Zida TX98-3D User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Handling Precautions

CAUTION
High potential static charge can cause damage to the integrated circuits on the board. Before
handling any mainboard outside of its protective packaging, ensure that there is no static
electric charge on your body.
Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent
type recommended by the manufacturer.
♦ Keep the board in its anti-static bag until you are ready to install it.
♦ Protect your board form static electricity by well grounding of your body and the equipment during the
installation, such as wearing a grounded wrist strap.
♦ Always handle the board by its edges.
♦ Do not touch with the components on the boards, add-on cards and modules, or the "gold finger"
connectors going to be plugged into the expansion slot. It is best to handle system components by their
mounting bracket.
♦ Ensure the system power is completely turn-off before doing any installation work.
Notice to Customers
The information contained in this User's Guide with no liability whatsoever, and disclaims any express or implied warranty,
relating to sale and/or use of products including liability or warranties relating to fitness for a particular purpose,
merchantability, or infringement of any patent, copyright or other intellectual property right. We shall not be liable for any loss
or profits, loss of business, loss of use or data, interruption of business, or for indirect, special, incidental, or consequential
damages arising from any defect or error in this User's Guide or product.
We retains the right to make changes on this User's Guide and product descriptions at any time, without notice.

Advertisement

Table of Contents
loading

Related Manuals for Zida TX98-3D

Summary of Contents for Zida TX98-3D

  • Page 1: Handling Precautions

    Handling Precautions CAUTION High potential static charge can cause damage to the integrated circuits on the board. Before handling any mainboard outside of its protective packaging, ensure that there is no static electric charge on your body. Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type recommended by the manufacturer.
  • Page 2 Trademarks™ ™ VIA is a registered trademark of VIA Technologies, Incorporated. Intel® ® , Pentium® ® are registered trademarks of Intel Corporation. IBM, IBM PC, IBM PC/AT ,PC-DOS, OS/2 and OS/2 WARP are registered trademarks of International Business Machines Corporation. MS-DOS, Windows and Windows 95 are registered trademarks of Microsoft Corporation.

  • Page 3: Table Of Contents

    Table of Contents FEATURES OF THE BOARD........................1 ..............................1 VERVIEW ............................1 UMPER ............................ 1 EATURES UMMARY MOTHERBOARD INSTALLATION......................3 INSTALLATION PRECAUTIONS......................3 A QUICK INTRODUCTION ........................3 ............................3 UMPERS ETTING Jumpers..............................3 CPU I ............................4 NSTALLATION INSTALLING SYSTEM MEMORY (RAM)....................

  • Page 4: Features Of The Board

    Motherboard Installation Features of the Board Overview ® Congratulations on purchasing the highest performance Pentium motherboard. With the advanced technology available today, this motherboard is designed to run Intel’s Pentium processors at speeds up to 233 MHz. The on-board system memory consists of SIMM and DIMM giving you the most flexibility for system design.
  • Page 5 Motherboard Installation þ Supports “Modems Ring On” (Requires ATX power supply and External COM2) þ PnP BIOS with support for power management, UltraDMA33/EIDE/SCSI features and desktop management interface (DMI) which allows higher level of hardware compatibility. þ Flash BIOS for easy upgrade þ...

  • Page 6: Motherboard Installation

    Motherboard Installation Motherboard Installation INSTALLATION PRECAUTIONS During installation and initial test, use caution to avoid personal injury and damage to wiring due to sharp pins on connectors and printed circuit assemblies, rough chassis edges and corners, and hot components. Adhere to warnings and limitations regarding accessibility into areas designated only for authorized technical personnel.

  • Page 7: Cpu Installation

    Motherboard Installation CPU Installation The motherboard provides a 321-pins, type-7, ZIP socket. The CPU should have a fan attached to it to prevent overheating. If this is not the case then purchase a fan before you turn-on the system. 45 degree Index corner Intel Pentium...

