This manual is furnished with each new TENNANT Model 5700. It provides necessary operating and preventive maintenance instructions. Read this manual completely and understand the machine before operating or servicing it. This machine will provide excellent service. However, the best results will be obtained at minimum costs if: The machine is operated with reasonable care.
- - Wear eye and ear protection when This machine is designed solely for scrubbing dirt using pressurized air or water. and dust in an indoor environment. Tennant does - - Disconnect battery connections before not recommend using this machine in any other working on machine.
Page 6
ON THE UNDERSIDE OF THE SOLUTION OPERATOR CONSOLE. TANK COVER. 10066 FLAMMABLE SPILLS LABEL - - LOCATED ON THE OPERATOR CONSOLE. BATTERY CHARGING LABEL - - LOCATED ON THE UNDERSIDE OF THE SOLUTION TANK. 5700 MM400 (9- -96) Home Find... Go To..
Tennant representative. - Order parts and supplies directly from your authorized Tennant representative. Use the parts manual provided when ordering parts. - After operation, follow the recommended daily and hourly procedures stated in the MAINTENANCE CHART.
Parking brake (option) J. Recovery tank drain hose K. Solution tank hose L. Support arm M. Stop arm N. Batteries O. Scrub head P. Scrub brush access cover Q. Scrub brush idler door 5700 MM400 (1- -95) Home Find... Go To..
Recovery tank full Circuit breaker #2 Scrub brushes down and on Circuit breaker #3 Scrub brushes up and off Circuit breaker #4 Battery charge Circuit breaker #5 Scrub brush pressure Circuit breaker #6 5700 MM400 (1- -95) Home Find... Go To..
L. Machine on light M. Circuit breakers N. Squeegee lever O. Power kill switch (option) P. Steering height adjustment latch Q. Solution tank hose R. Recovery tank drain hose S. Speed reduction knob (option) 5700 MM400 (2- -98) Home Find... Go To..
Backward: Rotate the handles toward you. Turning: Push the machine in the direction of the turn with the steering handles. The machine will turn on the swivel casters. 5700 MM400 (9- -96) Home Find... Go To..
The power wand switch turns on and off the power wand solution system. On: Press the top of the switch. The switch will light up. Off: Press the bottom of the switch. 5700 MM400 (9- -96) Home Find... Go To..
NOTE: The reading on the battery discharge indicator is not accurate when the machine is first powered on. Operate the machine a few minutes before reading the charge level of the batteries. 5700 MM400 (9- -96) Home Find... Go To..
SCRUB BRUSHES DOWN LIGHT The scrub brushes down light comes on when the scrub brushes are lowered enough to touch the floor. The light goes off when the scrub brushes are raised off the floor. 5700 MM400 (9- -96) Home Find... Go To..
MACHINE ON LIGHT The machine on light comes on when the machine is powered on with the on-off key switch. The machine on light goes off when the machine is powered off. 5700 MM400 (3- -97) Home Find... Go To..
The speed reduction knob adjusts the machine’ s maximum travel speed. To reduce the maximum travel speed, turn the knob to the left. To increase the maximum travel speed, turn the knob to the right. 5700 MM400 (3- -97) Home Find... Go To..
Heavy duty vacuum fan 25 A Machine propel 10 A Machine controls 20 A Scrub brush 35 A Heavy duty disk scrub brush 20 A Scrub brush 35 A Heavy duty disk scrub brush 5700 MM400 (3- -97) Home Find... Go To..
STOP ARM The stop arm prevents the solution tank from fully closing when the tank is lowered. Push the arm in to lower the solution tank completely. 5700 MM400 (9- -95) Home Find... Go To..
PARKING BRAKE (OPTION) The parking brake is controlled with a foot pedal and a release lever located by the squeegee. Set: Push down on the foot pedal. Release: Pull up on the release lever. 5700 MM400 (1- -95) Home Find... Go To..
800 mm (32 in) with the model 800, and the 900 mm (36 in) with the model 900. The two available brush types are disk and cylindrical. 5700 MM400 (1- -95) Home Find... Go To..
- Disc brushes: Check and make sure the scrub head skirt touches the floor all the way around the scrub head. - Check the squeegee for proper deflection. Check the squeegee blade for wear, rounded edges, nicks, or cuts. 5700 MM400 (1- -95) Home Find... Go To..
FILLING THE TANKS 1. Start the machine. 2. Drive the machine to the filling site. FOR SAFETY: Before leaving or servicing machine, stop on level surface, and turn off machine. 5700 MM400 (3- -96) Home Find... Go To..
Page 23
Make sure the ESt system is If you do not want to use the ESt system, make sure the ESt system is off. DO NOT fill the recovery tank. 5700 MM400 (3- -96) Home Find... Go To..
Page 24
For specific recommendations, contact your Tennant representative. WARNING: Flammable materials can cause an explosion or fire. Do not use flammable materials in tank(s). 5700 MM400 (3- -96) Home Find... Go To..
