30 minutes before operating the unit. Welcome! Thank you for purchasing this Sony CD/ DVD Player. Before operating the unit, please read this manual thoroughly and retain it for future reference.
ABLE OF CONTENTS About This Manual 4 This Player Can Play the Following Discs 4 Precautions 6 Notes About the Discs 6 Getting Started 7 Unpacking 7 TV Hookups 8 Receiver (Amplifier) Hookups 10 5.1 Channel Surround Hookups 12 Quick Setup 14 Operation Sound Effects (Sound Feedback) 16 Playing Discs 17 Playing Discs...
Audio CDs Audio 8 cm 12 cm 8 cm (CD single) 20 min. 74 min. 20 min. The “DVD VIDEO” logo is a trademark. Region code MODEL NO. DVP–XXXX CD/DVD PLAYER AC 00V 00Hz SONY CORPORATION MADE IN JAPAN 0-000-000-00...
Page 5
To avoid possible damage to the audio system, the consumer should take proper precautions when the analog stereo outputs of the DVD player are connected to an amplification system. To enjoy DTS Digital Surround™ playback, an external 5.1-channel DTS Digital Surround™...
If you have any questions or problems concerning your player, please consult your nearest Sony dealer. IMPORTANT NOTICE Caution: The enclosed DVD player is capable of holding a still video image or on-screen display image on your television screen indefinitely.
Getting Started This section describes how to hook up the player to a TV (with audio/video input connectors) and/or an AV receiver (amplifier). You cannot connect this player to a TV which does not have a video input connector. Be sure to turn off the power of each component before making the connections.
You can use sound imaging to create virtual rear speakers from the sound of built-in TV speakers without using actual rear speakers (TVS: TV Virtual Surround). For details, see page 35. CD/DVD player DIGITAL OUT LINE OUT S VIDEO...
Page 9
Connect the component via the COMPONENT VIDEO OUT connectors using three video connecting cords (not supplied) of the same kind. You will get a better picture. Monitor or projector CD/DVD player with component video input connectors COMPONENT COMPONENT...
Coaxial digital connecting cord (not supplied) (1) COMPONENT VIDEO OUT To S VIDEO To S VIDEO input To audio input To optical digital input To coaxial digital input White (L) Red (R) CD/DVD player To mains INPUT VIDEO S VIDEO AUDIO Receiver (Amplifier) Receiver DIGITAL IN...
Page 11
Notes • You cannot enjoy a picture with an S video signal if your TV does not conform to the S video signal. When your TV does not have an S VIDEO input, connect the component via the LINE OUT VIDEO connector using the video connecting cord (not supplied) instead of the S video cord.
5.1 Channel Surround Hookups With DVDs which contain DTS, Dolby Digital or MPEG audio sound, you can enjoy the surround sound while producing the effect of being in a movie theater or a concert hall using a digital component with a built-in DTS, Dolby Digital or MPEG audio decoder (not supplied).
Page 13
VIDEO WOOFER AUDIO AUDIO AUDIO AUDIO AUDIO SPEAKERS FRONT REC OUT REC OUT MD/DAT TAPE Center speaker INPUT Subwoofer (Active type) : Signal flow CD/DVD player To mains AC OUTLET WOOFER CENTER REAR CENTER – Front speaker Rear speaker (L)
Quick Setup Follow the steps below to make the minimum number of basic adjustments to the player. To skip an adjustment, press >. To return to the previous adjustment, press POWER ./> ENTER Turn on the TV. Switch the input selector on the TV to the player. Press POWER on the player and press ?/1 on the remote.
Page 15
Press M/m to select the item. Set “DOLBY DIGITAL” to “DOLBY DIGITAL” only when you connect an AV receiver (amplifier) having a Dolby Digital decoder to the DIGITAL OUT OPTICAL or COAXIAL connector. AUDIO SETUP AUDIO ATT: AUDIO DRC: STANDARD DOWNMIX: DOLBY SURROUND DIGITAL OUT:...
Operation Sound Effects (Sound Feedback) The player beeps when the following operations are performed. The default setting of the Sound Feedback function is set to off. Operation Operation sound Power is turned on One beep Power is turned off Two beeps H is pressed One beep X is pressed...
Playing Discs This chapter describes how to play a DVD/CD/VIDEO CD. Playing Discs Depending on the DVD or VIDEO CD, some operations may be different or restricted. Refer to the instructions supplied with your disc. POWER Power indicator Turn on your TV. Turn on the TV and switch the input selector on the TV to the player.