  • Page 8: Installing System Memory (Ram)

    Motherboard Installation INSTALLING SYSTEM MEMORY (RAM) The motherboard supports two 72-pin SIMMs (Single-In-Line Memory Modules) from 8MB up to 256MB memory size and two 168-pin DIMM. The four 72-pin SIMMs sockets are divided into two memory banks, Bank 0 and Bank 1, and each bank has two SIMM sockets which accept either FPM or EDO DRAM module.
  • Page 9 Motherboard Installation Vertically Insert for Installation Push to remove DIMM module 3.3V Key Unbuffered DRAM Key Push to remove DIMM module 168-Pin SDRAM Module Installation Diagram CAUTION SDRAM Module cannot be used together with the SIMMs Module. Page...

  • Page 10: Expansion Cards Installation

    Motherboard Installation EXPANSION CARDS INSTALLATION At the most of beginning, you must read your expansion card documentation on any hardware and software settings that may be required. The installation procedures are summarized as below: 1. Read the User’s Guide/Manual of your expansion card. 2.

  • Page 11: Atx Power Connector

    Motherboard Installation ATX Power Connector ± ± A single 20-pin connector incorporates standard 5V and 12V, optional 3.3V and soft-power signals. With a power supply supports remote power on/off, the motherboard can turn off the system power through software control, such as the shutdown in Windows 95 Start menu. The system BIOS will turn the system power off when it receives the proper APM command from the OS.

  • Page 12: Front Panel Function Connectors

    Motherboard Installation Provided 10 Pin Ribbon cable Red Wire Side Pin 1 Side Provided 40 Pin Ribbon cable Pin 1 Side Ribbon cable Installation Example NOTICE For the flat ribbon cable connection, please make sure that the pin 1 of the ribbon cable (the red wire side of the cable) is correctly connected to the on-board connector’s pin 1 as shown on the “Map of the Motherboard”.

  • Page 13: Replacing Battery

    USB 1 PS/2 Mouse On-board Sound Connector ( TX98-3D ) The total of three connectors are using to support the On-board sound features. JP18 including the Line- In, Mic-In, Line-Out and MIDI/JOYSTICK. J6 and J7 are the CD-Audio input headers, and there pin out...

  • Page 14: Quick Installation Guide

    Motherboard Installation Quick Installation Guide COM1 COM2 PRINTER DIMM2 DIMM1 SIMM2 SIMM1 FLOPPY SECONDARY IDE AUDIO PRIMARY IDE PCI1 TA-LINK JP19 PCI2 WAKEUP-LINK JP17 PCI3 PCI4 ISA1 ISA2 TX98-3D Page...
  • Page 15 Motherboard Installation TX98-3D A. AT Power Supply Connector K. Audio CD Connectors B. ATX Power Supply Connector L. PCI Bus Connector C. AT Keyboard Connector M. ISA Bus Connectors D. Serial (COM1 and 2) Headers E. Parallel (Printer) Port Header O.

  • Page 16: Auto Jumper Yes" Guide

    Motherboard Installation “Auto Jumper Yes” Guide • To enable the “Auto Jumper Yes”, the onboard jumper JP16 must shorted (1-2). Then, the CPU brands and its core voltage will automatically detected. But one thing to remind is the CPU speed is necessary to select a suitable one at the CMOS setup. Or, if JP16 is shorted (2-3), that means you should follow the jumper table (at the next page) to setup your CPU settings manually.
  • Page 17 Motherboard Installation INTEL PENTIUM P54C/P55C CPU Internal CPU External Bus Frequency Speed (MHz) Speed (MHz) Ratio [1-2] [1-2] [1-2] 1.5x [1-2] [1-2] [2-3] 2.0x [1-2] [1-2] [1-2] 2.0x [1-2] [1-2] [2-3] 2.5x [1-2] [1-2] [1-2] 2.5x [1-2] [1-2] [1-2] 3.0x [1-2] [1-2] [1-2]...
  • Page 18 Motherboard Installation Page...
  • Page 19 Motherboard Installation CPU Core Voltage Table Bus Frequency Ratio Vcore VID4 VID3 VID2 VID1 VID0 Ratio 2.2V 2.0x 2.8V 2.5x 2.9V 3.0x 3.2V 3.5x / 1.5x 3.3V 4.0x 3.4V 4.5x 3.5V 5.0x 5.5x Page...