D If you see poor scrubbing performance, stop scrubbing and refer to MACHINE TROUBLESHOOTING. 1. Start the machine. 2. Drive the machine to the area to be scrubbed. 3. Lower the squeegee to the floor with the squeegee lever. 5700 MM400 (9- -95) Home Find... Go To..
Page 26
Reactive metals and some detergents form explosive hydrogen gas. Contact Tennant Company for appropriate detergent selection. 7. Adjust brush pressure for cleaning application with the scrub brushes switch, while watching the brush pressure gauge. 5700 MM400 (3- -97) Home Find... Go To..
15 to 20 minutes. Then make a second pass scrubbing with the squeegee down. FOR SAFETY: When using machine, go slow on inclines and slippery surfaces. 5700 MM400 (3- -97) Home Find... Go To..
STOP SCRUBBING 1. Release the steering handles. 2. Raise the scrub brushes with the scrub brushes switch until the scrub brushes down light goes off. 3. Raise the squeegee with the squeegee lever. 5700 MM400 (1- -95) Home Find... Go To..
3. Turn the machine power off. FOR SAFETY: Before leaving or servicing machine, stop on level surface, and turn off machine. 4. Set the parking brake, if your machine has this option. 5700 MM400 (3- -96) Home Find... Go To..
Page 30
8. ESt mode: When the solution tank has completely drained, replace the drain hose plug in the solution tank drain hose and place the solution tank drain hose back onto the mounting clip on the machine. 5700 MM400 (3- -96) Home Find... Go To..
Page 31
11. Lift the solution tank to reach the recovery tank. 12. Flush out the inside of the recovery tank with clean water. NOTE: Do not use steam to clean the tank. 5700 MM400 (3- -96) Home Find... Go To..
Page 32
Insert the filter back in to the recovery tank when finished. NOTE: Be sure the vacuum filter is dry before reinstalling it in the machine. 5700 MM400 (9- -98) Home Find... Go To..
Page 33
17. Pull up on the support arm and lower the solution tank. Push the stop arm in to completely lower the solution tank. 18. Cylindrical scrub head: Remove and clean the debris trough. Place the trough back in the scrub head. 5700 MM400 (3- -97) Home Find... Go To..
3. Set the parking brake, if your machine has that option. FOR SAFETY: Before leaving or servicing machine, stop on level surface, set parking brake (if so equipped), turn off machine, and remove key. 5700 MM400 (3- -97) Home Find... Go To..
- Check for wire, string, or twine wrapped around the scrub brushes. - Check the squeegee for wear or damage. - Drain and clean the recovery tank. - ESt machines: Drain and clean the solution tank. 5700 MM400 (3- -97) Home Find... Go To..
Drive the machine slowly on inclines. FOR SAFETY: When using machine, go slow on inclines and slippery surfaces. The maximum rated climb and descent incline with empty tanks is 8_ , with full tanks is 6_ . 5700 MM400 (3- -97) Home Find... Go To..
Tires slip on oily or waxed floors Check with TENNANT representative for advice Uneven brush down pressure Uneven brush down pressure Level scrub head Broken brush drive belts on cylindrical scrub head, replace belt 5700 MM400 (3- -97) Home Find... Go To..
1. Turn the machine power off. FOR SAFETY: Before leaving or servicing machine, stop on level surface, and turn off machine. 2. Set the parking brake, if your machine has this option. 5700 MM400 (3- -97) Home Find... Go To..
Page 39
4. Put together the wand and the wand hose. 10080 5. Connect the vacuum wand hose and the squeegee suction hose with the adapter. 6. Turn the machine power on. 5700 MM400 (3- -97) Home Find... Go To..
Page 40
7. Lower the squeegee with the squeegee lever to turn the vacuum system on. 8. Vacuum the floor. 06599 9. When finished, raise the squeegee to shut off the vacuum. 10.Turn the machine power off. 5700 MM400 (3- -97) Home Find... Go To..
Page 41
OPERATION 11. Remove the vacuum hose from the squeegee suction hose. 12. Reconnect the squeegee suction hose to the top of the squeegee. 5700 MM400 (3- -97) Home Find... Go To..
2. Set the parking brake, if your machine has this option. 3. Remove the squeegee suction hose from the top of the squeegee. 5700 MM400 (3- -97) Home Find... Go To..
Page 43
Push the connector in until it stops. Pull on the hose to make sure it is connected. 6. Attach the other ends of the solution and vacuum hoses to the power wand. 7. Turn the machine power on. 5700 MM400 (3- -97) Home Find... Go To..
Page 44
Scrub the floor with the brush side of the cleaning tool. 11. Vacuum up the solution by turning over the cleaning tool so the squeegee side is down. 06202 5700 MM400 (3- -97) Home Find... Go To..
Page 45
06604 12. When finished, switch the power wand off. 13. When finished, raise the squeegee to shut off the vacuum. 14. Disconnect the solution hose from the machine. 5700 MM400 (3- -97) Home Find... Go To..
