Lightolier HDS2GLW1FT Specification

Page 1 of 2
Features
• 78.2% efficient.
• Only 2-1/4" plenum depth.
• Direct/indirect appearance with soft contoured interior.
• Same fixture fits both G and T ceiling types.
• Fits flush to face of slot grid (T) ceiling.
• Lens encloses lamp compartment.
• Translucent DR acrylic linear prismatic lens.
• Tension screws secure ends to body.
• Lamp shield opens from either side.
• Ballast accessible from room side.
• Wiring access plate standard.
• Optional DALI ballast i GEN TECHNOLOGY accepts digital dimming
controllers, scene controllers and automatic control devices.
• Construction meets NYC Code / Chicago Plenum available.
Mounting Methods
Exposed T-bar
by others
1-1/2"
max.
15/16" *
24"
exposed t-grid ceiling
* For flush mounting when using 9/16" Exposed T-Grid
ceiling system consult factory
Features
T-bar by others
Lens opens from either side
Lightolier is a Philips group brand
Exposed T-bar
by others
Acoustical
1-7/8"
material
max.
by others
9/16"
24"
exposed slot t-grid ceiling
HP90 Semi
Direct/Indirect Semi-Recessed Fluorescent
2' x 2' with Acrylic Linear Prismatic Lens, 1 Lamp TT5
Dimensions
Acoustical
material
by others
2-1/4" (57mm)
Job Information
Job Name:
Cat. No.:
Lamp(s):
Volts/Ballast:
For Factory Technical Information: (978) 657-7600 • Fax (978) 658-0595
631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710
We reserve the right to change details of design, materials and finish.
www.lightolier.com © 2008 a Philips Group
HDS2GLW1FT
2-5/16" (59mm)
24-1/8" (613mm)
1-9/16" X 2-13/16" Access Plate
with (2) 7/8" (73mm) Dia. KO
24" (610mm)
Type:
2-1/4" (57mm)
24"
(610mm)
11/08
Section 5/Folio M33-30
