Accusplit Alliance 1540 Operating Instructions

DISPLAY MODES
• Steps
Counts steps taken since last ReSet.
Reset daily to count each day's steps.
• DISt
Shows distance walked since last reset
of "Steps. "
005 19
0
®
ACCUSPLIT
RESET
(28)
Yellow: Gray:
ReSet Set
SETTING UP YOUR PEDOMETER
To record your distance and calories accurately, you will
need to set your stride length.
CHOOSING A MEASUREMENT SYSTEM
This unit is initially set to use English measurement units
(Miles). To change the unit back and forth between English
and Metric units (Kilometers). press the yellow RESET
button for 5 seconds.
Finding Your Stride Length: Your stride length is the
length of one of your steps, measured from "toe to toe."
To measure, walk 10 steps with your normal stride and
measure the TOTAL DISTANCE from the toe of your starting
step to the toe of your 10
the TOTAL DISTANCE by 10. This is your stride length.
Example: If you walk 22 feet, your stride length is 2.2 feet.
Setting Your Stride Length: Press the black MODE button
until the arrow on top right hand side of display points to
"DIST" (distance). Press the gray SET button for at least
two seconds to enter setting mode. Display will shift to show
stride. Press and hold down the gray SET button to increase
stride length. Press and hold the yellow RESET button to
decrease stride length. Press the black MODE button to exit
setting mode.
(For example, "F 1.95" means stride is set to 1.95 feet.)
10 steps
ACCUSPLIT, Inc. • 6120 Stoneridge Mall Rd., Suite 210 • Pleasanton, CA 94588 USA
800-965-2008 • 925-226-0888 • FAX 925-463-0147 • www.ACCUSPLIT.com • support@ACCUSPLIT.com
ACCUSPLIT®
ALLIANCE
ACTIVITY PEDOMETER
OPERATING INSTRUCTIONS
Congratulations on taking the first step to wellness with your purchase
of an ACCUSPLIT pedometer. It's easy to set up your new pedometer.
Just follow the steps below, and start walking!
DIST STEP
ACTIVITY
PEDOMETER
1540
ALLIANCE
SET
MODE
Black:
MODe
step (see diagram below). Divide
th
1540
WEARING YOUR PEDOMETER
While gently holding the belt clip open, slide the pedometer onto your
belt or the top edge of your pants or skirt. It should fit snugly and
level, above one knee.
Note: The pedometer should be as vertical as possible. Walkers with
larger stomachs may find it helpful to wear the pedometer farther
back on the body, toward one hip.
The cover must be closed for the pedometer to work. To avoid
losing or dropping your pedometer, use the included leash and clip to
fasten the pedometer securely to your clothing.
Attaching the Leash: Attach the pedometer to the leash by looping
the leash around the pedometer belt clip. Next, clasp the waistband
of your clothing with the attached clip. You can also use a safety pin
to fasten the leash to your clothing, loop the leash through your belt
or belt loop, or use a badge holder.
First, loop the
pedometer clip
Next, loop the metal clip, then
clasp clothing
Or, loop a belt
or belt loop
VIEWING YOUR RESULTS
Once you put on your pedometer with the cover closed, it will
automatically begin to record your steps and distance. Repeatedly
press the black MODE button to cycle through the pedometer
modes: STEPS → DISTANCE → STEPS
AUTO MOVEMENT SENSOR
1. To filter out random movements, the unit remains in standby
mode until 5 continuous steps are registered. Only then are the
5 steps calculated in, and an Active indicator "▲" appears on
the upper left of display.
2. When regular walk/run movement stops, after 2 seconds the
timer pauses and the unit switches to standby status (Active
indicator "▲" disappears).
Or, loop a
badge holder, then
put into pocket
(Badge holder not included)
960-045