Playing Discs To turn on the player Press POWER on the player. The player enters standby mode and the power indicator lights up in red. Then press @/1 on the remote. The player turns on and the power indicator lights up in green. In standby mode, the player also turns on by pressing A on the player or by pressing H.
Searching for a Particular Point on a Disc Z You can locate a particular point on a disc quickly by monitoring the picture or playing back slowly. Note Depending on the DVD/VIDEO CD, you may not be able to do some of the operations described.
Resuming Playback from the Point Where You Stopped the Disc (Resume Play) The player remembers the point where you stopped the disc and when “RESUME” appears on the front panel display, you can resume playback from that point. As long as you do not open the disc tray, Resume Play will work even if the player enters standby mode by pressing @/1 on the remote.
Using the DVD’s Menu Some DVDs have a title menu or a DVD menu that is provided with DVDs only. Using the title menu A DVD is divided into long sections of a picture or a music feature called “titles.” When you play a DVD which contains several titles, you can select the title you want using the title menu.
Playing VIDEO CDs with PBC Functions (PBC Playback) When playing VIDEO CDs with PBC (Play Back Control) functions (Ver. 2.0 discs), you can enjoy simple interactive operations, search functions, and other such operations. PBC Playback allows you to play VIDEO CDs interactively by following the menu on the TV screen.
Using the Front Panel Display Z You can check information about the disc, such as the total number of titles or tracks or remaining time, using the front panel display. When playing back a DVD Displaying information while playing the disc Lights up when Disc Playing...
Page 24
Using the Front Panel Display When playing back a CD/VIDEO CD Displaying information while playing a disc Lights up when the player outputs the Playing signal in NTSC status Current index number format VIDEO CD NTSC TRACK INDEX PGM SHUFFLE REPEAT1 Disc type Current...
Using Various Functions with the Control Menu This chapter describes how to play discs in various modes and how to use the convenient features of the on- screen menu (Control Menu). Using the Control Menu Display Using the Control Menu display, you can select the starting point, play scenes in any order you like, change the viewing angles, make TV Virtual Surround settings, and other such operations.
Page 26
Using the Control Menu Display Select the item you want using M/m. 1 2 ( 2 7 ) 1 8 ( 3 4 ) 1 : 3 2 : 5 5 1: ENGLISH Items Selected SUBTITLE Select: ENTER item Press ENTER. 1 2 ( 2 7 ) PLAY 1 8 ( 3 4 )
Control Menu Item List TITLE (DVD only) (page 28)/ SCENE (VIDEO CD during PBC playback only) (page 28)/ TRACK (VIDEO CD only) (page 28) CHAPTER (DVD only) (page 28)/ INDEX (VIDEO CD only) (page 28) TRACK (CD only) (page 28) INDEX (CD only) (page 28) You can search for a point on the disc by selecting the title, chapter, track, index or scene.
Searching for a Title/Chapter/Track/Index/Scene You can search the disc by title, chapter, track, index or scene. Select “TITLE,” “CHAPTER,” “TRACK,” “INDEX” or “SCENE” after pressing DISPLAY. When you play back a DVD, “TITLE” and “CHAPTER” are displayed. When you play back a VIDEO CD/CD, “TRACK” and “INDEX”...
Checking the Playing Time and Remaining Time You can check the playing time and remaining time of the current title, chapter or track and the total playing time or remaining time of the disc. Press DISPLAY. Then press TIME/TEXT on the remote to change the time information.
Selecting a Starting Point Using the Time Code Input the time code using the number buttons, then press ENTER. The player starts playback at the selected time code. To cancel the number, press CLEAR before pressing ENTER. To cancel while making a selection Press ORETURN.
Changing the Sound If the DVD is recorded with multilingual tracks, you can select the language you want while playing the DVD. If the DVD is recorded in multiple audio formats (PCM, Dolby Digital, MPEG or DTS), you can select the audio format you want while playing the DVD.
Page 32
Changing the Sound Displaying the audio information of the disc When you select “AUDIO,” the channels being played are displayed on the screen. In Dolby Digital format, multiple signals ranging from monaural to 5.1 channel signals can be recorded on a DVD.
•DTS “LFE” is always enclosed in a solid line regardless of the LFE signal component being output. 1: ENGLISH PROGRAM FORMAT DTS 3/2.1 AUDIO Select: ENTER •Dolby Digital Karaoke format (For details, see page 46.) 1: ENGLISH PROGRAM FORMAT DOLBY DIGITAL 3/2 KARAOKE AUDIO Select:...
