Specifications - TC-Helicon VoiceTone Create.XT Product Manual

Analog Inputs
Connectors Balanced XLR, Input Impedance
Mic Input Sensitivity @ 0dBFS
Mic Input Sensitivity @ 12dB headroom
EIN @ max. mic amp gain, Rg = 150 Ohm
Analog Outputs
Connectors
Output Impedance
Output Level @ 0dBFS
Input to Output Analog Audio Performance
Dynamic Range, Mic. @ Min gain 20Hz-20kHz *A-weighted >108dB
Dynamic Range, Mic. @ -18dBu sensitivity20Hz - 20kHz
THD+ Noise, Mic. @ Min gain
Frequency. Response, Max gain
-1.5dB @ 40 Hz, (200Hz to 20 kHz), +0/-0.3 dB
Conversion Characteristics
Sample Rate
Converter
AD / DA Conversion
1kOhm
-44dBu to +2dBu
-56dBu to -10dBu
-128dBu
Balanced XLR
40 Ohm
+2dBu
> 104dB
<-90dB
48 kHz,
AKM AK4620B
24 bit, 128x oversampling bitstream
EMC & Safety
Complies with EN 55103-1 and EN 55103-2 FCC part 15, Class B,
CISPR 22, Class B
Certified to IEC 65, EN 60065, UL6500 and CSA E60065 CSA FILE
#LR108093
Environment
Operating Temperature
Storage Temperature
Humidity
Supplementary
Dimensions 130mm x 132mm x 41mm (5" x 5.25" x 1.5")
Weight
Warranty Parts and labor

Specifications

32° F to 122° F (0° C to 50° C)
-22° F to 167° F (-30° C to 70° C)
Max. 90 % non-condensing
1.5 lb. (0.72 kg)
1 year
29
