Related Manuals for Patton electronics 457B
Summary of Contents for Patton electronics 457B
- Page 1 USER MANUAL MODEL 457B Seven Port Active Twinax Star Hub SALES OFFICE Part #07M457B-C Doc. #069011UC (301) 975-1000 Revised 4/22/98 TECHNICAL SUPPORT (301) 975-1007 An ISO-9001 http://www.patton.com Certified Company...
- Page 2 However, there is no guarantee that interference will not occur in a particular installation. If the Model 457B does cause interference to radio or television reception, which can be determined by disconnecting the RS-232 interface, the user is encouraged to try to...
- Page 3 3.1 DEFAULT SIGNAL-TO-PIN CONFIGURATION The Model 457B is configured at the factory so that RJ-45 pin 4 corresponds to TIP and RJ-45 pin 5 corresponds to RING. This default setting applies to the single host connection as well as the seven terminal connections.
- Page 4 4.0 INSTALLATION After the internal jumpers are configured for your equipment, you are ready to connect up the Model 457B. This section explains how to connect the host and terminals to the Model 457B in a star topology using twisted pair cable.
- Page 5 LED indicators. 5.1 POWER UP There is no power switch on the Model 457B. To apply power to the unit, plug the AC adapter into one of the two rear jacks (see figure 5, below) and then into a wall outlet.
