Digital Watchdog PTZ37X Quick Start Manual

37 Analog PTZ Dome Camera
x
Quick Start Guide
Version 1.01
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a
commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a
residential area is likely to cause harmful interference in which case the user will be required to correct the interference a this own
expense.
To disconnect power from the mains, pull out the mains cord plug.
When install the product, ensure that the plug is easily accessible.
PREPARATION
The following items are included with the PTZ camera
Mounting Mounting Box (Sold Separately)
PTZ37X QSG
Camera Module
Template
Upper Housing
Waterproof Tape
CD (Manual)
Hexagonal Wrench
Housing Safety
Covering Dome
Cable Hanger
Inner Box (Found in the upper
Anchor Bolt (4pcs)
housing or mounting box) Safety Wire
Thank you for purchasing Digital Watchdog's Super Speed Dome PTZ Outdoor Dome Camera.
Before installing the camera, please verify your model and read this guide carefully.
TEL: (866) 446-3595
www.Digital-Watchdog.com / technicalsupport@dwcc.tv
Technical Support Hours: Monday-Friday 9:00AM to 8:00PM EST
INSTALLATION
Prepare the Camera
Connect and secure all necessary cables from
the inner box to all desired applications
Connect the RS-485 wires to a terminal box
1
matching the inner box RS-485 terminals.
Connect the other end of the cable to a terminal
box matching the DVR or keyboard controller's
RS-485 Terminals.
AC
Adapter
Connect AC Power Adapter to the camera's Connect BNC Coaxial cable to camera's inner box.
2 4 3
Inner box. Make sure to connect positive and Connect other end of the BNC cable to a DVR
negative lines in their corresponding locations. or monitor.
Power Requirements: AC24V
Power Consumption: Heater Off: 24W, 1000mA,
Heater On: 57W, 2400mA
Mounting Accessory for the DWC-PTZ37X is sold separately
with the camera's wiring module. For wiring module in the
dome, see DWC-PTZ37XFM and DWC-PTZ37XAL models.
INSTALLATION INSTALLATION
DIP Switch Setup
Using the DIP Switch in the inner box, setup the camera's
Communication Protocol, Joystick Controller, and camera's ID.
Communication Bit Rate
Protocol
1 AUTO- Factory Default
1 2400 BPS
ON ON
1 2 3 4 5 6 7 8
J 1 2 3 4 5 6 7 8
8J
2
PELCO-D 2 4800 BPS
ON
ON
1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8
J 8J
3 PELCO-P 3 9600 BPS - Factory Default
ON
ON
1 2 3 4 5 6 7 8
J 1 2 3 4 5 6 7 8
8J
4 4 19200 BPS
SAMSUNG
ON
ON
1 2 3 4 5 6 7 8
1 2 3 4 5 6 7 8 8J
J
5 PANASONIC 5 38400 BPS
ON
ON
1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8
8J
J
6 GE(Kalatel)
ON
RS-485 Termination
1 2 3 4 5 6 7 8
J
Resistor
7 AD (American Dynamics)
ON ON
1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8
J 8J
2
20150121
INSTALLATION
Mount the Camera
Using the desired Wall or Ceiling Mount, secure camera's Mounting Box
to wall/ ceiling.
Unscrew the top cover of the mounting box
4
and remove the protective plastic to expose
the four screw holes
Using a drill, drill four holes for the bolts and
6
secure mounting box to wall/ceiling.
If camera model includes the inner box inside the mounting
box, make sure all cables remain intact during installation
3
INSTALLATION
Inner Box
ON
Pass the cable connector from the inner box
8
through the upper housing pipe.
1 2 3 4 5 6 7 8
8J
f inner box is located in the upper housing,
Protocol Setup Baud Rate Setup
RS 485
connect the desired mounting bracket and run
Termination Resistor
the wires through the bracket.
Camera's ID
Using the bottom D P Switch, setup the
camera's ID. By default, the camera's D
Hook the safety wire to the safety hook on the
10
is set as 1. Users can select 1~255 IDs upper housing. Using the safety hanger, secure it
to the mounting box/ bracket.
by turning switches ON or OFF.
Each switch has a numerical value. The
camera's ID = the sum of all switches
that are turned ON.
4
INSTALLATION
Snap the camera mechanism back into the upper
12
housing.
Using the mounting box or the mounting template
5
mark on the wall or ceiling the locations for the
four bolts.
Remove protecting gear from the camera's lens
14
Remove PTZ mechanism from the upper housing.
7
To detach mechanism from upper housing,
press down and hold both black handles marked
'A' and 'B' on the camera mechanism.
Pull both handles up to detach the camera.
5
INSTALLATION
Connect power and initial testing
Connect the camera to the power and make sure it is operating
Properly.
Power Requirements: AC24V
Power Consumption: 24W, 1000mA, Heater On: 57W, 2400mA
When System Initialize screen appear, take note of the camera's
protocol, Baud Rate and Address. This information will be necessary
to complete camera's connection to a DVR or Keyboard Joystick.
Screw the upper housing to the mounting box/
9
bracket. Turn the upper housing at least seven (7)
times to secure a tight connection.
For outdoor installation, wind the weatherproof tape
around the upper housing's pipe.
When setup is complete, Home Position will show OK
Plug cable connector from the inner box
11
to the upper housing.
f no adjustments need to be made to the
17
wiring, place the dome cover on the upper
housing.
This order of fastening the screws guarantees optimal
sealing and protects the camera from weather elements
6
Make sure the two black handles marked 'A'
13
and 'B' correspond with the 'A' and 'B' markings
on the sides of the upper housing.
Note: Before snapping the camera back into
the housing, make sure all cables are
properly secured.
Connect the cover dome to the upper housing
15
by securing the safety wire.
7
Secure dome to camera by fastening the screws
18
on the dome in the order shown here.
8
