor laser
Signal format system: NTSC/PAL
(See page 17 to switch)
Audio characteristics
Frequency response: DVD VIDEO (PCM
96 kHz): 2 Hz to 44 kHz (±1.0 dB)/
DVD VIDEO (PCM 48 kHz): 2 Hz to
22 kHz (±0.5 dB)/CD: 2 Hz to 20 kHz
(±0.5 dB)
Signal-to-noise ratio (S/N ratio): 115 dB
(LINE OUT L/R (AUDIO) jacks only)
Harmonic distortion: 0.003%
Dynamic range: DVD VIDEO: 103 dB/
CD: 99 dB
Wow and flutter: Less than detected value
(±0.001% W PEAK)
www
.
http://www.xiaoyu163.com
Outputs and Input
(Jack name: Jack type/Output level/
Load impedance)
LINE OUT (AUDIO): Phono jack/
2 Vrms/ 10 kilohms
DIGITAL OUT (OPTICAL):
Optical output jack/-18 dBm
(wave length: 660 nm)
DIGITAL OUT (COAXIAL): Phono jack/
0.5 Vp-p/75 ohms
COMPONENT VIDEO OUT
(Y, P
Y: 1.0 Vp-p, P
P /C
R
LINE OUT (VIDEO): Phono jack/
1.0 Vp-p 75 ohms
S VIDEO OUT: 4-pin mini DIN/
Y: 1.0 Vp-p, C: 0.3 Vp-p (PAL),
0.286 Vp-p (NTSC)/75 ohms
MIC 1/2: Phone jacks
x ao u163
y
i
http://www.xiaoyu163.com
2 9
8
RMT-D169A/RMT-D169P/RMT-D170P
Q Q
3 6 7 1 3 1 5
SPECIFICATIONS
/C , P /C ): Phono jack/
B B R R
/C ,
B B
: 0.7 Vp-p/75 ohms
R
co
.
– 1 –
DVP-K870P/K880P
9 4 2 8
Brazilian Model
Singapore Model
Saudi Arabia Model
Singapore Model
Chinese Model
0 5 8 2 9 9 4 2 8
General
Power requirements:
110-240 V AC, 50/60 Hz
Power consumption: 12 W
Dimensions (approx.):
DVP-K870P: 430 × 55.5 × 245.7 mm
DVP-K880P: 430 × 55.5 × 243.7 mm
(width/height/depth) incl. projecting
parts
Mass (approx.): 2.1 kg
Operating temperature: 5°C to 35°C
Operating humidity: 25% to 80%
Supplied accessories
See page 15
Specifications and design are subject to
change without notice.
m
CD/DVD PLAYER
9 9
DVP-K870P
DVP-K880P
