Page 1: User Manual
ACE PLUS CORP. EX-G066B HDMI to 3G/HD/SD-SDI Mini Converter User Manual Page 1 of 8 Headquarters : 9F-2., No. 190 Sec. 2 Jung Shing Rd.,Hsin-dian, Taipei, Taiwan 231 TEL: +886-2-2912-4201 FAX: +886-2-2912-3164 Website: www.ace-plus.com www.ace-plus.tw... -
Page 2: Safety And Notice
However, like all electronic equipments, the EX-G066B should be used with care. Please read and follow the safety instructions to protect yourself from possible injury and to minimize the risk of damage to the unit. - Page 3 Plus, with up to 8 channels audio support, 7.1 channel or 5.1 channel audio becomes available. The EX-G066B offers low jitter SDI output for daisy chain. With the use of EX-G066B, the most popular uncompressed video interface in the...
- Page 4 ACE PLUS CORP. Specifications & Package Contents Model Name EX-G066A EX-G066B Technical SDI standards SD-SDI, HD-SDI & 3G-SDI Auto 3G/HD/SD-SDI detection [2.97Gpbs & 2.97/1.001Gbps] Video bandwidth [3G] 1080p50/59.94/60 (4:2:2) Video support [HD] 720p50/59.94/60, 1080p24/30,1035i50/59.94/60, 1080i50/59.94/60 [SD] NTSC@59.94Hz, PAL@50Hz [SD-SDI] SMPTE 259M...
- Page 5 ACE PLUS CORP. Supported Resolutions 3G-SDI Output 1080p @ 50/ 59.94 / SMPTE 424M, SMPTE 60Hz 425M HD-SDI Output SMPTE 293M, 525p @ 59.94Hz ITU-BT.1358 625p @ 50Hz ITU-BT.1358 720p @ 50Hz SMPTE 296M -3 720p @ 60 / 59.94Hz...
-
Page 6: Front Panel
ACE PLUS CORP. Panel Description Front Panel 1.DIP Switch 2. HDMI input 3. Interlocked +5V power jack 4. Lock LED Rear Panel 5. 3G/HD/SD-SDI output Bottom Panel A 4-pin DIP switch is used for user interface, and users can access this switch from the bottom of the unit. - Page 7 The operation is shown in the EDID learning section. EDID Learning 1. Turn off EX-G066B and set the pin 1 of DIP switch of EX-G066B to ON [ ]. 2. Connect the TV monitor thru HDMI port to EX-G066B, and then turn on EX-G066B.
- Page 8 ACE PLUS CORP. Limited Warranty The SELLER warrants the EX-G066B HDMI to 3G/HD/SD-SDI Mini Converter to be free from defects in the material and workmanship for 1 year from the date of purchase from the SELLER or an authorized dealer. Should this product fail to be in good working order within 1 year warranty period,...
