Patton electronics SmartNode 4650 Series Quick Start Manual
Multiport isdn voip iad with g.shdsl
Hide thumbs
Also See for SmartNode 4650 Series:
- Getting started manual (72 pages) ,
- Quick start manual (13 pages)
Table of Contents
Advertisement
Quick Links
SmartNode 4650 Series
Multiport ISDN VoIP IAD
with G.SHDSL
Quick Start Guide
Approval—This device is approved for connection to the public ISDN telecommunication network,
over BRI/S0-ISDN interfaces.
Zulassung—Zugelassen für die Anschaltung an das öffentliche ISDN Telekommunikationnetz an
BRI/S0-ISDN Schnittstellen.
Aprobación—Este aparato está aprobado para conexión a red publica ISDN sobre interfaz BRI/S0.
Approbation—Cet appareil est approuve pour la connexion au reseau ISDN public avec les interfaces
BRI/S0.
Part Number: 07MSN4650-QS , Rev. D
Revised: February 8, 2012
Sales Office: +1 (301) 975-1000
Technical Support: +1 (301) 975-1007
E-mail: support@patton.com
WWW: www.patton.com
Advertisement
Table of Contents
Related Manuals for Patton electronics SmartNode 4650 Series
Summary of Contents for Patton electronics SmartNode 4650 Series
- Page 1 SmartNode 4650 Series Multiport ISDN VoIP IAD with G.SHDSL Quick Start Guide Approval—This device is approved for connection to the public ISDN telecommunication network, over BRI/S0-ISDN interfaces. Zulassung—Zugelassen für die Anschaltung an das öffentliche ISDN Telekommunikationnetz an BRI/S0-ISDN Schnittstellen. Aprobación—Este aparato está aprobado para conexión a red publica ISDN sobre interfaz BRI/S0.
-
Page 2: Connecting The Smartnode To Your Laptop Pc
• This device contains no user serviceable parts. The equipment shall be returned to Patton Electronics for repairs, or repaired by qualified ser- vice personnel. WARNING • Mains Voltage: Do not open the case the when the power cord is attached. -
Page 3: Configuring The Desired Ip Address
Straight-through wired cable LAN (ETH 0/0) Laptop PC Connecting to the PC Figure 1. Connect the PC’s Ethernet port to LAN (ETH 0/0) port of the SmartNode 4650. The SmartNode 4650 Series is equipped with Auto-MDX Ethernet ports, so you can use straight-through Ethernet cables for host or hub/switch connections. -
Page 4: Connecting The Smartnode To The Network
In general, the SmartNode will connect to the network via the WAN (ETH 0/0) port. This enables the SmartNode to offer routing services to the PC hosts on LAN (ETH 0/1) port. The SmartNode 4650 Series provides an auto- MDX feature for both Ethernet ports, so you can use a straight-through or cross-over cable to connect to a host or... - Page 5 Straight-through wired or crossover cable LAN (ETH 0/0) Network WAN (DSL) Figure 2. Connecting the SmartNode to the network You can check the connection with the ping command from the SmartNode to another host on the local LAN. 172.16.1.99(if-ip)[eth_dsl]#ping <IP Address of the host> If the WAN address is set to DHCP, to ping a device outside your local LAN you must first configure Note...
-
Page 6: Loading The Configuration (Optional)
5.0 Loading the configuration (optional) Patton provides a collection of configuration templates on the support page at www.patton.com/smart- node—one of which may be similar enough to your application that you can use it to speed up configuring the SmartNode. Simply download the configuration note that matches your application to your PC. Adapt the config- uration as described in the configuration note to your network (remember to modify the IP address) and copy the modified configuration to a TFTP server. -
Page 7: Additional Information
6.0 Additional Information For detailed information about configuring and operating guidance, set up procedures, and troubleshooting, refer to the SmartNode 4650 User Manual available online at www.patton.com/manuals/ and the SmartWare Software Configuration Guide available online at www.patton.com/ SN4650G.pdf smartnode. A.0 Customer and Technical Support Toll-Free VoIP support: call sip:support@patton.com with a VoIP SIP client... -
Page 8: Compliance Information
B.0 Compliance Information B.1 Compliance EMC Compliance: FCC Part 15, Class A • EN55022, Class A • EN55024 • Safety Compliance: UL60950-1/CSA C22.2 No. 60950-1 • IEC/EN 60950-1 • AS/NZS 60950-1 • PSTN Regulatory Compliance: TBR3 • AS/ACIF S031 • AS/ACIF S043 (G.SHDSL card) •... -
Page 9: Ce Declaration Of Conformity
B.4 CE Declaration of Conformity SmartNode 4650 Series Product Description: This equipment conforms to the requirements of Council Directive 1999/5/EC on the approximation of the laws of the member states relating to Radio and Telecommunication Terminal Equipment and the mutual recognition of their conformity. -
Page 10: Copyright Statement
Copyright statement Copyright © 2012, Patton Electronics Company. All rights reserved. The information in this document is subject to change without notice. Patton Electronics assumes no liability for errors that may appear in this document. Trademarks statement The term SmartNode is a trademark of Patton Electronics Company. All other trademarks presented in this docu- ment are the property of their respective owners. - Page 11 Notes ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________...
- Page 12 Notes ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ SmartNode 4650 G.SHDSL Quick Start Guide...