Page 46
16. Disconnect the other ends of the solution and vacuum hoses from the power wand. 17.Turn the machine power off. 18. Reconnect the squeegee suction hose to the squeegee. 5700 MM400 (3- -97) Home Find... Go To..
The rear casters each have one grease fitting on the caster swivel. Lubricate the caster with a grease gun containing Lubriplate EMB grease (TENNANT part no. 01433--1) every 100 hours of machine operation. TRANSAXLE Check the transaxle lubricant level every 1000 hours of operation by removing one of the orange filler plugs.
2. Turn the machine power off and set the parking brake if your machine has this option. FOR SAFETY: Before leaving or servicing machine, stop on level surface, and turn off machine. 5700 MM400 (3- -97) Home Find... Go To..
Page 50
6. Plug the battery charger into the wall outlet. NOTE: If the red “ ABNORMAL CYCLE”lamp lights when the TENNANT charger is plugged into a wall outlet, the charger cannot charge the battery and there is something wrong with the battery.
The carbon brushes on the vacuum fan motor should be inspected after every 500 hours of machine operation. The carbon brushes on the scrub brush motors and propelling motor should be inspected after every 1000 hours of machine operation. 5700 MM400 (3- -97) Home Find... Go To..
5. Pull the strap tight through the buckle, and attach the strap end to the skirt using the hook and loop fastener. 6. Raise the scrub head. 5700 MM400 (3- -97) Home Find... Go To..
6. Pull the strap tight through the buckle, and attach the strap end to the skirt using the hook and loop fastener. 7. Adjust the skirt as stated in ADJUSTING THE SCRUB HEAD SKIRT. 5700 MM400 (3- -97) Home Find... Go To..
3. Remove the retainer strip and hardware. 4. Replace the old skirt with a new skirt and mount in place with the retainer strip and hardware. 5700 MM400 (3- -97) Home Find... Go To..
1. Lower the scrub head. 2. Turn the machine power off. FOR SAFETY: Before leaving or servicing machine, stop on level surface, and turn off machine. 3. Remove the machine front cover. 5700 MM400 (3- -97) Home Find... Go To..
Page 56
5. Disconnect the wire harness. 6. Disconnect the scrub head from the guide by removing the clevis pin. 7. Disconnect the lift arms from the scrub head by removing the two clevis pins. 5700 MM400 (3- -97) Home Find... Go To..
2. Check the level of the scrub head by measuring the distance from the top of the scrub head, to the floor at all four corners. The scrub head should measure the same on all four corners. 5700 MM400 (3- -97) Home Find... Go To..
Page 58
Tighten the jam nut. 4. Install the machine front cover. 5. Cylindrical scrub head: Check the brush pattern as described in CHECKING AND ADJUSTING CYLINDRICAL BRUSH PATTERN. 5700 MM400 (3- -97) Home Find... Go To..
FOR SAFETY: Before leaving or servicing machine, stop on level surface, and turn off machine. 3. Open the access cover on either corner of the scrub head. 5700 MM400 (3- -97) Home Find... Go To..
Page 60
9. Lift the scrub brush into the drive plug. 10. Check to make sure the brush is securely mounted on the brush drive hub. 11. Close the scrub head access cover. 12. Repeat for the other brush. 5700 MM400 (3- -97) Home Find... Go To..
4. Pull the brush out of the scrub head. 5. With the double row end of the brush towards you, guide the brush onto the drive hub. NOTE: Use the double rows on the idler end of the brush. 5700 MM400 (3- -97) Home Find... Go To..
A polish mark will remain on the floor. 5. Raise the scrub head and move the machine away from the chalked area. Turn the machine power off. 5700 MM400 (3- -97) Home Find... Go To..
Page 63
Pull the idle plug off the brush. B. While holding the flat end of the idler shaft with a wrench, loosen the mounting screw on the outside of the idler door. 5700 MM400 (3- -97) Home Find... Go To..
The outside of the tank can be cleaned with vinyl cleaner. Rinse and wipe off the sensors daily on machines with optical sensors installed inside the recovery tank. 5700 MM400 (3- -97) Home Find... Go To..
A vacuum fan screen is located in the solution tank, for machines below serial number 006956. Remove and clean this screen daily. For machines serial number 006956 and above, a filter is located in the recovery tank. 5700 MM400 (9- -98) Home Find... Go To..
FOR SAFETY: Before leaving or servicing machine, stop on level surface, and turn off machine. 3. Remove the squeegee suction hose from the squeegee. 5700 MM400 (3- -97) Home Find... Go To..
2. Lower the squeegee. 3. Drive the machine forward, then turn the machine power off. 4. Look at the deflection of the squeegee blade, over the full length of the squeegee blade. 5700 MM400 (3- -97) Home Find... Go To..
Turn the squeegee deflection cams clockwise to increase blade deflection. 6. Drive the machine forward again to check the squeegee blade deflection. 7. Readjust the squeegee blade deflection if necessary. 5700 MM400 (3- -97) Home Find... Go To..
