Handling Precautions

CAUTION
High potential static charge can cause damage to the integrated circuits on the board. Before
handling any mainboard outside of its protective packaging, ensure that there is no static
electric charge on your body.
Danger of explosion if battery is incorrectly replaced. Replace only with the same or
equivalent type recommended by the manufacturer.
♦ Keep the board in its anti-static bag until you are ready to install it.
♦ Protect your board form static electricity by well grounding of your body and the equipment during the
installation, such as wearing a grounded wrist strap.
♦ Always handle the board by its edges.
♦ Do not touch with the components on the boards, add-on cards and modules, or the "gold finger"
connectors going to be plugged into the expansion slot. It is best to handle system components by their
mounting bracket.
♦ Ensure the system power is completely turn-off before doing any installation work.
Notice to Customers
The information contained in this User's Guide with no liability whatsoever, and disclaims any express or implied
warranty, relating to sale and/or use of products including liability or warranties relating to fitness for a particular purpose,
merchantability, or infringement of any patent, copyright or other intellectual property right. We shall not be liable for any
loss or profits, loss of business, loss of use or data, interruption of business, or for indirect, special, incidental, or
consequential damages arising from any defect or error in this User's Guide or product.
We retains the right to make changes on this User's Guide and product descriptions at any time, without notice.
Page
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the T530B and is the answer not in the manual?

Questions and answers

Related Manuals for Zida T530B

Summary of Contents for Zida T530B

  • Page 1: Handling Precautions

    Handling Precautions CAUTION High potential static charge can cause damage to the integrated circuits on the board. Before handling any mainboard outside of its protective packaging, ensure that there is no static electric charge on your body. Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type recommended by the manufacturer.
  • Page 2 Trademarks ™ ™ SIS is a registered trademark of Silicon Integrated Systems Corp. Intel® ® , Pentium® ® are registered trademarks of Intel Corporation. ® ® ® ® ® ® ® ® -K6-III are registered trademarks of -K5, AMD -K6, AMD -K6-2, AMD Advanced Micro Devices, Inc.

  • Page 3: Table Of Contents

    Table of Contents FEATURES OF THE BOARD ........................4 ..............................4 VERVIEW .............................4 EATURES UMMARY MOTHERBOARD INSTALLATION ......................6 INSTALLATION PRECAUTIONS ......................6 A QUICK INTRODUCTION........................6 CPU I ............................7 NSTALLATION INSTALLING SYSTEM MEMORY (RAM) ....................8 EXPANSION CARDS INSTALLATION .....................9 CONNECTING EXTERNAL CONNECTOR....................9 AT Power Connector ..........................9 ATX Power Connector..........................10 Floppy Drive Connector..........................10 IDE Connectors ............................10...

  • Page 4: Features Of The Board

    Features of the Board Overview Congratulations on purchasing the highest performance motherboard. With the advanced technology available ® ® ® today, this motherboard is designed to run Pentium , AMD and Cyrix processors. The on-board system memory consists of DIMM. In addition, two unbuffered, 3.3 Volts, 168-pin SDRAM sockets are also included for 16 to 256MB synchronous Dynamic memory support.
  • Page 5 þ ¨ Full Support for Microsoft Direct 3D and Direct Draw þ ¨ Award BIOS, PC98/ACPI/DMI Compliant þ ¨ Dual AT/ATX Power Supply Interface Page...

  • Page 6: Motherboard Installation

    Motherboard Installation INSTALLATION PRECAUTIONS During installation and initial test, use caution to avoid personal injury and damage to wiring due to sharp pins on connectors and printed circuit assemblies, rough chassis edges and corners, and hot components. Adhere to warnings and limitations regarding accessibility into areas designated only for authorized technical personnel. A QUICK INTRODUCTION To Install and operate your the new motherboard, you must follow the steps below: 1.

  • Page 7: Cpu Installation

    CPU Installation The motherboard provides a 321-pins, type-7, ZIP socket. The CPU should have a fan attached to it to prevent overheating. If this is not the case then purchase a fan before you turn-on the system. 45 degree Index corner Intel Pentium...

  • Page 8: Installing System Memory (Ram)

    INSTALLING SYSTEM MEMORY (RAM) The motherboard supports two 168-pin DIMM. Vertically Insert for Installation Push to remove DIMM module 3.3V Key Unbuffered DRAM Key Push to remove DIMM module 168-Pin SDRAM Module Installation Diagram Page...

  • Page 9: Expansion Cards Installation

    EXPANSION CARDS INSTALLATION At the most of beginning, you must read your expansion card documentation on any hardware and software settings that may be required. The installation procedures are summarized as below: 1. Read the User’s Guide/Manual of your expansion card. 2.

  • Page 10: Atx Power Connector

    ATX Power Supply Connector ± ± A single 20-pin connector incorporates standard 5V and 12V, optional 3.3V and soft-power signals. With a power supply supports remote power on/off, the motherboard can turn off the system power through software control, such as the shutdown in Windows 98 Start menu. The system BIOS will turn the system power off when it receives the proper APM command from the OS.

