Cleveland SGM Repair Manual

Free standing gas skillet
Hide thumbs

Advertisement

Quick Links

Download this manual
Repair Manual
Free Standing Gas
Skillets
Model SGM
UNITED STATES
1333 East 179th St. Cleveland- Ohio 44110 Phone:
(216) 482 -4900 Telex 98-0546 FAX:(216) 481-3782
Cleveland Range, Inc.
CANADA
Garland Commercial Ranges ll77 Kamano
Road
MississaughaOntario Canada L4W1X4
Phone: (416) 624-0260
FAX-
(416) 624-0623

Advertisement

loading
Need help?

Need help?

Do you have a question about the SGM and is the answer not in the manual?

Questions and answers

Related Manuals for Cleveland SGM

Summary of Contents for Cleveland SGM

  • Page 1 Free Standing Gas Skillets Model SGM Cleveland Range, Inc. UNITED STATES CANADA 1333 East 179th St. Cleveland- Ohio 44110 Phone: Garland Commercial Ranges ll77 Kamano Road (216) 482 -4900 Telex 98-0546 FAX:(216) 481-3782 MississaughaOntario Canada L4W1X4 Phone: (416) 624-0260 FAX-...
  • Page 2 Cleveland Range's liability on any claim of any kind including negligence, with respect to the goods or services covered hereunder, shall i no case exceed the price of the goods or services, or part thereof which gives use to the claim, NO EVENT SHALL CLEVELAND RANGE BE LIABLE FOR SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES, OR ANY DAMAGES IN THE NATURE OF PENALTIES.
  • Page 3 GAS SKILLET OPERATING CONTROLS AND INDICATORS For your better understanding and confidence, the following explanation of the control system used on these skillets is offered. Item No. Description Function Gas Control Valve Controls main gas supply to the skillet. (Skillet Bottom Dwg.) Micro (Cut-off) Switch Protective switch to prevent burners from igniting while skillet is in a tilted position.
  • Page 4 Use only replacement parts which are factory supplied as to preserve the certification of Underwriters Laboratories, American Gas Associaton, Canadian Standards Association or Canadian Gas Association (as applicable). The use of other than factory supplied replacement pans will void the warranty.
  • Page 5 Pilot Burner KE01018 Ignition Electrode (Spark Ignition) KE51116 Orifice, Pilot, Nat. Gas (.020") KE51162 Orifice, Pilot, LP. (.0145') SK50334 Zip Tube (SGM-30) SK50335 Zip Tube (SGM-40) SK50373 Micro (cut-off) Switch SK50363 Orifice, Zip Tube, Nat. Gas. #61 drill SK50364 Orifice. Zip Tube, LP., #72 drill SK50252 Heat Spreader (R H.
  • Page 6 Item No. Part No. Description Qty. SK00028 Thermostat, Control / Safety FA10140 Screw, Thermostat, 6-32 x 1 1/ 4" SK00031 Bezel FA10135 Screw, Bezel, 6-32 x 5/8 SK50059 Knob, Thermostat SK50062 Rubber Boot KE50504 Switch, Toggle, On/Off, SPST (115V Units) SK50056 Switch, Toggle, On/Off, DPST (208-240V Units)
  • Page 7 Transformer -120/24V *Note: Pilot Re-Lite and Cycling Pilot Safety Timer may be combined as one control, Cat. No. 50A22-1. Cleveland Part No. KE51405 Use only replacement parts which are factory supplied as to preserve the certification of Underwriters Laboratories American Gas Association, Canadian Standards Association or Canadian Gas Association (as applicable).
  • Page 8 GAS SKILLET POWER JACK ASSEMBLY Item No. Part No. Description Qty. SK50314 Complete Power Jack SE50025 Motor, Power Jack SK50377 Retaining Ring SK50376 Pin, Bottom Jack Mounting SK50425 Washer, 17/32" ID, 1-1/16" OD SK50368 Acorn Nut, 5/16-18 SK50367 Washer, 25/64" ID, 5/8" OD SK50256 Pin, Upper Jack Mounting SK50376-B...
  • Page 9 SKILLET HINGE ASSEMBLY Item No. Part No. Description Qty. KE00598 Hinge Assy. (30 Gal) SK00168 Hinge Assy. (40 Gal) KE51218 Body, Hinge KE50823 Pin, Hinge KE50820 Insert, Hinge KE50819 End Piece, Hinge FA11507 Screw, Tension Adjust, 10-24 x 3/4" FA11284 Screw, End Piece, 1/4 -20 x 1/2 °...
  • Page 10 KETTLE AND SKILLET FAUCET...
  • Page 11 KETTLE AND SKILLET FAUCET Item No. Part No. Description Qty. SE50020 Hot Water Stem Assy SE50021 Cold Water Stem Assy SE50022 Yoke Connection Kit FA00016 "0" Ring FA95022 Retaining Ring KE51404 Spout Nut see chart 3/4" spout (please see 3/4" spout chart below) 3/4"...
  • Page 12 FLOOR MODEL SKILLET COVER VENT CAP AND DEFLECTOR Item No. Part No. Description Qty. SK00105 Screw, 1/4- x3/8° SK50179 Washer SK00054 Vent Cap Assy. SK51032 Support Arm SK50218 Knob SK50131 Spacer SK00059 Cover SK50133 Spacer SK50444 Knob *3,4 SK00175 Deflector Assy. (30 Gal.) SK00176 Deflector Assy (40 GaL) The first figure represents the 30 gallon model and the second figure represents the 40 gallon model.

