HANDLING PRECAUTIONS

CAUTION
High potential static charge may cause damage to the integrated circuits on the board. Before
handling any mainboard outside of its protective packaging, ensure that there is no static
electric charge in your body.
Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent
type recommended by the manufacturer.
There are some basic precautions when handling the motherboard or other computer components:
♦ Keep the board in its anti-static bag until you are ready to install it.
♦ Protect your board from static electricity by well grounding of your body and the equipment during the
installation, such as wearing a grounded wrist strap.
♦ Always handle the board by its edges.
♦ Do not touch with the components on the boards, add-on cards and modules and with the "gold finger"
connectors plugged into the expansion slot. It is best to handle system components by their mounting
bracket.
♦ Ensure the system power is completely turn-off before doing any installation work.
TRADEMARKS™ ™
Intel, Pentium, Pentium II are registered trademark of Intel Corporation.
IBM, IBM PC, IBM PC/AT, PC-DOS, OS/2 and OS/2 WARP are registered trademarks of
International Business Machines Corporation.
MS-DOS, Windows, Windows NT and Windows 95 are registered trademarks of Microsoft
Corporation.
AMI BIOS is a product of American Megatrends Inc.
Third-party brands and names mentions in this User's Guide are the property of their
respective owners.
NOTICE TO CUSTOMERS
The information contains in this User's Guide with no liability whatsoever, and disclaims any express or implied warranty,
relating to sale and/or use of products including liability or warranties relating to fitness for a particular purpose,
merchantability, or infringement of any patent, copyright or other intellectual property right. We shall not be liable for any loss
or profits, loss of business, loss of use or data, interruption of business, or for indirect, special, incidental, or consequential
damages arising from any defect or error in this User's Guide or product.
We retains the right to make changes on this User's Guide and product descriptions at any time, without notice.
User's Guide Revision : 1.1
Release Date : March 1998
Copyright © 1997,1998 All rights reserved.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 6ABX/LX and is the answer not in the manual?

Questions and answers

Summary of Contents for Zida 6ABX/LX

  • Page 1: Handling Precautions

    HANDLING PRECAUTIONS CAUTION High potential static charge may cause damage to the integrated circuits on the board. Before handling any mainboard outside of its protective packaging, ensure that there is no static electric charge in your body. Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type recommended by the manufacturer.
  • Page 2: Table Of Contents

    Table of Contents Table of Contents CHAPTER 1..............................1 ..........................1 EATURES OF THE OARD Overview ..............................1 Features Summary............................ 1 Quick Reference of Your Motherboard ..................... 3 Motherboard Installation ......................... 7 CPU Card Installation ..........................9 Installing System Memory (RAM) ......................10 Expansion Cards Installation .........................
  • Page 3: Chapter 1

    Motherboard Installation Chapter 1 Features of the Board OVERVIEW ® Congratulations on purchasing the highest performance 6ABX/LX PENTIUM II motherboard. With the advanced technologies available today, this motherboard is designed to optimize for Intel’s ® PENTIUM II processors at speeds of 100 Mhz/ 66 Mhz bus clock. Three unbuffered, 3.3 Volts, 168- pin DIMM sockets are included for supporting 16MB to 512M SDRAM.
  • Page 4 Motherboard Installation POWER SOCKET TA-LINK PCI 1 WAKE- PCI 2 UP LINK SB-LINK PCI 3 JP10 PCI 4 PCI 5 ISA 1 TB-LINK ISA 2 Fig.1 Parts Location on the Motherboard Page 2...
  • Page 5: Quick Reference Of Your Motherboard

