MODEL 302IQ
©
(1991-MSRP $149.00)
OWNER'S MANUAL AND
INSTALLATION GUIDE
INTRODUCTION
Latest technology, high sound quality, powerful delivery, and LINEAR POWER™
reliability all describe LINEAR POWER™ low profile amplifiers. With new "IQ"
©
circuitry, their value increases. Versatile capabilities such as stereo, mono or
mixed stereo/mono operation and 2 ohm capability make these amplifiers
extremely desirable as the foundation of a multi-amplifier system.
TECHNICAL DESCRIPTION
The "IQ"
series amplifiers are low profile inverted channel ("I") amplifiers. A
©
quiet turn on circuit ("Q") has been added for improved performance. The
amplifier design incorporates an unregulated power supply for increased dynamic
headroom efficiency. The output stages of the 302IQ
amplifier will deliver a
©
significant increase in power into 2-ohm stereo loads. Amplifier reliability is
accomplished by the amplifier operation level being set at approximately 50% of
output transistors' rated power handling.
WIRING INSTRUCTIONS
Disconnect battery ground cable before making any power connections.
RED WIRE: +12 volts. Connect directly to battery positive terminal and should be
fused within 18 inches of battery and another fuse where the connection to the
amplifier is made. Remember to use the proper size fuses.
WARNING: USING
OVERSIZED FUSES IS DANGEROUS AND WILL VOID THE WARRANTY!
See specifications for proper fuse size. Do not install power fuse until amplifier
installation is completed!
© 2008 Linear Power, Inc. - ALL RIGHTS RESERVED
1
LINEAR POWER™ is a trademark of Linear Power, Inc.
Advertisement
Table of Contents
Related Manuals for Linear Power 302IQ
Summary of Contents for Linear Power 302IQ
- Page 1 INSTALLATION GUIDE INTRODUCTION Latest technology, high sound quality, powerful delivery, and LINEAR POWER™ reliability all describe LINEAR POWER™ low profile amplifiers. With new "IQ" © circuitry, their value increases. Versatile capabilities such as stereo, mono or mixed stereo/mono operation and 2 ohm capability make these amplifiers extremely desirable as the foundation of a multi-amplifier system.
- Page 2 4-ohm load may be used. For systems requiring higher sound quality, an 8-ohm load is recommended. (See diagram on next page) © 2008 Linear Power, Inc. - ALL RIGHTS RESERVED LINEAR POWER™ is a trademark of Linear Power, Inc.
- Page 3 302IQ STEREO AND BRIDGED/MONO OPERATIONAL DIAGRAMS © 2008 Linear Power, Inc. - ALL RIGHTS RESERVED LINEAR POWER™ is a trademark of Linear Power, Inc.
- Page 4 Follow the polarity of the strip as described in the section above. A second set of satellites may be added for 2-ohm operation. 3-CHANNEL OPERATIONAL DIAGRAM © 2008 Linear Power, Inc. - ALL RIGHTS RESERVED LINEAR POWER™ is a trademark of Linear Power, Inc.
- Page 5 This can be caused by lack of proper air circulation to the amp, or too low of speaker impedance. © 2008 Linear Power, Inc. - ALL RIGHTS RESERVED LINEAR POWER™ is a trademark of Linear Power, Inc.