  • Page 13: Servicing Guide

    SERVICING GUIDE This section contains servicing information intended for use by Authorized Service Personnel. A/ Problem: Skillet is not heating at all. (Skillet must be on, thermostat control set, and in a down position) Possible Causes 1. No power - either gas or electric. Defective pilot flame sensor.
  • Page 14 Can a pilot flame be achieved? Refer to Pilot Flame Adjustment Procedure and adjust flame if necessary. If adjustment is not required or unsuccessful, go to step #10. Replace defective gas control valve. Does the pilot flame sensor (thermopile) generate 450- Replace defective gas control valve.
  • Page 15 After pilot has been lit and just as pilot goes out Replace defective gas control valve. due to cycling pilot safety timer, pull pilot flame Refer to Pilot Flame Adjustment Procedure and sensor's connection off and quickly measure adjust flame if necessary. If adjustment is not continuity between pins #2 and #4.

  • Page 16: Fault Isolation Procedure

    D/Problem: Skillet fails to tilt. (Note: A thermal overload in jack motor does not allow constant consecutive tilting.) Possible Causes No electrical power to the skillet . Defective ON/OFF switch. Circuit breaker tripped or defective. Defective 208-240/120 VAC transformer Detective rocker (up - down) switch. (208-240V units).
  • Page 17 GAS PRESSURE ADJUSTMENT PROCEDURE CAUTION: The following procedure, as well as other work on gas controls should be performed only by a qualified service technician. NOTE: Gas pressure adjustment is pre-set and rarely needs any adjustment. Remove gas pressure adjustment cover screw. 2- Operating gas pressure output should be regulated to 6"W.C.
  • Page 18 POWER JACK REMOVAL PROCEDURE WARNING: Skillet pan is heavy and support should always be given to pan if jack is being removed. Refer to correct diagram and follow procedure required. PROCEDURE #1 1. Remove two screws holding pin retaining bracket. 2.
  • Page 19 HINGE ADJUSTMENT INSTRUCTIONS Insert 3/8" Allen wrench. Turn clockwise to relieve tension on spring. While tension is released remove one of the two slotted screws. To prevent Allen wrench from springing back abruptly while the second slotted screw is removed, insert a pin (approximately 1/8") in the hole where the first slotted screw was removed from.
