3.2 Login
To access the SmartNode, start the Telnet application on your PC. Type the default IP address into the
1.
address field: 192.168.1.1 . Accessing your SmartNode via a Telnet session displays the login screen.
Type the factory default login: administrator and leave the password empty. Press the Enter key after the
password prompt.
login: administrator
password:<Enter>
192.168.1.1>
2. After you log in, your SmartNode will be running in operator execution mode (indicated by > character
in the command line prompt). To enter configuration mode, use the commands enable and configure .
192.168.1.1> enable
192.168.1.1# configure
192.168.1.1(cfg)#

4.0 Connecting the SmartNode to the network

CAUTION
In general, the SmartNode will connect to the network via the WAN (ETH 0/0) port. This enables the SmartNode
to offer routing services to the PC hosts on LAN (ETH 0/1) port. The SmartNode 4650 Series provides an auto-
MDX feature for both Ethernet ports, so you can use a straight-through or cross-over cable to connect to a host or
a switch (see figure 2
4
The interconnecting cables shall be acceptable for external use and shall be rated for
the proper application with respect to voltage, current, anticipated temperature, flam-
mability, and mechanical serviceability.
).
SmartNode 4650 G.SHDSL Quick Start Guide
