HARDWARE GUIDE
BIGTOUCH INF7011
009-1521-02

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BIGTOUCH INF7011 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for InFocus BIGTOUCH INF7011

Summary of Contents for InFocus BIGTOUCH INF7011

  • Page 1 HARDWARE GUIDE BIGTOUCH INF7011 009-1521-02...

  • Page 3: Table Of Contents

    CONTENTS Declaration of Conformity ..............................3 Safety Considerations .................................4 What’s Included ..................................6 Setup ....................................7 Mounting ..................................7 Connecting to Other Devices ............................8 Connecting AC Power ..............................9 External PC Touchscreen Control Setup ........................9 Turning the Monitor On/Off ..............................9 Setting up the Wireless Mouse and Keyboard ........................10 Wireless Mouse ................................10 Wireless Keyboard ..............................10 Using the Remote ................................11...

  • Page 5: Declaration Of Conformity

    SRS Labs, Inc. InFocus, In Focus, INFOCUS (stylized), MondoCenter, Mondopad, BigTouch, and JTouch are either registered trademarks or trademarks of InFocus Corporation in the United States and other countries. All other trademarks are the property of their respective owners. Any other trademarks, service marks, personal names or product names are assumed to be the property of their respective owners and are used only for reference.

  • Page 6: Safety Considerations

    Input ratings: 100-240V~, 50-60Hz, 5A Output ratings: 100-240V~, 50-60Hz, 1A InFocus reserves the right to alter product offerings and specifications at any time without notice. SAFETY CONSIDERATIONS Please read and follow all safety instructions provided below and on the monitor before connecting the monitor to a power source.
  • Page 7 • Refer all service to qualified service personnel. Do not remove the cover or back. Servicing your own monitor can be dangerous to you and will void the warranty. • Only use replacement parts specified by InFocus. Unauthorized substitutions may result in fire, electrical shock or injury and may void the warranty.

  • Page 8: What's Included

    • 6' 3.5mm to L/R RCA cable *Not included for all countries. For setup purposes, a keyboard and mouse are recommended. For additional accessory options, such as stands, feet, carts and wall mounts, see the InFocus website (www.infocus.com/store) or your local dealer.

  • Page 9: Setup

    SETUP Mounting This product does not ship with mounting accessories. Only use commercially manufactured mounting accessories which meet this product's specifications and follow the manufacturer installation instructions. • Only use properly rated wall and stand mounting hardware that meet this product’s specifications and follow the manufacturer installation instructions.

  • Page 10: Connecting To Other Devices

    Connecting to Other Devices A full range of digital and analog video inputs and audio source devices can be connected to the connection panels on the back and side of the monitor. Available jacks include: HDMI In (2), PC In (1), Composite Video (1), Component RCA (1), RS232 (1), Audio In 3.5mm (1), Audio In RCA (1-R/L), Microphone In (1), RJ45 (2), USB-B for touch control (1), USB 2.0-A (5), USB 3.0-A (2), Audio Out RCA (1-R/L), and HDMI Out (1).

  • Page 11: Connecting Ac Power

    Connecting AC Power Connect one end of the AC power cord to the AC In jack on the back of the monitor. Connect the other end of the AC power cord to an AC outlet. Press the power switch. (The LED on the front of the monitor turns on.) NOTES: • Your monitor should only be operated from the power source indicated on the label.

  • Page 12: Setting Up The Wireless Mouse And Keyboard

    SETTING UP THE WIRELESS MOUSE AND KEYBOARD NOTE: The wireless mouse and keyboard is not included as a standard accessory for some countries. For initial setup and/or configuration, it may be easier to use a mouse and keyboard. Any standard wired or wireless mouse or keyboard can be connected through the monitor's USB ports.

  • Page 13: Using The Remote

    USING THE REMOTE The remote uses two (2) AAA batteries (not included). Install the batteries by removing the cover from the remote’s back, aligning the + and – ends of the batteries, sliding them in place and replacing the cover. To operate, point the remote at the monitor sensor at the bottom right-hand corner of the monitor.
  • Page 14 Remote buttons Power: Switches the power on or puts the monitor into Standby. POWER POWER Home: Changes the active source back to the embedded PC. HOME HOME INPUT MENU RESIZE Input: Toggles the Input Source menu on and off, which allows the user to INPUT change sources.

