Summary of Contents for Ace Plus EX-G035
-
Page 1: User Manual
ACE PLUS CORP. EX-G035 YPbPr/VGA to VGA Converter/Switch with Audio User Manual Page 1 of 7 Headquarters : 9F-2., No. 190 Sec. 2 Jung Shing Rd.,Hsin-dian, Taipei, Taiwan 231 TEL: +886-2-2912-4201 FAX: +886-2-2912-3164 Website: www.ace-plus.com... -
Page 2: Safety And Notice
The EX-G035 YPbPr/VGA to VGA Converter/Switch with Audio has been tested for conformance to safety regulations and requirements, and has been certified for international use. However, like all electronic equipments, the EX-G035 should be used with care. Please read and follow the safety instructions to protect yourself from possible injury and to minimize the risk of damage to the unit. - Page 3 VGA monitor, plasma, LCD or a projector in high resolution formats. The EX-G035 accepts both VGA and YPbPr inputs, and it converts YPbPr inputs into VGA outputs. Therefore, with only a press of the switch button, you can freely select between your PC and game consoles, such as PS3, Wii, XBOX, XBOX360, and DVD player.
-
Page 4: Package Content
ACE PLUS CORP. Features Automatic conversion between YPbPr and VGA Supports PC video display resolutions up to UXGA (1600x1200 @75Hz) YPbPr supports 480p, 576p, and 720p Fully compatible and ideal for DVD players and game consoles Buffered VGA output for 60m (200ft) long range transmission... -
Page 5: Front Panel
ACE PLUS CORP. Panel Descriptions Front Panel YPbPr-IN L/R Audio-IN +5V DC 1. Power jack 4. YPbPr component video input 2. Power LED indicator 5. YPbPr stereo audio input 3. VGA/YPbPr switch button ( : switch to YPbPr source; : switch to VGA... -
Page 6: Hardware Installation
Audio in. 3. Plug in 5V DC power cord to the power jack, and power up the device. 4. Enjoy the convenience of EX-G035! You can select VGA or YPbPr source at your will by pressing the switch button. -
Page 7: Limited Warranty
ACE PLUS CORP. Limited Warranty The SELLER warrants the EX-G035 YPbPr/VGA to VGA Converter/Switch with Audio to be free from defects in the material and workmanship for 1 year from the date of purchase from the SELLER or an authorized dealer. Should this product fail to be in good...