FOR SAFETY: Before leaving or servicing machine, stop on level surface, and turn off machine. 3. Loosen the two retention knobs, one at each end on the squeegee. 5700 MM400 (3- -97) Home Find... Go To..
3. Remove the squeegee from the machine. See REMOVING THE SQUEEGEE ASSEMBLY. 4. Remove the rear squeegee blade and retainer. See REPLACING OR ROTATING THE REAR SQUEEGEE BLADE. 5700 MM400 (3- -97) Home Find... Go To..
Page 71
10. Install the squeegee assembly on the squeegee pivot. See INSTALLING THE SQUEEGEE ASSEMBLY. 11. Adjust the squeegee blade leveling and deflection as stated in LEVELING THE SQUEEGEE and ADJUSTING SQUEEGEE BLADE DEFLECTION. 5700 MM400 (3- -97) Home Find... Go To..
STATIC DRAG CHAIN A static drag chain prevents the buildup of static electricity in the machine. The chain is attached to the transaxle. Make sure the chain is always touching the floor. 5700 MM400 (3- -97) Home Find... Go To..
FOR SAFETY: When servicing machine, block machine tires before jacking machine up. FOR SAFETY: When servicing machine, jack machine up at designated locations only. Block machine up with jack stands. 5700 MM400 (3- -97) Home Find... Go To..
4. Start the solution flow. Start the power wand solution system or ESt system to circulate the washer solution through the components. 5. The washer solution does not need to be drained from the solution tank. 5700 MM400 (3- -97) Home Find... Go To..
Recovery tank capacity to full sensor 114 L (30 gal) Recovery tank capacity to top of tank 152 L (40 gal) Transaxle 90 weight gear lubricant capacity 1.42 L (1.5 qt) GVWR 690 kg (1520 lb) 5700 MM400 (3- -97) Home Find... Go To..
Location Type Size Pressure Front (2) Pneumatic 4.10/3.5 -- 6 415 to 450 kPa (60 to 65 psi) Front (2) Solid (option) 1.2/3.0--6 Rear, casters (2) Solid, non-marking 5 x 2 in 5700 MM400 (3- -97) Home Find... Go To..
1065 mm (42 in) 720 mm (28.25 in) 1155 mm (45.5 in) 1600 mm (63 in) 1625 mm (64 in) 1660 mm (65.25 in) 1690 mm (66.5 in) 1090 mm (43 in) 10189 MACHINE DIMENSIONS 5700 MM400 (3- -97) Home Find... Go To..
This manual is furnished with each new TENNANT Model 5700. This manual consists of the How To Use This Manual; Standard Parts; Options; Breakdowns; and Cross Reference sections. MACHINE DATA Please fill out at time of installation for future reference.
-- Find important machine information for ordering correct repair parts. -- Find TENNANT part numbers. -- Order TENNANT parts and supplies. IMPORTANT INFORMATION When placing an order for parts, the machine model and machine serial number are important.
Ñ -- indicates the part is an assembly. -- indicates the part is included in the assembly listed just before it. -- TENNANT Part No. -- column lists the TENNANT part number for the part. -- Serial Number -- column indicates the set of machines the part number is applicable to.
Do not order by page number or reference number. If you are not able to find the part number, call your TENNANT representative for help or send the old part as a sample. 4. Determine the quantity of the part you need.
If parts received are suspected to be incorrect or defective, please contact the TENNANT representative from whom you ordered the part. They will give authorization for return and/or handle replacement shipments when required.
Scr Panssm 4X0.7 35 11777 (000000-- Pad, Strip 18D Brown 370093 (000000-- Pad, Strip--Hd 18D Black 11778 (000000-- Pad, Scrub 18D Blue 11780 (000000-- Pad, Buff 18D Red 11781 (000000-- Pad, Polish 18D White 5700 MM400 (9- -99) Home Find... Go To..
Page 98
STANDARD PARTS Fig. 5 - - Main Frame and Drive Group 2-10 5700 MM400 (9- -99) Home Find... Go To..
Page 99
STANDARD PARTS 10016 - - 5700, NA, JP Fig. 5 - - Main Frame and Drive Group Tennant Machine Serial Ref. Description Qty. Part No. Number 222029 (000000-- Frame, Main 222037 (000000-- Transaxle Motor Assy 22Lg (See Breakdowns) Ñ 222371 (000000-- Motor,Elec 0.5Hp36V.Dc,2000Rpm (See Breakdowns)
Page 100
STANDARD PARTS Fig. 6 - - Tire and Rim Assembly, Black 2-12 5700 MM400 (2- -98) Home Find... Go To..
Page 101
Machine Serial Ref. Description Qty. Part No. Number 78572 (000000-- Tire and Rim Assembly, Black Ñ 374049 (000000-- Tire, 4.10/3.5--6, Black 04658 (000000-- Tube, Inner 04657 (000000-- 11109 (000000-- Nut, Wheel 2-13 5700 MM400 (9- -99) Home Find... Go To..
Page 102
STANDARD PARTS Fig. 7 - - Scrub Head Lift Group 2-14 5700 MM400 (2- -98) Home Find... Go To..