  • Page 20: Quick Reference Of Your Motherboard

    Motherboard Installation Quick Reference of Your Motherboard AT Power Supply Connector Based on the AT specification, one 12-pin power connector covers all the required power sources, ±5V and ±12V. ATX Power Supply Connector Based on the ATX specifications, one 20-pin power connector covers all the required power sources, ±5V, ±12V, and ±3.3V, with soft-touch button power on/off features.
  • Page 21 Motherboard Installation SIMM Sockets This motherboard provides two 72-pin SIMM sockets. The minimum memory size is 8 MB by using two 1M x 32 SIMM modules and maximum memory size is 128 MB by four 8M x 32 SIMM modules. Memory timing can be configured through the BIOS setup, please refer to the chapter of BIOS setup.
  • Page 22 Motherboard Installation TA-LINK Intel LAN Header This header interface supporting E100+ PCI LAN Card using Intel LAN chip. IDE Connectors This motherboard have two independent high performance bus-mastering PCI IDE interfaces capable of supporting up to UltraDMA-33 devices. The system BIOS supports automatic detection of the IDE device data transfer rate and translation between different kinds of device mode such as Logical Block Addressing (LBA) and Extended Cylinder Sector Head (ECSH) translation modes and ATAPI (e.g., CD-ROM) devices on both IDE interfaces.

  • Page 23: S Tandard Cmos S Etup

    Motherboard Technical Specification AMIBIOS Setup Types of Setup Description Standard CMOS Setup Sets time, date, hard disk type, types of floppy drives, monitor type, and if keyboard is installed. Advanced CMOS Setup Sets Typematic Rate and Delay, Above 1 MB Memory Test, Memory Test Tick Sound, Hit <Del>...

  • Page 24: Standard Cmos Setup

    Motherboard Technical Specification Standard CMOS Setup Select the AMIBIOS Setup options by choosing Standard Setup from the AMIBIOS Setup main menu. Standard Setup options are described below. Floppy Drive A: and B: Move the cursor to these fields via ↑ and ↓ and select the floppy type. The settings are 360 KB 5¼...
  • Page 25 Motherboard Technical Specification Type How to Configure Select Type. Select Not Installed o the drive parameter screen. The SCSI SCSI drivers provided by the SCSI manufacturer should allow you to configure the SCSI drive. Select Type. Select Auto to let AMIBIOS determine the parameters. Click on OK when AMIBIOS displays the drive parameters.

  • Page 26: Cpu Configuration Setup

    Motherboard Technical Specification CPU CONFIGURATION SETUP The system BIOS is capable to detect the CPU type, say, Pentium II or Celeron. The user is only required to select the CPU speed. In addition, overclocking option is provided for advanced users who prefer to run the CPU over the specified clock frequency of 66MHz.

  • Page 27: Advanced Cmos Setup

    Motherboard Technical Specification ADVANCED CMOS SETUP Quick Boot Set this option to Enabled to instruct AMIBIOS to boot quickly when the computer is powered on. This option replaces the old Above 1 MB Memory Test Advanced Setup option. The settings are: Boot Device This option sets the type of device for the first boot drives that the AMIBIOS attempts to boot from after AMIBIOS POST completes.
  • Page 28 Motherboard Technical Specification Try Other Boot Devices Set this option to Yes to instruct AMIBIOS to attempt to boot from any other drive in the system if it cannot find a boot drive among the drives specified in the 1 Boot Device, 2 Boot Device, 3 Boot Device options.
  • Page 29 Motherboard Technical Specification Boot To OS/2 Set this option to Enabled if running OS/2 operating system and using more than 64 MB of system memory on the motherboard. The settings are Enabled or Disabled. The Optimal and Fail-Safe default settings are Disabled. CPU Microcode Update Set this option to Enabled to permit the CPU to be updated online at any time.

  • Page 30: Advanced Chipset Setup

    Motherboard Technical Specification ADVANCED Chipset Setup The AMIBIOS Setup options described in this section are selected by choosing Advanced Chipset Setup from the AMIBIOS Setup main menu. Memory Holes This option enables or disables the memory hole. Memory holes are the region in memory forwarded to ISA/PCI bus instead of memory bus.
  • Page 31 Motherboard Technical Specification default settings are 3CL. Bank Interleave Set this option to Enabled to enable DRAM banks interleave logic. The settings are Enabled or Disabled. The optimal and fail-safe default settings are Enabled. DRAM Timing Control This option is used set DRAM timing of the chipset. For user convenience the options are specified as Normal, Medium, Fast and Turbo.

