Surly Dummy Deck Instructions

Dummy Deck Instructions
Hi there. Thanks for spending your hard-earned cash on this Surly product. Surly stuff is designed to be useful and durable.
We're confident it will serve you well for years to come.
The Dummy Deck, offered in two widths, fat and standard, provides a light, durable cargo platform and rail connector for
your Surly long-tail cargo bike. It features cut-outs for attaching straps and cordage, a mounting hole for a rear light bracket,
and accessory-mounting holes.
Our deck is made of 4mm-thick aluminum, chosen for its strength, durability, and recyclability. Aluminum can be painted,
powdercoated, and anodized. It machines relatively easily, it resists corrosion if properly coated, and it lends itself to a low-profile,
lightweight design.
The Dummy Deck bolts directly to Dummy Rails using M5 metric hardware. We include 20mm-long stainless steel flanged button-
head machine screws with the Dummy Rails for this application.
We highly recommend you have your Dummy Rails installed by a competent professional bicycle mechanic.
WARNING: Cycling can be dangerous. Bicycle products should be installed and serviced by a professional mechanic.
Never modify your bicycle or accessories. Read and follow all product instructions and warnings including information
on the manufacturer's website. Inspect your bicycle before every ride. Always wear a helmet.
Check with your bicycle's manufacturer to verify proper fit, mounting points, bicycle cargo load capacity, and compatibility for
carrying cargo. Do not exceed the bicycle's permissible load.
For additional safety information about all Surly products visit: surlybikes.com/safety
Le mode d'emploi est disponible sur le site Web : surlybikes.com/safety
Dummy Deck Compatibility & Intended Use
Surly Dummy Decks are designed specifically for use with the Surly family of long-tail cargo bikes and Dummy Rails.
NOTE: Fat Dummy Deck is compatible with a maximum wheel size of 26 x 5.25"
Standard Dummy Deck is compatible with a maximum wheel size of 26 x 2.5"
RETAILER: These instructions MUST BE provided to the end user.
NOTE: Never exceed ASTM Use Condition 2 when transporting passengers.
INTENDED USE: CONDITION 2
This is a set of conditions for the operation of a bicycle that includes Condition 1 as well as unpaved and gravel roads
and trails with moderate grades. In this set of conditions, contact with irregular terrain and loss of tire contact with
the ground may occur. Drops are intended to be limited to 15cm (6") or less. Please see link to Bike Owner's Manual
on surlybikes.com/safety for complete list of riding condition descriptions.
For off-road
riding and
Consult long-tail cargo complete bike and frameset specifications for ASTM Use Conditions for general use and cargo
jumps less than
12" (30cm)
transportation.
NOTE: Be mindful of your surroundings and path or trail conditions. When conditions exceed what is safe for a passenger, have
your passenger dismount from the cargo bike.

Parts Included

Standard or Fat Dummy Deck

Tools Needed

Grease
3mm hex wrench
Torque wrench measuring in Nm

Installation on Dummy Deck

1. Install Dummy Rails according to the instructions.
2. Install Dummy Bags on Dummy Rails according to the instructions.
3. Place the deck on top of the rails, lining up the deck slots with the threaded
rail bosses.
4. Grease the threads of the flanged button head screws supplied with the
Dummy Rails.
5. Thread the screws through the slotted deck holes and into the threaded rail bosses.
Don't tighten any screws until all of them have been threaded into the rails.
6. Tighten the deck-fastening screws to 4–5 Nm.
6400 West 105th Street, Bloomington, MN 55438
P 877.743.3191 E derby@surlybikes.com W surlybikes.com
212301 12/19 | 85-000418_INST_E