Page 103
STANDARD PARTS 10018 - - 5700, EE, NA, JP Fig. 7 - - Scrub Head Lift Group Tennant Machine Serial Ref. Description Qty. Part No. Number 222027 (000000-- Arm, Lift, Head 222099 (000000-- Spacer, Lift Arm 222028 (000000-- Sleeve, .344B .62D1.3 Bronze...
Page 104
STANDARD PARTS Fig. 8 - - Model 700D Scrub Head Kit, 700 mm (28 in) 2-16 5700 MM400 (2- -98) Home Find... Go To..
Page 105
STANDARD PARTS 10440 - - 5700, XP, XPS, 28in, NA, JP Fig. 8 - - Model 700D Scrub Head Kit, 700 mm (28 in) Tennant Machine Serial Ref. Description Qty. Part No. Number 222012 (000000-- Scrub Head Kit 700D 5700 Ñ...
Page 106
STANDARD PARTS Fig. 9 - - Model 800D Scrub Head Kit, 800 mm (32 in) 2-18 5700 MM400 (2- -98) Home Find... Go To..
Page 107
STANDARD PARTS 10440 - - 5700, XP, XPS, 32in, NA, JP Fig. 9 - - Model 800D Scrub Head Kit, 800 mm (32 in) Tennant Machine Serial Ref. Description Qty. Part No. Number 222013 (000000-- Scrub Head Kit 800D 5700 Ñ...
Page 108
STANDARD PARTS Fig. 10 - - Model 900D Scrub Head Kit, 900 mm (36 in) 2-20 5700 MM400 (2- -98) Home Find... Go To..
Page 109
STANDARD PARTS 10064 - - 5700, XP, XPS, 36in, NA, JP Fig. 10 - - Model 900D Scrub Head Kit, 900 mm (36 in) Tennant Machine Serial Ref. Description Qty. Part No. Number 222014 (000000-- Scrub Head Kit 900D 5700 Ñ...
Page 110
STANDARD PARTS Fig. 11 - - Model 800D Heavy Duty Scrub Head Kit, 800 mm (32 in) 2-22 5700 MM400 (2- -98) Home Find... Go To..
Page 111
STANDARD PARTS 10064 - - 5700, XP, XPS, HD32in, NA, JP Fig. 11 - - Model 800D Heavy Duty Scrub Head Kit, 800 mm (32 in) Tennant Machine Serial Ref. Description Qty. Part No. Number 222022 (000000-- Scrub Head Kit Hd 800D5700 Ñ...
Page 112
STANDARD PARTS Fig. 12 - - Model 700C Scrub Head Drive Group, 700 mm (28 in) 42 41 2-24 5700 MM400 (9- -99) Home Find... Go To..
Page 113
10049 - - 5700, XP, XPS, 28in, NA, JP Fig. 12 - - Model 700C Scrub Head Drive Group, 700 mm (28 in) NOTE: Scrub Head Kit, Tennant Part Number 222015, includes Fig. 12, and Fig. 13. Tennant Machine Serial Ref.
Page 114
STANDARD PARTS Fig. 13 - - Model 700C Scrub Head Frame Group, 700 mm (28 in) 2-26 5700 MM400 (2- -98) Home Find... Go To..
Page 115
10051 - - 5700, XP, XPS, 28in, NA, JP Fig. 13 - - Model 700C Scrub Head Frame Group, 700 mm (28 in) NOTE: Scrub Head Kit, Tennant Part Number 222015, includes Fig. 12, and Fig. 13. Tennant Machine Serial Ref.
Page 116
STANDARD PARTS Fig. 14 - - Model 800C Scrub Head Drive Group, 800 mm (32 in) 42 41 2-28 5700 MM400 (9- -99) Home Find... Go To..
Page 117
10049 - - 5700, EE, XP, XPS, 32in, NA, JP Fig. 14 - - Model 800C Scrub Head Drive Group, 800 mm (32 in) NOTE: Scrub Head Kit, Tennant Part Number 222016, includes Fig. 14, and Fig. 15. Tennant Machine Serial Ref.
Page 118
STANDARD PARTS Fig. 15 - - Model 800C Scrub Head Frame Group, 800 mm (32 in) 2-30 5700 MM400 (2- -98) Home Find... Go To..
Page 119
10051 - - 5700, EE, XP, XPS, 32in, NA, JP Fig. 15 - - Model 800C Scrub Head Frame Group, 800 mm (32 in) NOTE: Scrub Head Kit, Tennant Part Number 222016, includes Fig. 14, and Fig. 15. Tennant Machine Serial Ref.
Page 120
STANDARD PARTS Fig. 16 - - Model 900C Scrub Head Drive Group, 900 mm (36 in) 42 41 2-32 5700 MM400 (9- -99) Home Find... Go To..
Page 121
351685 - - 5700, XP, XPS, 36in, NA, JP Fig. 16 - - Model 900C Scrub Head Drive Group, 900 mm (36 in) NOTE: Scrub Head Kit, Tennant Part Number 222017, includes Fig. 16, and Fig. 17. Tennant Machine Serial Ref.
