ACCUSPLIT®
healthengine
ACTIVITY PEDOMETER
OPERATING INSTRUCTIONS
Congratulations on taking the first step to wellness with
your purchase of an ACCUSPLIT healthengine pedometer.
It's easy to set up your new pedometer.
Just follow the steps below, and start walking!
AH120MAG FEATURES:
• Outstanding accuracy
• MAGNUM display with very large digits
• Sturdy metal clip
• Records up to 999,999 steps, then rolls over back to zero
USING YOUR PEDOMETER
HOW TO OPEN YOUR PEDOMETER.
See diagrams at right.
WEARING YOUR PEDOMETER
While gently holding the metal belt clip open, slide the pedome-
ter onto your belt or the top edge of your pants or skirt. It should
fit snugly and level, above one knee.
Note: the pedometer should be as vertical as possible. Walkers
with larger stomachs may find it helpful to wear the pedometer
farther back on the body, toward one hip.
The cover must be closed
for the pedometer to work.
SAFETY LEASH
This pedometer comes with a free safety leash, to help prevent
accidental loss. The leash comes pre-attached to the pedometer.
To use the leash, simply clasp the waistband of your clothing
with the attached alligator clip. You can also use a safety pin to
fasten the leash to your clothing, loop the leash through your
belt or belt loop, or use a badge holder.
Leash is already attached
to the pedometer.
Clasp the waistband of
your clothing with
the attached
alligator clip.
Or, loop a belt
or belt loop
ACCUSPLIT, Inc. • 3090 Independence Drive, Suite 148 • Livermore, CA 94551 USA
800-935-1996 • 925-290-1900 • FAX 925-290-1930 • www.ACCUSPLIT.com • support@ACCUSPLIT.com
AH120MAG
™
VIEWING YOUR RESULTS
Once you put on your pedometer with the cover closed, it will
automatically begin to record your steps.
RESETTING YOUR PEDOMETER
Most people prefer to reset step counts daily. To reset: Press and hold
yellow RESET button for at least two seconds to reset to zero.
REPLACING THE BATTERY
When the display starts to dim or goes blank, it is time to replace the battery.
Your pedometer uses one Type LR43 (L1142) 1.5 volt alkaline battery. You'll
need a jeweler's screwdriver set to change the battery. To replace:
1. Insert a coin into the slot on the bottom of the case, and twist counter-
2. Use a jeweler's screwdriver
yes
no
3. Replace with a new battery. The battery's positive (+) terminal should
4. Align case front over the pedometer and press gently to
Or, loop a
badge holder,
then put into pocket
(Badge holder not included)
DISPLAY MODES
• STEPS: Counts steps taken since last RESET.
Reset daily to count each day's steps.
8793
PedometerEngine
clockwise to loosen the case front. Lift case front away.
to remove the battery
terminal screws.
Terminal
Screws
be FACE UP while you put it into the pedometer.
snap cover back into place, starting with top.
REGISTER NOW
Email (preferred)
Please return
your AH120MAG Registration to
User
the Repair Center address in the
warranty, and we will let you know
about future products.
NO-PROOF-OF-PURCHASE LIMITED WARRANTY
Free service for first year of ownership;
$12 fee for service thereafter. See label inside unit for date.
See www.accusplit.com/support for details.
Yellow:
RESET
RESET
TM
MAG
990-005A
