Icom IC-F30GT Service Manual page 24

[MAIN UNIT]
REF ORDER
NO. NO.
J3 6510022360 S.CONNECTOR
F1 5210000710 S.FUSE
5210000880 S.FUSE
S1 2250000180 ENCODER
W2 7030003860 S.RESISTOR
W3 7030003860 S.RESISTOR
W4 7030003860 S.RESISTOR
W5 8900009790 CABLE
EP1 0910055243 PCB
[GT]: IC-F30GT/F31GT, M.=Mounted side (T: Mounted on the Top side,
[GS]: IC-F30GS/F31GS,
[F30G]: IC-F30GT/F30GS,
[F31G]: IC-F31GT/F31GS
[IS]: Intrinsically safe version
DESCRIPTION M.
26FLZ-SM1-TB
KAB 2402 322 NA29 [F31G]
043403.5NRP [F30G]
EC10SP16-47
ERJ3GE JPW V
ERJ3GE JPW V
ERJ3GE JPW V
OPC-972
B 5511C
B: Mounted on the Bottom side)
*=safety critical components
S.=Surface mount
T
T
T
B
B
T
B
6 - 7
