Lincoln Aviator 2004 Quick Reference Manual

Essential Information
aviator
2004 FUEL TANK CAPACITY/FUEL RECOMMENDATIONS:
gallons of fuel. Your vehicle is designed to use "Premium" unleaded fuel with an (R+M)/2 octane
QUICK REFERENCE GUIDE
rating of 91 or higher for optimum performance. The use of fuel with lower octane ratings may
degrade performance.
FUSES: If electrical components in your vehicle stop working, a fuse may have blown. (You'll notice a
broken wire within the fuse.) For information on changing fuses, please consult your Owner's Guide.
TIRE PRESSURE: Your tire pressure is properly set at the dealership according to the
recommended specifications found on the Tire Pressure Label located on the driver door jamb. Please
check your tire pressure during routine maintenance and seasonal changes. If the Tire Pressure
Monitoring System light stays illuminated after starting, immediately check your tire pressure.
Warning: Improperly inflated tires can affect vehicle handling and can fail suddenly, possibly resulting
in loss of vehicle control.
CHANGING THE TIRES: Your spare tire is not equipped with a tire pressure monitoring system
sensor. The tire pressure monitoring system indicator light (if equipped) will illuminate when the
Ford Motor Company Customer Relationship Center spare is in use. Replace the spare with the road tire as soon as possible. If your vehicle is equipped
P.O. Box 6248, Dearborn, MI 48121 with AWD, remember that a spare tire of a different size shall not be used. It can make your vehicle
1-800-392-3673 (FORD) difficult to control and can result in damage to driveline components. If you get a flat tire while
(TDD for the hearing impaired: 1-800-232-5952) driving, do not apply the brake heavily. Instead, gradually decrease your speed. Hold the steering
wheel firmly and slowly move to a safe place on the side of the road.
This Quick Reference Guide is not intended to replace the Owner's Guide
that contains more detailed information concerning the features of your
vehicle and important safety warnings to help reduce the risk of injury to
• SPARE TIRE: Under the vehicle, just in front of the rear bumper.
you and your occupants. Always carefully read your entire Owner's Guide
when first learning about your vehicle and consult the appropriate section • SPARE TIRE WINCH DRIVE NUT:
when questions arise.
• JACK, LUG NUT WRENCH, JACK HANDLE AND WHEEL CHOCK:
carpeted floor lid in the cargo door.
ROADSIDE EMERGENCIES: To fully assist you if you should have a vehicle concern, Lincoln offers
a complimentary roadside assistance program. This program is separate from the New Vehicle
Limited Warranty. The service is available 24 hours a day, seven days a week for the New Vehicle
Limited Warranty period of four years or 50,000 miles.
Roadside assistance will cover:
• Changing a flat tire
• Lockout assistance
• Jump-starts
*F4C5J19G217AB*
• Towing of your vehicle
4C5J-19G217-AB
• Limited fuel delivery
October 2003 For complete details on any roadside assistance concerns, see the Roadside Emergencies or Customer Assistance
Second Printing sections of your Owner's Guide.
Lincoln Aviator
Quick Reference Guide Litho in U.S.A.
Additional Features
Your Aviator's fuel tank can accommodate 22.5 Climate
Control Seats
(if equipped)
The controls are
located on the front door trim panels. To
cool the seats, push the icon on the right
side of the button; a blue light will
illuminate. Push again to disengage. To
heat the seats, push the icon on the left
side of the button; a red light will
illuminate. Push again to disengage. To
adjust the heating or cooling levels,
rotate the thumbwheel from 1 (MIN) to 5
(MAX). Allow five minutes for the
temperature to stabilize.
Remote Entry
System
The remote entry
system allows you
to lock or unlock all vehicle doors, the
liftgate and the liftgate window without
Rear center of the cargo area, under a lid. a key. This system operates in any
ignition position.
Behind the rear seat under the
Unlocking Doors/Liftgate: Press
this control to unlock the driver's
door; the interior lamps will illuminate
with the ignition OFF. Press the control
a second time within three seconds to
unlock all doors and liftgate.
Locking Doors/Liftgate: Press
this control to lock all doors and
liftgate; the park/turn signal lamps will
Country: Phone Number:
flash once. To confirm all doors are
United States (800) 521-4140 closed and locked, press the control a
second time within three seconds; the
Canada (800) 665-2006
park/turn signal lamps will flash once
and the horn will chirp. If any of the
doors or liftgate are ajar, the horn will
make two quick chirps, reminding you
to properly close all doors.

