HANDLING PRECAUTIONS

CAUTION
High potential static charge may cause damage to the integrated circuits on the board. Before
handling any mainboard outside of its protective packaging, ensure that there is no static
electric charge in your body.
Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent
type recommended by the manufacturer.
There are some basic precautions when handling the motherboard or other computer components:
♦ Keep the board in its anti-static bag until you are ready to install it.
♦ Protect your board from static electricity by well grounding of your body and the equipment during the
installation, such as wearing a grounded wrist strap.
♦ Always handle the board by its edges.
♦ Do not touch with the components on the boards, add-on cards and modules and with the "gold finger"
connectors plugged into the expansion slot. It is best to handle system components by their mounting
bracket.
♦ Ensure the system power is completely turn-off before doing any installation work.
TRADEMARKS™ ™
Intel, Pentium, Pentium II are registered trademark of Intel Corporation.
IBM, IBM PC, IBM PC/AT, PC-DOS, OS/2 and OS/2 WARP are registered trademarks of
International Business Machines Corporation.
MS-DOS, Windows, Windows NT and Windows 95 are registered trademarks of Microsoft
Corporation.
AMI BIOS is a product of American Megatrends Inc.
Third-party brands and names mentions in this User's Guide are the property of their
respective owners.
NOTICE TO CUSTOMERS
The information contains in this User's Guide with no liability whatsoever, and disclaims any express or implied warranty,
relating to sale and/or use of products including liability or warranties relating to fitness for a particular purpose,
merchantability, or infringement of any patent, copyright or other intellectual property right. We shall not be liable for any loss
or profits, loss of business, loss of use or data, interruption of business, or for indirect, special, incidental, or consequential
damages arising from any defect or error in this User's Guide or product.
We retains the right to make changes on this User's Guide and product descriptions at any time, without notice.
User's Guide Revision : 1.1
Release Date : October 1997
Copyright © 1997, All rights reserved.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 6mlx and is the answer not in the manual?

Questions and answers

Related Manuals for Zida 6mlx

Summary of Contents for Zida 6mlx

  • Page 1: Handling Precautions

    HANDLING PRECAUTIONS CAUTION High potential static charge may cause damage to the integrated circuits on the board. Before handling any mainboard outside of its protective packaging, ensure that there is no static electric charge in your body. Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type recommended by the manufacturer.

  • Page 2: Table Of Contents

    Table of Contents Table of Contents CHAPTER 1..............................1 ..........................1 EATURES OF THE OARD Overview ..............................1 Features Summary............................ 1 Quick Reference of Your Motherboard ..................... 3 Motherboard Installation ......................... 7 CPU Card Installation ........................... 10 Installing System Memory (RAM) ......................11 Expansion Cards Installation .........................

  • Page 3: Chapter 1

    EPP/ECP capable parallel port, and support for an IrDA and Consumer Infra Red compatible interface. The 6MLX is designed to support the new graphic interface standard, Accelerated Graphic Port (AGP), The AGP interface can reach a theoretical ~532Mbytes/sec transfer rate for 3D graphics data.
  • Page 4 Motherboard Installation POWER SOCKET JP18 PCI 1 PCI 2 PCI 3 PCI 4 ISA 1 ISA 2 ISA 3 BIOS Fig.1 Parts Location on the Motherboard Page 2...