  • Page 15: Using The Keypad

    USING THE KEYPAD The keypad, located on the side of the monitor, has the following buttons: Power button: Switches the power on or puts the monitor into Standby. Input button: Turns the Source menu on allowing the user to change sources. Saves changes/selections if the OSD menu is on.

  • Page 16: Osd (On-Screen Display) Menu System

    OSD (ON-SCREEN DISPLAY) MENU SYSTEM The OSD provides the user the ability to control the monitor display. This is different than the Mondopad software described in the Mondopad Software Guide. To access the OSD, press the Menu button on the remote or the keypad located on the right-hand side of the monitor. Use the up and down arrows on the remote or keypad to scroll through the menu options and press OK to enter the highlighted menu.

  • Page 17: Picture Menu

    Picture Menu PICTURE BRIGHTNESS CONTRAST SHARPNESS NATIVE COLOR TEMPERATURE COLOR CONTROL BLUE GREEN STANDARD PICTURE MODE PICTURE RESET < > Adjust Enter Back Quit Brightness: changes the intensity of the image. Range: 0-100. (Default 70.) Contrast: controls the degree of difference between the lightest and darkest parts of the picture and changes the amount of black and white in the image.

  • Page 18: Screen Menu

    Screen Menu SCREEN H POSITION V POSITION CLOCK CLOCK PHASE ASPECT RATIO WIDE SCREEN RESET < > Adjust Enter Back Quit H Position: adjusts the horizontal position of the image. Range: 0-100. (Default 50.) V Position: adjusts the vertical position of the image. Range: 0-100. (Default 50.) Clock: adjusts the width of the image (For VGA input only).

  • Page 19: Audio Menu

    Audio menu AUDIO SPEAKER INTERNAL AUDIO SOURCE PC SPEAKER AUDIO RESET < > Adjust Enter Back Quit Speaker: controls whether both the internal and external speakers (sound bar, etc.) or just external speakers are used. Options include: Internal (both internal and external speakers operate) and External (only external speakers operate). Default Internal.

  • Page 20: Pip Menu

    PIP menu PIP SIZE SMALL PIP AUDIO MAIN PIP RESET < > Adjust Enter Back Quit PIP Size: changes the size of the PiP window used in the Corner-to-Corner configuration. Options include: Small (default), Middle and Large. PIP Audio: switches the audio source from the main source to the PiP source. Options include: Main (default) and Sub. PIP Reset: resets all PIP menu items to factory default settings.

  • Page 21: Configuration 1

    Configuration 1 CONFIGURATION 1 AUTO ADJUST ENGLISH LANGUAGE NTSC COLOR SYSTEM CONFIGURATION RESET FACTORY RESET < > Adjust Enter Back Quit Auto Adjust: automatically adjusts the display of an external VGA source image. Press OK on the remote to activate. Language: switches the OSD menu language.

  • Page 22: Configuration 2

    Configuration 2 CONFIGURATION 2 OSD TURN OFF INFORMATION OSD SLEEP TIMER OSD H POSITION OSD V POSITION MONITOR INFORMATION < > Adjust Enter Back Quit OSD Turn Off: controls how many seconds the OSD menu remains on the screen Range: 5-120 (seconds). (Default: 45) Information OSD: controls how many seconds the Information OSD remains on the screen.

  • Page 23: Advanced Option

    Advanced Option ADVANCED OPTION INPUT RESOLUTION MODE1 GAMMA SELECTION OVER SCAN SCAN CONVERSION NORMAL IR CONTROL UNLOCK KEYBOARD CONTROL MONITOR ID DDC/CI ADVANCED OPTION RESET < > Adjust Enter Back Quit Input Resolution: sets the resolution of the VGA input. This is only required when the monitor is unable to detect the VGA input resolution correctly.

