How to operate the unit when an optional 5.1 ch decoder/AV matrix unit connected

3. Display settings

Screen settings when the optional 5.1 ch decoder/
AV matrix unit is connected
Up to two external monitors can be connected when the 5.1 ch decoder/AV matrix unit is
connected. Separate images can be displayed on each external monitor.

External monitor image settings

Select the image to be displayed on the external monitors.
Press
NAVI MENU
Touch INFO.
screen.
Touch
AV SELECTOR
Touch
VTR 1
HEAD UNIT
Touch ENTER
If a VTR or DVD player is not connected to the 5.1 ch decoder/AV matrix unit, no
image will be displayed.
.
in the MENU
.
, or
VTR 2
to select an image.
.
151