Changing the Angles With DVDs on which various angles (multi-angles) for a scene are recorded, you can change the angles. For example, while playing a scene of a train in motion, you can display the view from either the front of the train, the left window of the train or from the right window without having the train’s movement interrupted.
TV Virtual Surround Sound Settings (TVS) When you connect a stereo TV or 2 front speakers, TV Virtual Surround lets you enjoy surround sound effects by using sound imaging to create virtual rear speakers from the sound of the front speakers (L: left, R: right) without using actual rear speakers.
TV Virtual Surround Sound Settings (TVS) TVS (TV Virtual Surround) STANDARD Uses sound imaging to create virtual rear speakers from the sound of the front speakers (L, R) without using actual rear speakers. The virtual speakers are reproduced as shown in the illustration below. Use this setting when you want to use TVS with 2 separate speakers and retain the sound quality.
Displays of each item By pressing DISPLAY repeatedly, you can display either “BIT RATE” or “LAYER,” whichever was selected in “ADVANCED.” BIT RATE BIT RATE 384kbps Mbps When you play MPEG audio sound tracks BIT RATE kbps 1000 Mbps Bit rate refers to the amount of video/audio data per second in a disc.
Page 38
Locking Discs (Custom Parental Control) Select “ON,” using M/m, then press ENTER. x If you have not entered a password The display for entering a password appears. CUSTOM PARENTAL CONTROL Enter a new 4-digit password, then press ENTER To return, press RETURN x When you have already registered a password The display for confirming the password appears.
Creating Your Own Program (Program Play) You can play the contents of the disc in the order you want by arranging the order of the titles, chapters or tracks on the disc and create your own program. One program can be stored in the player and contain up to 99 titles, chapters and tracks.
Page 40
Creating Your Own Program (Program Play) x When playing a VIDEO CD or CD Select the track you want to program. Total time of the programmed tracks 0:15:30 PROGRAM ALL CLEAR – – 1. TRACK 0 2 2. TRACK 3. TRACK – – 4.
Playing in Random Order (Shuffle Play) You can have the player “shuffle” titles, chapters or tracks and play them in a random order. Subsequent “shuffling” may produce a different playing order. Select “SHUFFLE” after pressing DISPLAY. When you select a shuffle mode other than “OFF,” the “SHUFFLE” indicator lights up in green.
Playing Repeatedly (Repeat Play) You can play all of the titles or tracks on a disc or a single title, chapter or track repeatedly. In Shuffle or Program Play mode, the player repeats the titles or tracks in the shuffled or programmed order. You cannot perform Repeat Play during PBC playback of VIDEO CDs (page 22).
Repeating a Specific Portion (A-B Repeat) You can play a specific portion of a title, chapter or track repeatedly. This function is useful when you want to do such things as memorize lyrics. During PBC Playback of VIDEO CDs (page 22), this function is available only while playing moving pictures.
Repeating a Specific Portion (A-B Repeat) When you reach the ending point (point B), press ENTER again. The set points are displayed and the player starts repeating this specific portion. “A-B” appears on the front panel display during A-B repeat play. 1 2 ( 2 7 ) PLAY 1 8 ( 3 4 )
Enjoying Karaoke This chapter describes how to play discs in karaoke mode and how to use the various karaoke features . Using Karaoke You can enjoy karaoke (singing along with a disc) by setting this player to karaoke mode. You can connect up to two microphones (not supplied) to the player.
Page 46
Using Karaoke Adjusting the microphone Set the MIC 1/2 LEVEL control of the MIC connector to MIN. Plug a microphone (not supplied) into the MIC connector. When a microphone is connected to the MIC 1 or 2 connector, the player enters karaoke mode. Set the ON/OFF switch on the microphone to ON and turn the MIC 1/2 LEVEL control to adjust the microphone volume.
Using the Karaoke Control Menu Display You can use the Karaoke Control Menu display when the player is in karaoke mode. Using the Karaoke Control Menu display, you can enjoy karaoke features such as changing the key, applying effects and programming the next titles and tracks.
Changing the Key (Key Control) You can change the key to suit your vocal range. While playing karaoke, press one of the KEY CONTROL buttons repeatedly to find the key that suits your vocal range. KEY CONTROL indicators These indicators light up when you select one of the keys.
Applying the Surround Effect (Karaoke Surround) The karaoke surround function gives surround effects to the accompaniment sound. Select “KARAOKE SURROUND” in the Karaoke Control Menu display. Select the karaoke surround mode using M/m, and then press ENTER. To cancel the karaoke surround, select “OFF”...
