How to operate the unit when an optional 5.1 ch decoder/AV matrix unit connected

1. Before adjusting sound quality

Functions available when the optional 5.1 ch
decoder/AV matrix unit is connected
The following table shows the finer audio adjustments that can be performed when the
optional 5.1 ch decoder/AV matrix unit is connected.
Item
Parametric EQ
POSITION
FADER/BALANCE
Speaker
System
Time
Alignment
Crossover
Speaker Sub-woofer
Settings level
Sub-woofer
phase
Speaker
Level
Speaker
Size
Dolby Pro
Logic II
COMPRES
SION
Surround
Center
System
Width
Settings
Center
Level
Rear Level
Perform a 5-band parametric equalizer adjustment on each
channel (front, rear, center) and a 1-band adjustment on
the woofer for a total of a 16-band adjustment.
Sound localization can be adjusted according to the
number and position of passengers in order to obtain
optimum acoustic effects.
The left/right/front/rear balance can be adjusted.
The settings can be adjusted according to the connected
speaker system (1-way 4 speaker system or front 3-way
speaker system).
The delay time and level of sound from each speaker can
be adjusted in order to correct any phase mismatches in
the sound resulting from the listening position.
Allocate specified frequency bands to each speaker for
improved sound integration.
When a sub-woofer is connected, the preferred output
level for the audio can be set.
The merging of sound between the front and rear speakers
and the sub-woofer can be improved by selecting the
phase. Switch to a phase that lets the speakers combine
without any disharmony.
Adjust the frequency band output to fit the size of the
speakers connected to the unit.
Set the speaker size.
Achieve surround sound by moving from 2 channel stereo
to 5.1 channel sound.
Set the dynamic range (difference between the lowest and
highest audio signal).
When Dolby Pro Logic II is set to Music and the center
speaker is set to LARGE or SMALL, sound from the center
speaker is distributed to the left and right front speakers.
Adjust the output level of the center speaker.
Adjust the output level of the rear speakers.
Function Page
127
132
133
139
140
143
145
146
147
148
135
138
137
136
136
Continue to the next page
119