Audio System

CAUTION: DO NOT USE CD WITH ADHESIVE LABEL*
1
Tire Pressure 7 8 9
2
3
Monitoring
System
Using radio-frequency 4
pressure sensors, this system monitors
tire pressure on all road tires and
5 6
provides the driver with a yellow
10
warning light when air needs to be
added. Message Center equipped
Audiophile Satellite-Ready In Dash Six CD Radio (if equipped)
vehicles provide additional warning
messages. The TPMS warning light will
(If your Aviator is equipped with a different audio 6 SATELLITE: Your Audiophile radio
Reset itself (turn off) after the tires are
system, please refer to your Owner's Guide.)
comes equipped with satellite-ready
set to specification and the vehicle is
capability. The kit to enable satellite
either parked up to 1 hour or by driving 1 CD/AUX: Press to select CD/AUX
modes. No CD will display if there is not reception is available through your Lincoln
the vehicle above 20 mph (30 km/h) for
a CD present in the audio system. If a dealer. Detailed satellite instructions are
10 seconds. Please note: Outside
included with the dealer-installed kit.
temperature affects tire pressure. See disc is loaded, there will be a number
(1-6) inside the circle on the display.
Owner's Guide for more information. 7 DISC/TUNE CAT: In radio mode, press
2 SCAN FUNCTION: In radio mode, to move to the next frequency up or down
Opening
press to hear a sampling of all listenable the band. In CD mode, press to select a
the Liftgate stations. In CD mode, press to hear a disc in the CD player. CAT is only
brief sampling of all selections on the available when equipped with satellite
& Liftgate
radio. The kit to enable satellite reception
current CD.
Window
is available through your Lincoln dealer.
3 LOADING CD: Press to open the CD
Detailed satellite
To prevent injury or damage to your
door, then load a CD into the player. Press
vehicle, always make sure the liftgate included with the dealer-installed kit.
LOAD and then a preset number to select
window is closed before opening
8 SEEK FUNCTION:
a slot. Press and hold LOAD to activate
the liftgate.
autoload. to move to the next listenable station up
The liftgate on your Aviator is designed or down the band. In CD mode, press to
4 VOLUME/POWER CONTROL: Press the
to be opened from outside the vehicle. select the next/previous track on the
control to turn the audio system on or off.
current disc.
You can unlock the liftgate with the
Turn the control to raise or lower volume.
power door locks, the remote entry, or
The speed sensitive volume feature 9 DIGITAL SIGNAL PROCESSING:
keyless entry pad. Push the center
DSP and then SEL to choose the desired
automatically adjusts radio volume in
control button under the license plate
accordance with vehicle speed to signal mode (DSP OFF, NEWS, JAZZ
lamp shield while pulling the liftgate. To
CLUB, HALL, CHURCH, STADIUM).
compensate for road and wind noise. To
open the liftgate window, press the
engage, press and hold the volume
control on the remote entry key fob or, 10 SETTING MEMORY PRESET STATIONS:
control for five seconds (with the radio
with the liftgate unlocked, push the Select AM, FM1, or FM2 band, then
on), then simultaneously press SEL to
right control button under the license select a station. Next, press and
choose the compensation level.
hold a numbered control until the
plate lamp shield.
5 AM/FM SELECT: In radio mode, press sound returns.
AM/FM to select AM or FM frequency
11 SETTING THE CLOCK:
bands. In CD mode, press AM/FM to stop
until SELECT HOUR or SELECT MINUTE
play and begin radio play.
is displayed. Press SEL to set the
time. Press MENU again to disengage
the clock mode.
*CDs with adhesive labels and irregularly shaped CDs may get stuck in the CD player.
Homemade CDs should be identified with permanent felt tip marker rather than adhesive labels.

Climate Control

10 11 12
6 7 8
13
9
1 2 3 4 5
11
Automatic Temperature Control
1 AUTO: Press AUTO and select the achieve the selected temperature. To
temperature you find most comfortable. adjust fan speed manually, press the up
The system will automatically determine arrow to increase the speed, the down
fan speed, airflow location and whether arrow to decrease the speed. To return to
outside or recirculated air is required. automatic fan operation, press AUTO.
2 AUTO OFF: Press OFF to disengage 8 EXTERIOR TEMPERATURE DISPLAY:
automatic temperature control. Press EXT to display the outside
temperature; press again to end exterior
3 DIRECT AIRFLOW: You can personally
temperature display.
determine where you'd like air to go by
choosing one of these manual override 9 FAHRENHEIT/CELSIUS: Press the °F °C
controls. control to switch between Fahrenheit and
Celsius.
4 DEFROST: To clear thin ice and fog from
instructions are
the windshield, choose DEFROST; this 10 A/C: You may override automatic
control will distribute outside air through operation at any time by pressing the A/C
the windshield defroster ducts and the control. To return to automatic air
In radio mode, press
side window demisters. To return to conditioning operation, press AUTO.
automatic operation, press AUTO.
11 RECIRCULATED AIR: Press this button
5 DEFROST REAR WINDOW: Press this to manually control recirculated air; to
control to manually enable or disable the return to automatic recirculated air,
rear window defroster in all modes. After press AUTO.
Press
approximately 10 minutes of operation,
12 PASSENGER TEMPERATURE CONTROL:
the climate control system will
Press the up arrow of the passenger
automatically disable the rear defrost
temperature control for a warmer
operation. If more defrosting is needed,
temperature, the down arrow for a cooler
press the control again.
temperature.
6 DRIVER TEMPERATURE CONTROL: Press
13 DUAL TEMPERATURE ZONE: Press
the up arrow of the driver temperature
DUAL to enable or disable the dual zone
control for a warmer temperature, the
temperature feature that allows driver and
down arrow for a cooler temperature.
front passenger to select a temperature
Press MENU
7 FAN SPEED: When your climate control based on personal preference. Press
system is in automatic mode, the fan DUAL again to disable this feature.
speed will automatically adjust to
aviator
2004
QUICK REFERENCE GUIDE