Playing Karaoke with Any Stereo Disc (Karaoke Pon) You can enjoy karaoke with a stereo-recorded disc, even if it is a non-karaoke disc, by reducing the sound of the vocals. KARAOKE PON Press KARAOKE PON in karaoke mode. To cancel the Karaoke Pon function Press KARAOKE PON again.
You can turn the Vocal function on and off using “VOCAL” in the Karaoke Control Menu display Select “VOCAL” in the Karaoke Control Menu display (page 47), select “ON” or “OFF” using M/m, and then press ENTER. VOCAL Select: Cancel: ENTER You can select the vocals When the Vocal function is set to on, you can change the guide...
Selecting the Vocals (Vocal Select) When playing a VIDEO CD or CD To select the vocal track, press VOCAL SELECT during playback. Each time you press VOCAL SELECT, the output channel changes as follows: L+R (same sound is output from both speakers) STEREO When playing a Super VCD To select the vocal track, press VOCAL SELECT during...
Turning the Guide Melody On and Off (Guide Melody) You can listen to the guide melody. Select “GUIDE MELODY” in the Karaoke Control Menu display. To turn the guide melody on, select “ON” using M/m, and then press ENTER. To cancel the guide melody, select “OFF”...
Reserving Karaoke (Reserve) You can select and reserve up to 24 tracks/titles when the player is in karaoke mode. You can reserve additional tracks/titles even if somebody is performing karaoke. Once the track or title is performed, it disappears from the reserve list.
Page 55
Notes • You cannot do Shuffle Play and Repeat Play while using this function. The Shuffle Play or Repeat Play setting is canceled when you start reserving tracks or titles. • If the reserved title or track does not exist, “Reserve play of title** is prohibited.”...
Settings and Adjustments This chapter describes how to set and adjust the player using the on-screen setup menu. Most settings and adjustments are required to be set when you first use the player. Using the Setup Display Using the setup display, you can do the initial setup, adjust the picture and sound and set the various outputs.
Page 57
Press M/m to select “CUSTOM,” then press ENTER. The setup display appears. LANGUAGE SETUP OSD: ENGLISH DVD MENU: ENGLISH AUDIO: ORIGINAL SUBTITLE: ENGLISH Select the main item you want using M/m. LANGUAGE SETUP OSD: DVD MENU: AUDIO: Main item SUBTITLE: Press ENTER.
Setup Display Item List The default settings are underlined. LANGUAGE SETUP (page 59) ENGLISH CHINESE 1 CHINESE 2 DVD MENU ENGLISH CHINESE JAPANESE FRENCH GERMAN ITALIAN SPANISH DUTCH DANISH SWEDISH FINNISH NORWEGIAN PORTUGUESE RUSSIAN OTHERS , AUDIO ORIGINAL (same as DVD MENU) AUDIO FOLLOW SUBTITLE (same as DVD MENU)
Setting the Display Language or Sound Track (LANGUAGE SETUP) “LANGUAGE SETUP” allows you to set various languages for the on-screen display or sound track. The default settings are underlined. Select “LANGUAGE SETUP” in the setup display. LANGUAGE SETUP OSD: DVD MENU: AUDIO: SUBTITLE: To set, press...
Settings for the Display (SCREEN SETUP) “SCREEN SETUP” allows you to set the display according to the playback conditions. The default settings are underlined. Select “SCREEN SETUP” in the setup display. SCREEN SETUP TV TYPE: SCREEN SAVER: BACKGROUND: JACKET PICTURE To set, press , then ENTER...
Custom Settings (CUSTOM SETUP) “CUSTOM SETUP” allows you to set the playback conditions. The default settings are underlined. Select “CUSTOM SETUP” in the setup display. CUSTOM SETUP COLOR SYSTEM: AUTO PLAY: DIMMER: PAUSE MODE: PARENTAL CONTROL TRACK SELECTION: To set, press , then To quit, press DISPLAY...
Page 62
Custom Settings (CUSTOM SETUP) Limiting playback by children (Parental Control) Playback of some DVDs can be limited depending on the age of the users. The “Parental Control” function allows you to set a playback limitation level. Select “CUSTOM SETUP” in the setup display. CUSTOM SETUP COLOR SYSTEM: AUTO PLAY:...