Page 122
STANDARD PARTS Fig. 17 - - Model 900C Scrub Head Frame Group, 900 mm (36 in) 2-34 5700 MM400 (2- -98) Home Find... Go To..
Page 123
351686 - - 5700, XP, XPS, 36in, NA, JP Fig. 17 - - Model 900C Scrub Head Frame Group, 900 mm (36 in) NOTE: Scrub Head Kit, Tennant Part Number 222017, includes Fig. 16, and Fig. 17. Tennant Machine Serial Ref.
Page 124
STANDARD PARTS Fig. 18 - - Recovery Tank Group 2-36 5700 MM400 (2- -98) Home Find... Go To..
Page 125
STANDARD PARTS 10022 - - 5700, EE, XP, XPS, NA Fig. 18 - - Recovery Tank Group Tennant Machine Serial Ref. Description Qty. Part No. Number 222040 (000000-- Tank, Recovery 75611 (000000-- Ftg--Plug Npt 12Pm Rd Hd Plstc. 222361 (000000--...
Page 126
STANDARD PARTS Fig. 19 - - Solution Tank Group 9 10 2-38 5700 MM400 (2- -98) Home Find... Go To..
Page 127
STANDARD PARTS 10026 - - 5700, XP, XPS, NA Fig. 19 - - Solution Tank Group Tennant Machine Serial Ref. Description Qty. Part No. Number 222064 (000000-- Bracket, Prop Arm 222516 (000000-- Sleeve, .318B .496D .312 Ss 30013 (000000-- Washer--Flt .31 Fender Pltd...
Page 128
STANDARD PARTS Fig. 20 - - Vacuum Fan Group 2-40 5700 MM400 (2- -98) Home Find... Go To..
Page 129
STANDARD PARTS 10024 - - 5700, XP, XPS, NA Fig. 20 - - Vacuum Fan Group Tennant Machine Serial Ref. Description Qty. Part No. Number 17363 (000000-- Fan, Vac (See Breakdowns) Ñ 223264 (000000-- Seal, Vac Fan 222122 (000000-- Bracket, Mounting, Vac Fan...
Page 130
STANDARD PARTS Fig. 21 - - Solution Control Group 2-42 5700 MM400 (2- -98) Home Find... Go To..
Page 131
STANDARD PARTS 10032 - - 5700, EE, XP, XPS, NA, JP Fig. 21 - - Solution Control Group Tennant Machine Serial Ref. Description Qty. Part No. Number 222185 (000000-- Lever, Control 222190 (000000-- Grip, Handle 222186 (000000-- Housing, Control Lever...
Page 132
STANDARD PARTS Fig. 22 - - Battery Group 10028 - - 5700, EE, XP, XPS, NA Tennant Machine Serial Ref. Description Qty. Part No. Number 222218 (000000-- Cable, Battery 63735 (000000-- Cable Assy--Lead, 11.0, 6Ga 222510 (000000-- Cable, Battery 45962...
Page 133
STANDARD PARTS Fig. 23 - - Steering Control Group 10030 - - 5700, EE, NA, CE Tennant Machine Serial Ref. Part No. Number Description Qty. 222740 (000000-- Handle, Speed Control 222648 (000000-- Grip, Handle Round 222079 (000000-- Gear, Speed Control...
Page 134
STANDARD PARTS Fig. 24 - - Operator Console Group 2-46 5700 MM400 (2- -98) Home Find... Go To..
Page 135
STANDARD PARTS 10034 - - 5700, NA Fig. 24 - - Operator Console Group Tennant Machine Serial Ref. Description Qty. Part No. Number 222714 (000000-- Housing, Steering, Adj, Std, w/Label 222225 (000000-- Latch 34738 (005151-- Rivet, Pop, .125D X .32 X .25Dhd...
Page 136
STANDARD PARTS Fig. 25 - - Electrical Panel Group 2-48 5700 MM400 (2- -98) Home Find... Go To..
Page 137
STANDARD PARTS 10040 - - 5700, NA, JP Fig. 25 - - Electrical Panel Group Tennant Machine Serial Ref. Description Qty. Part No. Number 222495 (000000-- Plate Wldt, Electronics 222589 (000000-- Clip, Canoe 222450 (000000-- Strap, Lanyard 04685 (000000-- Contactor Spst...
Page 138
STANDARD PARTS Fig. 26 - - Squeegee Lift Group 2-50 5700 MM400 (9- -98) Home Find... Go To..
Page 139
STANDARD PARTS 10046 - - 5700, EE, NA, JP Fig. 26 - - Squeegee Lift Group Tennant Machine Serial Ref. Description Qty. Part No. Number 222460 (000000-- Sleeve 222139 (000000-- Lever, Squeegee Lift 222448 (000000-- Lever, Squeegee Lift, Upper 44847...
Page 140
STANDARD PARTS Fig. 27 - - Squeegee Linkage Group 2-52 5700 MM400 (2- -98) Home Find... Go To..
