Ice Cream Truck Fork Instructions
Hi there. Thanks for spending your hard-earned cash on this Surly fork. Surly stuff is designed to be useful and durable.
We're confident it will serve you well for years to come.
WARNING: Cycling can be dangerous. Bicycle products should be installed and serviced by a professional mechanic.
Never modify your bicycle or accessories. Read and follow all product instructions and warnings including information
on the manufacturer's website. Inspect your bicycle before every ride. Always wear a helmet.
Additional Product and Safety Information can be found at the website: surlybikes.com/safety
Compatibility
Steerer:
Steerer diameter:
Steerer length:
Axle-to-crown:
Offset:
Hub spacing:
Tire clearance:
Brakes:
*NOTE — 135mm Surly Ice Cream Truck, Moonlander and Pugsley forks use "rear rotor spacing" for brake rotor placement on the hub, and are not compatible with all fat bike hubs. Check with the hub
manufacturer for compatibility. Surly 135mm front hubs use "rear rotor spacing" for brake rotor placement.
Intended Use
RETAILER: These fork instructions MUST BE provided to the end user.
CONDITION 4
ASTM F2043
This is a set of conditions for operation of a bicycle that includes Conditions 1, 2, and 3, or downhill grades
on rough trails at speeds less than 40 km/h (25 mph), or both. Jumps are intended to be less than 122cm (48˝).
Please see link to Bike Owner's Manual on surlybikes.com/safety for complete list of riding condition descriptions.
4
Jumps are
intended to be
less than
122cm (48")
Tools Required
• Crown race setting tool
• Star nut setter
• Hammer/mallet
• Steerer tube cutting guide (recommended)
Verify that the fork, headset and all required parts for proper assembly have compatible dimensions. The fork, headset,
headset spacers and stem steerer clamp must have compatible diameters. Use of incompatible components can cause
component failure.
Make sure headset and stem parts that come into contact with the steerer tube are free of burrs or sharp edges.
Remove burrs or sharp edges by using very fine grit sandpaper.
Threadless
1-1/8˝
260mm
483mm
47mm
150mm x 15mm thru,
front disc rotor spacing
26 x 5.25˝
Disc
Threadless
1-1/8˝
260mm
483mm
47mm
135 x 10mm QR*
26 x 5.0˝
Disc
• Hacksaw and permanent marker or tape
• Cutting fluid (recommended)
• Hex wrenches: 4, 5, 6mm
• Torque wrench
6932 06/14