Page 63
Select a geographic area as the playback limitation level standard using M/m, then press ENTER. When you select “OTHERS,,” select and enter the standard code in the table on the next page using the number buttons. CUSTOM SETUP PARENTAL CONTROL LEVEL: STANDARD: CHANGE PASSWORD...
Page 64
Custom Settings (CUSTOM SETUP) Standard Code number Argentina 2044 Australia 2047 Austria 2046 Belgium 2057 Brazil 2070 Canada 2079 Chile 2090 China 2092 Denmark 2115 Finland 2165 France 2174 Germany 2109 Hong Kong 2219 India 2248 Indonesia 2238 Italy 2254 Japan 2276 Korea...
Settings for the Sound (AUDIO SETUP) “AUDIO SETUP” allows you to set the sound according to the playback conditions. The default settings are underlined. Select “AUDIO SETUP” in the setup display. AUDIO SETUP AUDIO ATT: AUDIO DRC: DOWNMIX: DOLBY SURROUND DIGITAL OUT: DOLBY DIGITAL: MPEG:...
Page 66
Settings for the Sound (AUDIO SETUP) Setting the digital output signal Switches the methods of outputting audio signals when you connect, 1. a digital component such as a receiver (amplifier) having a digital connector, 2. an audio component having a built-in decoder (Dolby Digital, MPEG or DTS), 3.
If you experience any of the following difficulties while using the player, use this troubleshooting guide to help remedy the problem. Should any problem persist, consult your nearest Sony dealer. Power The power is not turned on. , Check that the mains lead is connected securely.
Page 68
Troubleshooting Sound There is no sound. , Check that the player is connected securely. , The audio connecting cord is damaged. Replace it with a new one. , Make sure you connect the player to the audio input connectors on the receiver (amplifier). (page , Make sure you turn on the TV and the receiver (amplifier).
Page 69
, The self-diagnosis function was activated. See the table on page 70. The disc tray does not open and “LOCKED” is displayed on the front panel display. , Contact your Sony dealer or local authorized Sony service facility.
, Open the disc tray and insert the disc correctly. •To prevent a malfunction, the player has performed the self-diagnosis function. , When you contact your Sony dealer or local authorized Sony service facility, give the 5-character service number. (example: E 61 10)
Specifications CD/DVD player Laser Semiconductor laser Signal format system NTSC/PAL (See page 9 to switch.) Audio characteristics Frequency response DVD (PCM 96 kHz): 2 Hz to 44 kHz (±1 dB)* DVD (PCM 48 kHz): 2 Hz to 22 kHz (±0.5 CD: 2 Hz to 20 kHz (±0.5 dB)
Glossary Bit rate (page 36) Value indicating the amount of video data compressed in a DVD per second. The unit is Mbps (Mega bit per second). 1 Mbps indicates that the data per second is 1,000,000 bits. The higher the bit rate, the larger the amount of data.
Page 73
TV Virtual Surround (TVS) (page 35) Technology from Sony developed to produce surround sound for home use using just a stereo TV. Designed to work with the sound characteristics of your TV, this technology brings the excitement of surround sound to your home using nothing more than your stereo TV’s...
Language Code List For details, see page 33, 59. Code Language Code Language 1027 Afar 1186 Scots Gaelic 1194 Galician 1028 Abkhazian 1032 Afrikaans 1196 Guarani 1203 Gujarati 1039 Amharic 1209 Hausa 1044 Arabic 1045 Assamese 1217 Hindi 1051 Aymara 1226 Croatian 1229...
Index to Parts and Controls Refer to the pages indicated in parentheses for details. Front Panel qs qd qf qg qh 1 POWER button and indicator (17) Disconnects the power of the player or places the player in standby mode. 2 MIC 1 and 2 LEVEL controls (45) Adjusts the volume of the microphone connected to the MIC 1 and 2 connectors.
Page 76
Index to Parts and Controls Rear Panel DIGITAL OUT LINE OUT S VIDEO PCM/DTS/MPEG/ DOLBY DIGITAL R – AUDIO 1 – L VIDEO 1 COAXIAL OPTICAL R – AUDIO 2 – L VIDEO 2 1 DIGITAL OUT COAXIAL connector (10, 12) Connect to an audio component using a coaxial digital connecting cord.
Page 77
Remote 1 TIME/TEXT button (23) Displays the playing time of the disc, etc., on the front panel display. 2 ZOPEN/CLOSE button (18) Opens or closes the disc tray. 3 Number buttons Selects the items or settings. 4 CLEAR button (28, 40) Press to return to continuous play, etc.