Page 141
STANDARD PARTS 10020 - - 5700, EE, XP, XPS, NA, JP Fig. 27 - - Squeegee Linkage Group Tennant Machine Serial Ref. Description Qty. Part No. Number 222399 (000000-- Block, Pivot, Machined 222239 (000000-- Pin, Pivot Block 02942 (000000-- Pin,Hair Cotter .12Wire 2.37Sl...
Page 142
STANDARD PARTS Fig. 28 - - Tight- -Aisle Squeegee Group, 550 mm (22 in) 2-54 5700 MM400 (3- -99) Home Find... Go To..
Page 143
STANDARD PARTS 351849 - - 5700, XP, XPS, NA Fig. 28 - - Tight- -Aisle Squeegee Group, 550 mm (22 in) Tennant Machine Serial Ref. Description Qty. Part No. Number 374031 (000000-- Squeegee Assembly, Tight--Aisle Ñ 374033 (000000-- Frame, Sqge, Tight--Aisle...
Page 144
STANDARD PARTS Fig. 29 - - Model 700 Squeegee Group, 700 mm (28 in) 2-56 5700 MM400 (9- -98) Home Find... Go To..
Page 145
STANDARD PARTS 10044 - - 5700, XP, XPS, 28in, NA Fig. 29 - - Model 700 Squeegee Group, 700 mm (28 in) Tennant Machine Serial Ref. Description Qty. Part No. Number 222338 (000000-- Squeegee Assembly 700 Ñ 222131 (000000-- Frame, Sqge 28”...
Page 146
STANDARD PARTS Fig. 30 - - Model 800 Squeegee Group, 800 mm (32 in) 2-58 5700 MM400 (9- -98) Home Find... Go To..
Page 147
STANDARD PARTS 10044 - - 5700, EE, XP, XPS, 32in, NA Fig. 30 - - Model 800 Squeegee Group, 800 mm (32 in) Tennant Machine Serial Ref. Description Qty. Part No. Number 222339 (000000-- Squeegee Assembly 800 Ñ 222134 (000000-- Frame, Squeegee 32”...
Page 148
STANDARD PARTS Fig. 31 - - Model 900 Squeegee Group, 900 mm (36 in) 2-60 5700 MM400 (9- -98) Home Find... Go To..
Page 149
STANDARD PARTS 10044 - - 5700, XP, XPS, 36in, NA Fig. 31 - - Model 900 Squeegee Group, 900 mm (36 in) Tennant Machine Serial Ref. Description Qty. Part No. Number 222340 (000000-- Squeegee Assembly 900 Ñ 222411 (000000-- Frame, Squeegee 36”...
Page 150
STANDARD PARTS Fig. 32 - - Electrical Schematic 10282 - - 5700, NA, JP, CE 2-62 5700 MM400 (9- -99) Home Find... Go To..
Page 151
62A/ 54/BRN 13V/ 13R/BLK 64A/ LOWER TANK (ES) 13U/ LEVEL SWITCH ES PUMP PROPEL 13S/ MOTOR BATTERIES 13DD 1/RED 71C/ 71B/ 13Y/ 13X/ 2/RED OPTIONAL VAC FAN VAC FAN MAIN HARNESS 2-63 5700 MM400 (9- -98) Home Find... Go To..
Page 154
STANDARD PARTS Fig. 34 - - Label Group 10299 - - 5700, XP, XPS, NA Tennant Machine Serial Ref. Description Qty. Part No. Number 222678 (000000-- Label Set, 5700, Xps 222578 (000000-- Label Set, Info & Hzd 5700 222533 (000000--...
Page 155
..............3-33 5700 MM400 (9- -99) Home Find...
Page 156
OPTIONS Fig. 1 - - ESt Kit 5700 MM400 (3- -97) Home Find... Go To..
Page 157
OPTIONS 10062 - - 5700, EE, NA, CE Fig. 1 - - ESt Kit Tennant Machine Serial Ref. Description Qty. Part No. Number 222351 (000000-- Es Standard 5700 Ñ 222259 (000000-- Pump Assy, Water 36Vdc (See Breakdowns) 17188 (000000-- Clamp--Wormdrive, 1.62--3.50D...
Page 159
OPTIONS Fig. 3 - - Power Wand Hose Assembly 08042 - - ALL NOTE: Power Wand Kit, Tennant Part Number 222352, includes Fig. 3, Fig. 4, Fig. 5, and Fig. 6. Tennant Machine Serial Ref. Description Qty. Part No. Number...
Page 160
OPTIONS Fig. 4 - - Power Wand Assembly 5700 MM400 (2- -98) Home Find... Go To..
Page 161
OPTIONS 06459 - - ALL Fig. 4 - - Power Wand Assembly NOTE: Power Wand Kit, Tennant Part Number 222352, includes Fig. 3, Fig. 4, Fig. 5, and Fig. 6. Tennant Machine Serial Ref. Description Qty. Part No. Number 65340...
