Bill and Ted Trailer assemBly insTrucTions
inTro
Thanks for buying a Surly trailer. We took care in designing your trailer to work with many
different kinds of bikes, to haul a lot, and to last a long time. But it won't do all these things
to its full potential if it isn't properly assembled. read these instructions and gather
tools and supplies before attempting the assembly of your surly trailer. Improper
assembly will limit its life expectancy and may result in personal injury or death. If you
lack appropriate tools and/or mechanical aptitude, take the trailer to your local bike shop
and get served.
Oh, one more thing: this trailer was not designed for carrying live animals or people. Doing
so may result in injury to you and/or your passengers, and that would make us feel bad.
WHaT you's need
• Metric hex keys
• 14mm and 15mm open-end wrench or adjustable wrench
• Tire pump
• Grease
assemBly seTuP
• Remove all the parts from the box and make sure everything is present
• C ollapse box on floor, blast some tunes, get your break'n on, and properly
dispose of packaging
• Read and understand the instructions
• W e recommend you apply a moisture barrier to inside of frame tubes to prevent
corrosion (J.P.Weigle's Framesaver, linseed oil, etc). This will extend the life
of your trailer
• D uring assembly, apply grease to all fastener threads unless otherwise noted
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Surly Bill and Ted
Summary of Contents for Surly Bill and Ted
- Page 1 Bill and Ted Trailer assemBly insTrucTions inTro Thanks for buying a Surly trailer. We took care in designing your trailer to work with many different kinds of bikes, to haul a lot, and to last a long time. But it won’t do all these things to its full potential if it isn’t properly assembled.
- Page 2 Trailer ParTs lisT Part# Description QR Axle Screw - M8 x 20mm Bearing Cap Washer Hitch Axle Bearing Non-Drive Side Skewer Nut QR Skewer Rod Drive Side Skewer Nut Bearing Retaining Ring Axle Hook Spring Axle Hook Thumbscrew Drive Side Yoke Yoke Clamp Screw - M6 x 20mm Non-Drive Side Yoke Hammer Joint Lock Nut - M10 x 1 Hammer Joint Brass Bearing Hammer Joint Serrated Washer Hammer Joint Pivot Bolt Boom Safety Bolt Screw - M8 x 30mm Wheel Cover Spoke Guard / Fender Screw - M5 x 16mm Wheel Cover Clamp Screw - M6 x 25mm Deflector Shield Flat-Head Screw - M6 x 20mm Deflector Shield Wheel Retaining Bolt - Non-Drive Side...
- Page 3 Trailer HiTcH Trailer Bed 35 36 26 27 24 25...
- Page 5 Bed assemBly 1. A pply a light coating of grease to the entire outside of the stub axles and fully insert the axles into the trailer bed axle tube. noTe: The stub axles for each side of your trailer are different! The stub axle marked ‘D’ goes into the right side of the trailer bed (bicycle drive side) and the stub axle marked ‘ND’ goes into the left side of the trailer bed (bicycle non-drive side). During installation, rotate the stub axles so that the wedges are orientated in the 6 o’clock position.
- Page 6 connecTing HiTcH To Bed 10. I nsert the hitch into the clamp at the front of the trailer bed and snug tight the clamp bolts. You’ll adjust orientation of the hitch later. noTe: The hitch assembly will need to swing down to allow the threaded safety bolt boss to clear the gusset on the trailer bed. 11. T hread the (1) M8 x 30mm machine screw into the safety bolt boss on the boom. 12. Have you been making sure all your hardware is greased? connecTing Trailer To BiKe 13. Prep rear wheel if you have a Qr axle Remove the skewer from your hub.
- Page 7 You can easily check the tongue weight of your trailer with a standard bathroom scale. After you have loaded everything and the bike is attached to the trailer, place the scale under the rear wheel of your bike (without you on the bike) and ensure that the scale does not read over 50 lb. Obviously, your cargo must be well-secured to the trailer. Use Surly Junk Straps, ropes, bungees, etc. to hold things in place. Tire Pressure Tire pressure will play a large role in the performance of your trailer. After your trailer has been loaded, adjust the tire pressure to best work with your load (35 psi is a good place to start).
- Page 8 WarranTy: Surly trailers are guaranteed to be free from manufacturing defects for three years from the original date of purchase. What this means is that if we screwed up something in the manufacturing process that resulted in the premature failure of the product, we’ll fix or replace it at our discretion. This warranty is for the original buyer of the product and is not...