  • Page 11: Front Panel Function Connectors

    Provided 10 Pin Ribbon cable Red Wire Side Pin 1 Side Provided 40 Pin Ribbon cable Pin 1 Side Ribbon cable Installation Example NOTICE For the flat ribbon cable connection, please make sure that the pin 1 of the ribbon cable (the red wire side of the cable) is correctly connected to the on-board connector’s pin 1 as shown on the “Map of the Motherboard”.

  • Page 12: Replacing Battery

    Integrated USB, Infra-Red and PS/2 Mouse connector The total of two USB device connectors, a PS/2 mouse, and Infrared devices are all allocated at this connector • Pin1 to Pin5 for USB1 connector • Pin11 to Pin15 for USB2 connector •...

  • Page 13: Quick Installation Guide

    Quick Installation Guide DIMM3 DIMM2 DIMM1 USB2 USB1 PS/2 COM2 COM1 FLOPPY PRINTER SECONDARY IDE PRIMARY IDE PCI1 Clear CMOS (1-2) VID4 VID3 Normal (2-3) VID2 PCI2 VID1 VID0 PCI3 WAKEUP-LINK ISA1 PWR.ON IDE..LED ISA2 RESET Front Panel KEYLOCK SPEAKER Page...
  • Page 14 T530B A. AT Power Supply Connector L. PCI Bus Connectors B. ATX Power Supply Connector M. ISA Bus Connectors C. AT Keyboard Connector D. Serial (COM1 and 2) Headers O. Front Panel Connector E. Parallel (Printer) Port Header F. Integrated Functions Connector Q.
  • Page 15 T530B-S Quick Installation Guide DIMM3 DIMM2 DIMM1 USB2 USB1 PS/2 AUDIO HEADER COM2 COM1 FLOPPY PRINTER SECONDARY IDE PRIMARY IDE PCI1 Clear CMOS (1-2) VID4 VID3 Normal (2-3) VID2 PCI2 VID1 VID0 PCI3 WAKEUP-LINK ISA1 PWR.ON IDE..LED ISA2 RESET Front Panel...

  • Page 16: Audio Connector

    T530B-S A. AT Power Supply Connector L. PCI Bus Connectors B. ATX Power Supply Connector M. ISA Bus Connectors C. AT Keyboard Connector D. Serial (COM1 and 2) Headers O. Front Panel Connector E. Parallel (Printer) Port Header F. Integrated Functions Connector Q.

  • Page 17: Quick Reference Of Your Motherboard

    Quick Reference of Your Motherboard AT Power Supply Connector Based on the AT specification, one 12-pin power connector covers all the required power sources, ±5V and ±12V. ATX Power Supply Connector Based on the ATX specifications, one 20-pin power connector covers all the required power sources, ±5V, ±12V, and ±3.3V, with soft-touch button power on/off features.
  • Page 18 Floppy Drive Connector A 34-pin connector on-board allows connection to two 360K, 720K, 1.2M, 1.44, 2.88M floppy disk drives. PCI Add-in Board Connectors This motherboard provides full-length 32-bits PCI slots with up to 133MB/sec burst data transfer rate. ISA Add-in Board Connectors This motherboard provides 16-bits ISA slots which allows backward hardware compatibility.

  • Page 19: Ultra Dma 66 Device Guide

    Ultra DMA 66 Device Guide For the best I/O transfer rate, we recommend you connecting your Ultra ATA/66 and Ultra ATA/33 Devices according to the following configuration : Primary IDE - Connect Ultra ATA/66 device with Ultra ATA/66 cable ( Optional ) - Attach the blue connector to mainboard IDE 1.
  • Page 20 Supplementary Jumper Guide Please set the jumper manually according to the CPU’s marking before boot up the system. Using the tables on page 18-20 to set the suitable CPU Core, External Bus Speed & Bus Frequency Ratio. For the following table: 1.

  • Page 21: Cpu Jumper Settings

    CPU Jumper Settings Please set the jumper manually according to the CPU’s marking before boot up the system. Using the following tables to set the suitable CPU Core, External Bus Speed & Bus Frequency Ratio. 1. Set the CPU Core Voltage CPU Voltage Selection List CPU type Voltage Requirements...
  • Page 22 2. Set the External Bus Speed (MHz) and Bus Frequency Ratio CPU TYPE Freq. Ratio Bus F. AMD-K6-III/550 550MHz 5.5x 100MHz Open Open Close Close Open Open Close AMD-K6-III/500 500MHz 5.0x 100MHz Open Open Close Close Open Close Close AMD-K6-III/475 475MHz 5.0x 95MHz...

  • Page 23: Clear Cmos

    All CPU / SDRAM / PCI Frequency Setting Table SDRAM Open Close Close Close 66.8 66.8 33.4 Open Close Close Open Open Close Open Close 83.3 83.3 33.3 Open Close Open Open 31.7 Open Open Close Close 33.3 Open Open Close Open 37.3...

  • Page 24: Award Bios Setup

    Award BIOS Setup Standard CMOS Setup Sets time, date, hard disk type, types of floppy drive. Monitor type, and if keyboard is installed. Bios Features Setup Sets Typematic Rate and Delay, Above 1 MB Memory Test, Memory Test Tick Sound, Hit <Del> Message Display, System Boot Up Sequence, and many others.