Page 162
OPTIONS Fig. 5 - - Power Wand Pump and Fittings Group 5700 MM400 (2- -98) Home Find... Go To..
Page 163
OPTIONS 10078 - - ALL Fig. 5 - - Power Wand Pump and Fittings Group NOTE: Power Wand Kit, Tennant Part Number 222352, includes Fig. 3, Fig. 4, Fig. 5, and Fig. 6. Tennant Machine Serial Ref. Description Qty. Part No.
Page 164
OPTIONS Fig. 6 - - Power Wand Mount Group 3-10 5700 MM400 (9- -95) Home Find... Go To..
Page 165
OPTIONS 10082 - - 5700, EE, XP, XPS, NA, JP Fig. 6 - - Power Wand Mount Group NOTE: Power Wand Kit, Tennant Part Number 222352, includes Fig. 3, Fig. 4, Fig. 5, and Fig. 6. Tennant Machine Serial Ref.
Page 172
OPTIONS Fig. 11 - - Transport Group 10289 - - 5700, EE, XP, XPS, NA, JP Tennant Machine Serial Ref. Part No. Number Description Qty. 11636 (000000-- Latch, Draw, Flexible 01335 (000000-- Rivet, Pop--.125Dx.44X.25Dhd Al 3-18 5700 MM400 (9- -99) Home Find...
Page 173
OPTIONS Fig. 12 - - Neoprene Caster Group 10274 - - 5700, EE, XP, XPS, NA, JP Tennant Machine Serial Ref. Part No. Number Description Qty. 222458 (000000-- Caster, 5.0 Dia Wheel, Neopre Ñ 222354 (000000-- Wheel Assy, 5.0 Neoprene...
Page 174
OPTIONS Fig. 13 - - Solid Tire Group 10060 - - ALL Tennant Machine Serial Ref. Description Qty. Part No. Number 369345 (000000-- Tire & Rim Assy 12.3 Dia Solid 3-20 5700 MM400 (9- -99) Home Find... Go To..
Page 175
OPTIONS Fig. 14 - - Foam Filled Tire Group 10602 - - 5700, EE, XP, XPS, NA, JP Tennant Machine Serial Ref. Description Qty. Part No. Number 374044 (000000-- Tire & Rim Assy Foam Filled, Black 61598 (000000-- Tire & Rim Assy Foam Filled, Gray...
Page 176
OPTIONS Fig. 15 - - Tire and Rim Assembly, Gray 04200 - - 5700, EE, XP, XPS, NA, CE Tennant Machine Serial Ref. Description Qty. Part No. Number 61597 (000000-- Tire and Rim Assembly, Gray Ñ 61596 (000000-- Tire, Gray...
Page 177
OPTIONS Fig. 16 - - Heavy Duty Battery Kit, Wet, 305AH 10270 - - 5700, XP, XPS, NA Tennant Machine Serial Ref. Description Qty. Part No. Number 222777 (000000-- Battery Kit 36V 305Ah Wet Ñ 222846 ( xxxxxx-- Battery, 6V, Res Cap:196 Wet...
Page 178
OPTIONS Fig. 17 - - Heavy Duty Battery Kit, Dry, 305AH, International Only 10270 - - 5700, XP, XPS, NA Tennant Machine Serial Ref. Description Qty. Part No. Number 222775 (000000-- Battery Kit 36V 305Ah Dry Ñ 222847 ( xxxxxx--...
Page 179
OPTIONS Fig. 18 - - Battery Kit, Dry, 235AH, International Only 10268 - - 5700, EE, XP, XPS, NA Tennant Machine Serial Ref. Description Qty. Part No. Number 222776 (000000-- Battery Kit 36V 235Ah Dry Ñ 222285 (000000-- Battery, 6V, Res Cap:129 M Dry...
Page 180
OPTIONS Fig. 19 - - Battery Charger Group 08080 - - 5700, XP, XPS, NA Tennant Machine Serial Ref. Part No. Number Description Qty. 24685 (000000-- xxxxxx ) Charger, 36V/20A 60H/ Ph 115V (See Breakdowns) (Re- placed by 364014) 374014...
Page 181
Fig. 20 - - Urethane Scrub Head Skirt Kit 10604 - - ALL Tennant Machine Serial Ref. Description Qty. Part No. Number 222819 (000000-- Skirt Kit, Urethane, Scrubber Head Ñ 222808 (000000-- Skirt, Scrub Head 3-27 5700 MM400 (9- -99) Home Find... Go To..
Page 227
We Need Your Help... As part of Tennant’ s Zero Defects Program, we want to know about errors you have found or suggestions you may have regarding our machine manuals. If you find an error or have a suggestion, please complete this postage-paid form and mail it to us.
Page 229
We Need Your Help... As part of Tennant’ s Zero Defects Program, we want to know about errors you have found or suggestions you may have regarding our machine manuals. If you find an error or have a suggestion, please complete this postage-paid form and mail it to us.
Need help?
Do you have a question about the 5700 and is the answer not in the manual?
Questions and answers
