Page 1: User Manual
ACE PLUS CORP. EX-G039 HDMI/DVI to VGA/Component & Audio Converter User Manual Page 1 of 9 Headquarters : 9F-2., No. 190 Sec. 2 Jung Shing Rd.,Hsin-dian, Taipei, Taiwan 231 TEL: +886-2-2912-4201 FAX: +886-2-2912-3164 Website: www.ace-plus.com... -
Page 2: Safety And Notice
However, like all electronic equipments, EX-G039 should be used with care. Please read and follow the safety instructions to protect yourself from possible injury and to minimize the risk of damage to the unit. - Page 3 ACE PLUS CORP. Features HDMI 1.2a & DVI 1.1 compliant HDMI video supports up to 1080p Support HD (1080i / 720p) component video output Support up to UXGA PC graphics output Coaxial S/PDIF audio output Stereo analog audio output Front panel LED indicators and push button...
-
Page 4: Specifications & Package Contents
ACE PLUS CORP. Specifications & Package Contents Model Name EX-G039 Technical Role of usage D/A converter HDMI compliance HDMI 1.2a DVI compliance DVI 1.1 Video bandwidth Single-link 165MHz [4.95Gbps] Up to 1080p60, WUXGA [1920x1200@60] & UXGA Video support [1600x1200@60] Audio support... -
Page 5: Supported Resolutions
ACE PLUS CORP. Supported Resolutions PC Graphics (DVI/VGA) VESA 640x400 VESA 1024x768 VESA 1280x960 1152x864@60Hz @85Hz @60Hz @85Hz VESA 720x400 VESA 1024x768 VESA 1280x1024 Mac 480-66A @85Hz @75Hz @60Hz VESA 640x480 VESA 1024x768 VESA 1280x1024 Mac 480-66B @72Hz @85Hz @85Hz... -
Page 6: Panel Descriptions
ACE PLUS CORP. Panel Descriptions Front Panel +5V DC 1. DIP switch 3. HDMI input 5. Power indicator 2. HDMI/DVI switch button 4. DVI input 6. 5V DC DIP Switch Mode Learn EDID from VGA socket and save EDID to HDMI... -
Page 7: Hardware Installation
4. Power up the EX-G039. EDID Learning 1. Power up the EX-G039. Connect display to VGA/YPbPr Output. 2. To learn EDID for HDMI source, pull down the DIP switch 1 to ON, the red light will be dark and bright to indicate the EDID learning process is complete. You DON’T NEED to pull up the DIP switch again unless you want to learn another EDID by pulling DIP switch 1 up and down. - Page 8 ACE PLUS CORP. Notice 1. Only HDMI enabled TV sets with underscan/overscan* support, the full active video can be accurately displayed. Some HDMI equipped TV sets may not support this feature. If underscan/overscan* is NOT supported, the top, bottom, left and right border of the active video may be screened, and the S/PDIF audio may not sound right.
-
Page 9: Limited Warranty
ACE PLUS CORP. Limited Warranty The SELLER warrants the EX-G039 HDMI/DVI to VGA/Component & Audio Converter to be free from defects in the material and workmanship for 1 year from the date of purchase from the SELLER or an authorized dealer. Should this product fail to be in good working order within 1 year...