  • Page 24: Troubleshooting

    TROUBLESHOOTING SYMPTOM POSSIBLE SOLUTIONS No power • Verify the power cord is properly connected to the power outlet and to the monitor. • Verify the power switch is ON and that the Power button on the remote or keypad has been turned on (the front LED should be white). • Plug another electrical device to the power outlet to verify that the outlet is supplying the proper voltage.
  • Page 25 Remote is not working • Make sure the batteries are installed in the proper orientation and are not dead. • Verify the remote is turned on (the button is on the bottom of the remote). • Verify you are pointing the remote at the table and are within 26’ (8m) and 30 degrees (horz/vert) of the sensor.
  • Page 26 • The monitor is in standby mode. Press the Power button on the remote or keypad. White Green • The monitor is powered on. Orange • Contact InFocus Support at www.infocus.com/support. For additional troubleshooting support, please contact: InFocus Corporation - Technical Support 6am-5pm PST 877-388-8385 www.infocus.com/support...

  • Page 27: Specifications

    SPECIFICATIONS To read the latest product specifications, be sure to visit our support website at www.infocus.com/support, as specifications are subject to change. Size (viewable) 69.51” (176.56cm) diagonal Dimensions (without stand) 65.3" W x 39.5 H x 4.1" D (165.86 x 100.33 x 10.41cm) Weight (without stand) 176.37lbs (80 kg)

  • Page 28: Limited Warranty

    If a hardware defect arises and a valid claim is received within the Warranty Period, at its option and to the extent permitted by law, InFocus will either (1) repair the hardware defect at no charge, using new parts or refurbished...
  • Page 29 (l) if the product is not used under normal operating conditions which are defined as use not in excess of 16 hours continuously per day with a minimum 8 hour period of continuous rest in the powered off state; or (m) if any InFocus serial number has been removed or defaced.
  • Page 30 EXPRESS WARRANTY AND TO THE REPAIR OR REPLACEMENT SERVICE AS DETERMINED BY INFOCUS IN ITS SOLE DISCRETION. No InFocus reseller, agent, or employee is authorized to make any modification, extension, or addition to this warranty. If any term is held to be illegal or unenforceable, the legality or enforceability of the remaining terms shall not be affected or impaired.
  • Page 31 If during the diagnosis period, InFocus identifies that the repair can be accomplished by the use of a CSR part, InFocus will ship that part directly to you for replacement. There are two categories of CSR parts: • Parts for which customer self repair is mandatory. ...
  • Page 32 InFocus may install system software updates as part of warranty service that will prevent the hardware from reverting to an earlier version of the system software. Third party applications installed on the hardware may not be compatible or work with the hardware as a result of the system software update.

  • Page 33: Appendix

    APPENDIX Calibration Tool From your Start menu, navigate to All Programs>PQLabs Software>MultiTouch Platform, and double-click MultiTouchPlatform. The MultiTouch Platform window displays. Using a mouse and keyboard, click Calibrate. The Reset Touchscreen Data window displays. INF7011 Hardware Guide Page 31...
  • Page 34 Do not touch the screen until the white cross and the message Touch + for more than 1 second" displays. Using a stylus (or your finger), touch and hold the white cross until the cross turns green and the message Please release your finger displays.

  • Page 35: Calibration Troubleshooting Tool

    Calibration Troubleshooting Tool From your Start menu, navigate to All Programs>PQLabs Software>MultiTouch Platform, and double-click MultiTouchPlatform. The MultiTouch Platform window displays. Click Diagnose. The Start MultiTouch Doctor window displays. Click Start. INF7011 Hardware Guide Page 33...
  • Page 36 If a check mark appears, the panel has passed that test. If a red X appears, the panel has failed. In that case, follow the instructions in the Details box. If instructed to send a report to the PQ Labs team, click Send report, type your information, and click Send. Close the application.

