Lightolier HP90 Surface HDB2GLR1FT Specification Sheet

Page 1 of 2
Features
• 78.2% efficient.
• Direct/indirect appearance with soft contoured interior.
• Lens encloses lamp compartment.
• Translucent DR acrylic linear prismatic lens.
• Tension screws secure ends to body.
• Lamp shield opens from either side.
• Ballast accessible from room side.
• Built-in earthquake clips.
• Optional DALI ballast i GEN TECHNOLOGY accepts digital dimming
controllers, scene controllers and automatic control devices.
• Construction meets NYC Code / Chicago Plenum available.
• Not for continuous row mounting.
Dimensions
2-15/16" (75mm)
3-5/8" (92mm)
Lightolier is a Philips group brand
2' x 2' with Acrylic Linear Prismatic Lens, 1 Lamp TT5
24-1/8" (613mm)
7/8" (73mm) Dia. KO (2)
1/4" (51mm) Mounting Holes (2)
24-1/8"
(613mm)
15-3/4" (400mm)
1-5/8" (41mm)
3-5/8" (92mm)
18-7/16" (468mm)
24" (610mm)
HP90 Surface
Direct/Indirect Surface Mounted Fluorescent
2-17/32" (64mm)
2-5/16" (59mm)
Job Information
Job Name:
Cat. No.:
Lamp(s):
Volts/Ballast:
For Factory Technical Information: (978) 657-7600 • Fax (978) 658-0595
631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710
We reserve the right to change details of design, materials and finish.
www.lightolier.com © 2008 a Philips Group
HDB2SLW1FT
Type:
Section 5/Folio M33-10
11/08
