AngleMeter 45

press the MITRE button (15) for ~2 sec. The displayed angle and the CNR indicator (6) will flash once and the corner (CNR) angle is
now stored in memory.
If the stored corner angle does not need to be changed, press MITRE button (15) for ~1 sec to move to the next step.
Step 4: If you do not already have the MTR indicator (5) shown in the display, press the MITRE button (15) for ~1 sec. This is the
calculated mitre angle for setting the saw. See pic. 3, angle M.
Step 5: Press the MITRE button (15) for ~1 sec to change the display to the bevel angle. The BVL indicator (4) will be displayed. This
is the bevel angle for setting the saw. See pic. 3, Angle B.
Press the MITRE button (15) for ~1 sec to cycle back through the stored spring angle, the stored corner angle and the calculated mitre
and bevel angles.
Press the ON/OFF button (12) at any time for ~1 sec to exit compound angle mode.