  • Page 37: 安全注意事項

    安全注意事項 在將顯示器連接到電源之前，請仔細閱讀並遵守顯示器上提供的下述安全說明。如不遵守安全說明則可能導致火災、觸電或 人身傷害，並可能損壞或 損害對設備所提供的保護。 請妥善保存所有安全說明。 • 這種顯示器是非常沉重的，應由至少兩個人進行搬動和安裝。不要試圖自行搬動或安裝顯示器，否則可能造成傷害和/ 或損害。 • 搬動顯示器時，利用手柄和側板或底板始終牢固地把持住顯示器。不要把持頂板。 • 在搬動顯示器紙箱時，不要傾斜或倒置紙箱。始終將其保持在豎直方向。 • 在移動顯示器前，請斷開所有配件和電纜。 • 如果顯示器安裝在牆上，顯示器與牆壁之間的距離至少保持為 1.98 英寸（5釐米），以提供足夠的通風。 • 請參閱正確的開機和關機程式方面的指南。 • 遵循本手冊和顯示器上的所有警告和注意事項。 • 顯示器的安放位置遠離加熱和冷卻通風孔至少 4 英尺（1.2米）。 • 請勿堵塞通風口。顯示器放在通風良好且不阻礙進氣口和排氣口的地方。 • 不要在諸如散熱器、熱記錄器、火爐或其他發熱設備（包括放大器）等熱源附近安裝或使用顯示器或揚聲器。 • 不要將顯示器放置在陽光直射、潮濕、油膩或灰塵較多的地方，或顯示器可能接觸到雨水、煙霧或蒸汽的地方。 • 顯示器使用的電源線不應該靠近水，例如靠近浴缸、洗臉盆、廚房水槽、游泳池等。 • 不要在靠近水的地方使用顯示器的任何元件，包括揚聲器。警告：為減少火災或觸電的危險，請勿將本設備和該設備的 任何元件淋雨或受潮。 • 請勿摔落顯示器。 • 不要將液體灑在顯示器上。濺落的液體可能損壞顯示器。...
  • Page 38 • 只使用富可視公司指定的更換零部件。未經認可的代用品可能會導致火災、觸電或人身傷害，並可能導致保修失效。 • 在將顯示器安裝到牆上時，必須使用 M8 (12 毫米) 規格的螺栓。此外，安裝介面應符合北美 UL1678 標準。安裝方 式應牢固到足以承受顯示器的重量(無底座重量約為176.37 磅/80斤）。 • 請遵照以下說明，以確保顯示器使用壽命期間的圖像品質。不遵守這些說明可能會影響保修。 • 鋰電池（PC 主機殼中的）注意事項：如果更換的電池類型不正確，則有爆炸的危險。更換的電池應為相同類型，或製 造商推薦的等效類型。根據當地 處理法規處理廢舊電池。 Page 36...

  • Page 39: Bigtouch 70"顯示器I/O Port 介紹前/後面板

    BigTouch 70”顯示器I/O port 介紹前/後面板 Antennas TOUCH CONTROL RS232 IN 1 Audio IN 2 Audio OUT VIDEO HDMI2 HDMI1 PC IN COMPONENT TOUCH TOUCH CONTROL CONTROL 將USB纜線從顯示器連接至外部電腦，以便使用觸控模組。 直接存取USB磁碟機上的多媒體檔案。 INF7011 Hardware Guide Page 37...
  • Page 40 VIDEO HDMI2 HDMI1 PC IN COMPONENT VIDEO 接受來自外部裝置（例如VCR或DVD播放器）的VIDEO信號。 HDMI2 接收外部裝置的HDMI信號。 HDMI1 接收外部裝置的HDMI信號。 PC IN 接收來自外部裝置（例如電腦）的類比RGB訊號。 COMPONENT 接收來自外部裝置（例如DVD播放器,HDTV裝置或雷射光碟播放器）的色 差視訊(YPbpr)訊號。 ANTENNAS 無線數據的接收和發射。 Antennas POWER 開啟/關閉主機。 USB-A 連接至USB 3.0/2.0硬碟機，數據傳輸。 RJ45 連接到乙太網絡。 HDMI 將內部信號通過HDMI線纜輸出至另一台顯示器上。 RS232 連接外部數據機。 RS232 連接至麥克風。 AUDIO IN1 接收來自外部裝置（例如iPod播放器）所發出的音頻訊號。 IN 1 AUDIO IN2 Audio 接收來自外部裝置（例如DVD播放器）所發出的音頻訊號。...
  • Page 41 開啟或關閉顯示器。 選取/確認屏幕顯示(OSD) 功能表中的選項。 INPUT MENU 開啟或關閉OSD 功能表。 CH ^ 在OSD 功能表中向上捲動瀏覽各個設定和選項。 在OSD 功能表中向下捲動瀏覽各個設定和選項。 VOL ^ 音量增加鍵，在OSD 功能表中向左捲動瀏覽各個設定和選項。 音量減小鍵，在OSD 功能表中向右捲動瀏覽各個設定和選項。 INF7011 Hardware Guide Page 39...