  • Page 32: Pci/Pnp Setup

    Motherboard Technical Specification PCI/PnP Setup Choose PCI/Plug and Play Setup from the AMIBIOS Setup screen to display the PCI and Plug and Play Setup options, described below. Plug and Play Aware O/S Set this option to Yes to inform AMIBIOS that the operating system can handle plug and Play (PnP) devices.
  • Page 33 Motherboard Technical Specification configuration space is the VGA Palette Snoop bit (0 is disabled). For example: if there are two VGA devices in the computer (one PCI and one ISA) and: Page...
  • Page 34 Motherboard Technical Specification VGA Palette Action Snoop Bit Disabled Data read and written by the CPU is only directed to the PCI VGA device's palette registers. Enabled Data read and written by the CPU is directed to the both the PCI VGA device's palette registers and the ISA VGA device palette registers, permitting the palette registers of both devices to be identical.
  • Page 35 Motherboard Technical Specification PCI Slot1 IRQ Priority PCI Slot2 IRQ Priority PCI Slot3 IRQ Priority PCI Slot4 IRQ Priority These options specify the IRQ priority for PCI devices installed in the PCI expansion slots. The settings are Auto, (IRQ) 3, 4, 5, 7, 9, 10, and 11, in priority order.

  • Page 36: Power Management Setup

    Motherboard Technical Specification POWER MANAGEMENT SETUP The AMIBIOS Setup options described in this section are selected by choosing Power Management Setup from the AMIBIOS Setup main menu. Power Management/APM Set this option to Enabled to enable the chipset power management and APM (Advanced Power Management) features.
  • Page 37 Motherboard Technical Specification Green PC Monitor Power State This option specifies the power state that the green PC-compliant video monitor enters when AMIBIOS places it in a power saving state after the specified period of display inactivity has expired. The settings are Off, Standby, Suspend, or Disabled.
  • Page 38 Motherboard Technical Specification Display Activity When set to Monitor, this option enables event monitoring on the video display. If set to Monitor and the computer is in a power saving state, AMIBIOS watches for display activity. The computer enters the Full On state if any activity occurs. AMIBIOS reloads the Standby and Suspend timeout timers if display activity occurs.

  • Page 39: Peripheral Setup

    Motherboard Technical Specification PERIPHERAL SETUP Peripheral Setup options are displayed by choosing Peripheral Setup from the AMIBIOS Setup main menu. All Peripheral Setup options are described here. Onboard Crystal 3D Audio Set this option to Enabled to enable the onboard Crystal 3D Audio. USB Function Set this option to Enabled to enable USB (Universal Serial Bus) support.
  • Page 40 Motherboard Technical Specification Onboard Floppy Controller Set this option to Enabled to enable the floppy drive controller on the motherboard. The settings are Auto (AMIBIOS automatically determines if the floppy controller should be enabled), Enabled, or Disabled. Onboard Serial Port1 This option specifies the base I/O port address of serial port 1.

  • Page 41: Save And Exit Setup

    Motherboard Technical Specification Setting Description Normal The normal parallel port mode is used. Bi-Dir Use this setting to support bidirectional transfers on the parallel port. The parallel port can be used with devices that adhere to the Enhanced Parallel Port (EPP) specification. EPP uses the existing parallel port signals to provide asymmetric bidirectional data transfer driven by the host device.

  • Page 42: Motherboard Technical Specification

    Motherboard Technical Specification Motherboard Technical Specification ENVIRONMENT Parameter Specification Operating Temperature C to +55 Humidity 20% to 80% Atmosphere Non-condensing Non-operating/Transportation Temperature C to +65 Humidity 10% to 90% Atmosphere Non-condensing TX Power Supply Requirement ±5 V ±5 % ±12 V ±5 % Vibration Operating...

  • Page 43: Request For Technical Support

    Request for Technical Support Request For Technical Support In order to provide you with effective and quick technical support, we need to know your system specification and environments. Please fill the following form as complete as possible so we can give you assistance.