    Motherboard Installation QUICK REFERENCE OF YOUR MOTHERBOARD PS/2 Keyboard / Mouse Connectors K. Intel SB82371AB Chipset Universal Serial Bus (USB) Connectors Infra-Red (IR) Connector External I/O Connectors M. IDE device connector PENTIUM II CPU Card Slot N. Floppy Drive Connector Accelerated Graphic Port (AGP) O.
  • Page 6 Motherboard Installation PS/2 Keyboard / Mouse Connectors PS/2 device, likes some PS/2 keyboard and mouse, are all have a standard 6-pin round shape connector. The benefit of PS/2 device is one of the serial port may be free for other serial device such as writing table.
  • Page 7 The flash BIOS allows user have more flexibility to upgrade their motherboard. The flash BIOS can be programmed by software easily. For the latest BIOS upgrade information, please feel free to visit our web site: http://www.zida.com PCI Add-in Board Connectors This motherboard provides four 32-bit PCI slots with up to 133MB/sec burst data transfer rate.
  • Page 8 Motherboard Installation IDE Connectors This motherboard have two independent high performance bus-mastering PCI IDE interfaces capable of supporting up to Mode 4 devices. The system BIOS supports automatic detection of the IDE device data transfer rate and translation between different kinds of device mode such as Logical Block Addressing (LBA) and Extended Cylinder Sector Head (ECSH) translation modes and ATAPI (e.g., CD-ROM) devices on both IDE interfaces.
  • Page 9: Motherboard Installation

    Motherboard Installation MOTHERBOARD INSTALLATION Installation Precautions During installation and initial test, use caution to avoid personal injury and damage to wiring due to sharp pins on connectors and printed circuit assemblies, rough chassis edges and corners, and hot components. Adhere to warnings and limitations regarding accessibility into areas designated only for authorized technical personnel.
  • Page 10 Motherboard Installation CPU Speed Selection • JP7-JP10 for frequency ratio setting The table below shows the jumper setting for the Pentium II and Celeron. CPU and it based on its internal clock speed. Internal CPU speed (Mhz) External Bus JP10 Frequency 100 / 66 Mhz bus speed 6ABX / 6ALX...
  • Page 11: Cpu Card Installation

    Motherboard Installation CPU CARD INSTALLATION The motherboard provides a 242-pin CPU card slot. The CPU card should have a fan attached to it to prevent overheating. If this is not the case then purchase a fan before you turn-on the system. There are two CPU fan power connector, JP2 and JP3, on-board.
  • Page 12: Installing System Memory (Ram)

    Motherboard Installation INSTALLING SYSTEM MEMORY (RAM) The motherboard supports three 168-pin DIMM. The three 168-pin DIMM sockets are divided into six banks for single or double side SDRAM DIMM. Vertically insert for installation Push to remove DIMM module 3.3V Key Unbuffered DRAM Key Push to remove...
  • Page 13: Connecting External Connector

    Motherboard Installation 8. Replace the computer’s cover. 9. Setup the BIOS configuration if necessary. 10. Install the required software drivers for your expansion card. CAUTION Before adding or removing any expansion card or other system components, make sure that you unplug your system power supply. Failure to do so may cause damage of your motherboard and expansion cards.
  • Page 14 Motherboard Installation Floppy Drive Connector This 34-pin connector supports the provided floppy drive ribbon cable. After connecting the single end to the on-board “FLOPPY” connector, connect the remaining plugs on the other end to the floppy drives correspondingly. IDE Connector The two on-board IDE connectors support the provided 40-pin IDE hard disk ribbon cable.
  • Page 15 Motherboard Installation About Soft Touch Power Button For the ATX system case, the new soft touch power button replaces the main power switch to switch ON / OFF your system. You can switch the system ON by pressing the button. If you want to switch OFF your system, press the button and hold it for 4 seconds.
  • Page 16 Motherboard Installation 26-pin (Female) 26-pin Parallel Port Connector (Male) connector SERIAL SERIAL Onboard Back PRINTER I/O Connector Onboard Back EXTERNAL MODEM I/O Connector PARALLEL 9-pin Seriall Port (Female) connector 9-pin (Male) Connector COM 1 COM 2 SERIAL MOUSE Fig. 8 I/O Back Panel Connector Installation Diagram for Serial and Parallel Ports Page 14...
  • Page 17: Revision History

    Manual Revision History REVISION HISTORY Revision 1.0 First release. Revision 1.1 Add Celeron CPU settings Page 15...
