Idealarc
Product
Product
Input
Name
Number
Power
R3R-500-I
K1380-2
220/380/440/3/50/60
R3R-600-I
K1381-2
220/380/440/3/50/60
(1) NEMA Class I Rated Output / Based on a 10 minute period.
(2) Includes lift bail.
R3R-500-I & 600-I
TECHNICAL SPECIFICATIONS
Rated Output
Current/Voltage/Duty Cycle(1)
400A / 36V / 60%
500A / 40V / 60%
STICK WELDERS
CC DC
Input Current @
Rated Output
Output Range
74 / 47 / 37A
60-500A
Max. OCV: 67V
88 / 56 / 44A
75-625A
Max. OCV: 67V
3
50
60
Hz
PHASE
Dimensions
H x W x D
Net Weight
in.(mm)
lbs.(kg)
(2)
31.0
x 22.3 x 32
402
(787 x 566 x 813)
(183)
(2)
31.0
x 22.3 x 32
446
(787 x 566 x 813)
(203)
Publication E2.100.1 6/03
www.lincolnelectric.com