  • Page 25: Standard Cmos Setup

    Standard CMOS Setup Select the Award BIOS Setup options by choosing Standard Setup from the Award BIOS. Setup main menu. The Standard CMOS Setup options are described below. Floppy Drive A: and B: Move the cursor to these fields and select the floppy type. The setting are 360 KB 5 1/4 inch, 1.2 MB 5 1/4 inch, 720 KB 3 1/2 inch or 2.88 MB 3 1/2 inch.
  • Page 26 TYPE How to Configure Select Type. Select Auto to let BIOS determine the parameters. Click on OK when BIOS displays the drive parameters. Select LBA Mode. Select On if the drive has a capacity greater than 540 MB. Select Block Mode. Select On to allow block mode data transfers.

  • Page 27: Bios Features Setup

    BIOS Features Setup Virus Warning You can "Enable" or "Disable" this feature. When enabled, it will activate automatically if anything attempt to access the boot sector or hard disk partition table during system boot-up. The default value is "Disabled". CPU Internal Cache This category enables or disables the internal cache to speed up memory access.
  • Page 28 Boot Up NumLock Status It determine the Num-Lock is turned on/off Num Lock. when the system is powered on so that the end user can use the arrow keys on both the numeric keypad and the keyboard. The default value is "On". Memory Parity Check It enables the memory parity checking.

  • Page 29: Chipset Features Setup

    Chipset Features Setup Choose Chipset Features Setup on the Setup main menu. All Chipset Setup options are then displayed. Refresh Rate Control This field sets the Refresh Rate Contol timing. The Choice: 15.6us, 7.8us, 3.9us Ref/Act Command Delay This field sets the Ref/Act Command Delay timing. The Choice: 5T, 6T, 7T, 8T Refresh Queue Depth This field sets the Refresh Queue Depth...
  • Page 30 Starting Point of Paging This field sets the Starting Point of Paging timing. The Choice: 1T, 2T, 4T, 8T. SDRAM CAS latency This field sets the CAS latency timing. The Choice: 2T, 3T. SDRAM WR Retire Rate This field sets the SDRAM WR Retire Rate. The Choice: X-1-1-1, X-2-2-2.
  • Page 31 AGP Aperture Size (MB) Select the size of the Accelerated Graphics Port (AGP) aperture. The aperture is a portion of the PCI memory address range dedicated for graphics memory address space. Host cycles that hit the aperture range are forwarded to the AGP without any translation. The choice: 4, 8, 16, 32, 64, 128, 256 PCI Post Write Buffer This field sets the PCI Post Write Buffer.

  • Page 32: Pci/Pnp Configuration Setup

    PCI/PnP Configuration Setup Choose PCI/Plug and Play Setup from the BIOS Setup screen to display the PCI and Plug and Play Setup options, described below. Resources Controlled by The Award Plug and Play BIOS can automatically configure all the boot and Plug and Play- compatible devices.

  • Page 33: Power Management Setup

    Power Management Setup The BIOS Setup options described in this section are selected by choosing Power Management Setup from the BIOS Setup main menu. ACPI function This item allows you to enable/disable the Advanced Configuration and Power Management (ACPI). The choice: Enabled, Disabled. Power Management This category allows you to select the type (or degree) of power saving and is directly related to the following modes:...
  • Page 34 There are three selections for Power Management, three of which have fixed mode settings. Disable (default) No power management. Disables all four modes Min. Power Saving Minimum power management. Doze Mode = 1 hr. Standby Mode = 1 hr., Suspend Mode = 1 hr., and HDD Power Down = 15 min.
  • Page 35 PM Timers The following four modes are Green PC power saving functions which are only user configurable when User Defined Power Management has been selected. See above for available selections. HDD Power Down When enabled and after the set time of system inactivity, the hard disk drive will be powered down while all other devices remain active.

  • Page 36: Integrated Peripheral Setup

    Integrated Peripheral Setup Integrated Peripheral Setup options are displayed by choosing Peripheral Setup form the BIOS Setup main menu. All Peripheral Setup options are described here. Internal PCI / IDE The chipset contains a PCI IDE interface with support for two IDE channels. Select Enabled to activate the first and/or second IDE interface.
  • Page 37 IDE Primary/Secondary Master/Slave UDMA Ultra DMA/33 implementation is possible only if your IDE hard drive supports it and the operating environment includes a DMA driver (Windows 95 OSR2 or a third-party IDE bus master driver). If your hard drive and your system software both support Ultra DMA/33, select Auto to enable BIOS support. The Choice: Auto, Disabled Init Display First This item allows you to decide to active PCI Slot or AGP first...

  • Page 38: Driver Installation Guide

    Onboard Parallel Port Select a logical LPT port name and matching address for the physical parallel (printer) port. The choice: 378H/IRQ7, 278H/IRQ5, 3BCH/IRQ7, Disabled. port EPP or ECP mode. Choices are SPP, ECP/EPP, ECP, EPP/SPP. ECP Mode Use DMA Select a DMA channel for the port. Choices are 3, 1.
